- Page 1 Installation Instructions crlaurence.com CRL690 SERIES SLIDING DOOR KITS CRL690 | CRL6901 | CRL690D | CRL6901D C.R. Laurence Co., Inc · 2503 E. Vernon Ave., Los Angeles, CA 90058 · 1.800.421.6144 · crlaurence.com MAY 18, 2023...
-
Page 2: Parts List
CRL690 SERIES SLIDING GLASS DOOR SYSTEM INSTALLATION MANUAL PARTS LIST Wall and Ceiling mount Kit CRL690/BSA/MBL CRL690D/BSA/MBL Dropped ceiling mount Kit Kit Contains: Kit Contains: 1xCRL4932EXT 1xCRL2940 1xCRL490EXT 1xCRL4939 1xCRL2945 SET 1xCRL290TF SET 1xCRL4942 1xCRL4937 SET 1xCRL2940 1xCRL4939 1xCRL2945 SET... -
Page 3: Wall Mounting
CRL690 SERIES SLIDING GLASS DOOR SYSTEM CRL690 - GLASS DEDUCTIONS AND SECTIONS WALL MOUNTING CEILING MOUNTING 2 7/16" 2 7/16" 1 1/4" 1 1/4" ± 3mm ± 3mm ± 1/8" ± 1/8" 10-12-14 10-12-14 3/8" - 1/2" - 9/16" 3/8" - 1/2" - 9/16"... - Page 4 CRL690 SERIES SLIDING GLASS DOOR SYSTEM CEILING MOUNT WITH FIXED GLASS CRL690 - GLASS DEDUCTIONS AND SECTIONS 3 3/16" 21mm - 13/16" 10mm - 3/8" 19mm - 3/4" 12mm - 1/2" 17mm - 11/16" 14mm - 9/16" ± 3mm ± 1/8"...
- Page 5 CRL690 SERIES SLIDING GLASS DOOR SYSTEM GLASS WALL MOUNT CRL4972- GLASS DEDUCTION AND SECTION 2 7/16" 32mm - 1 1/4" 10mm - 3/8" 30mm - 1 3/16" 12mm - 1/2" ± 3mm 28mm - 1/18" 14mm - 9/16" ± 1/8"...
- Page 6 CRL690 SERIES SLIDING GLASS DOOR SYSTEM FALSE CEILING MOUNT CRL690D - GLASS DEDUCTION AND SECTION 3 15/16" 3 1/8" 1 5/8" ± 3mm ± 1/8" 10-12-14 3/8" - 1/2" - 9/16" ● GLASS HEIGHT "A" - 1 7/8" - 47mm Min.
- Page 7 CRL690 SERIES SLIDING GLASS DOOR SYSTEM FALSE CEILING MOUNT WITH FIXED PANEL CRL6901D - GLASS DEDUCTION AND SECTION 3 15/16" 3 1/8" 1 5/8" → 21mm - 13/16" 10mm - 3/8" → 19mm - 3/4" 12mm - 1/2" → 17mm - 11/16"...
-
Page 8: Hardware Installation
CRL690 SERIES SLIDING GLASS DOOR SYSTEM CLAMPS ASSEMBLY HARDWARE INSTALLATION 1" 7 11/16" 7 11/16" 1" (x1) ANTI-DERRAILMENT SCREW (x6) CLAMP TIGHTEN SCREWS (x1) HEIGHT ADJUSTMENT SCREWS (x6) GLASS THICKNESS SETTING SCREWS ADJUST GLASS THICKNESS SCREWS Clamps distance Glass thickness 1/8"... - Page 9 CRL690 SERIES SLIDING GLASS DOOR SYSTEM WALL MOUNT / CEILING MOUNT HARDWARE INSTALLATION ● Cut track to length. Fix the track to the wall or ceiling using the marked holes, using screws DIN-7505 Ø5 / Ø 6 (NOT INCLUDED). ● Ensure Track is level.
- Page 10 CRL690 SERIES SLIDING GLASS DOOR SYSTEM DOOR MOUNT HARDWARE INSTALLATION INCLUDED ● Fix the 1st part of the bottom guide to the floor. ● Hang the glass panel on the track. HEIGHT ADJUSTMENT ● Fix the second part of the bottom guide and regulate heigh if necessary supplied in.
- Page 11 CRL690 SERIES SLIDING GLASS DOOR SYSTEM TRACK COVER ● Insert the track cover. ● Then fix the track assemblies using screws provided. ● Regulate the anti-derrailment screw in height. ● Clip trim cover profile END TRACK COVERS C.R. Laurence Co., Inc ꞏ 2503 E. Vernon Ave., Los Angeles, CA 90058 ꞏ 1.800.421.6144 ꞏ crlaurence.com...
- Page 12 CRL690 SERIES SLIDING GLASS DOOR SYSTEM GLASS WALL BRACKET CRL4972 MOUNT CRL4972 FLUSH MOUNT GLASS SUPPORT CUT PROFILE TO LENGTH AND DRILL PROFILE AS SHOWN IN PICTURES MARKED HOLES FOR DRILLING GLASS WALL BRACKET LOCTITE CRL4972 FOLLOW INSTALLATION STEPS AS PER CRL695 KIT PAGE 11.
- Page 13 CRL690 SERIES SLIDING GLASS DOOR SYSTEM CEILING MOUNT WITH FIXED GLASS HARDWARE INSTALLATION CEILING MOUNT 1/4" 13,2 1/2" Ø Ø SCREW DIN-7505 6 (NOT INCLUDED) MOUNT PROFILE FOR FIXED GLASS OPTIONAL PVC GASKET CODE CRL2944 12mm - 1/2" CRL2943 10mm - 3/8"...
- Page 14 CRL690 SERIES SLIDING GLASS DOOR SYSTEM HARDWARE INSTALLATION TWO-PIECE CHANNEL FOR FIXED GLASS 3/8" 3/8" 1/16" 3/16" Screws (Not included) TRIM PROFILES AND END COVERS MOUNT *CUT TO SIZE C.R. Laurence Co., Inc ꞏ 2503 E. Vernon Ave., Los Angeles, CA 90058 ꞏ 1.800.421.6144 ꞏ crlaurence.com...
- Page 15 CRL690 SERIES SLIDING GLASS DOOR SYSTEM FALSE CEILING MOUNT WITH FIXED GLASS HARDWARE INSTALLATION INSTALL TRACK FALSE CEILING DIFERENTS PROFILES MOUNT 23 5/8" 1" 1 3/4" TURN 90º AND FIX C.R. Laurence Co., Inc · 2503 E. Vernon Ave., Los Angeles, CA 90058 · 1.800.421.6144 · crlaurence.com...
