- Page 1 ASS DRILL I INSTALLATION INSTRUCTIONS crlaurence.com crlaurence.com CRL PATCH FITTING HYDRAULIC DOOR HINGE C. C.R. Laurence Co., Inc. • 2503 E. Vernon Ave., Los Angeles, CA 90058 • 1.800.421.6144 • crlaurence.com...
- Page 2 CRL Patch Fitting Hydraulic Door Hinge CAUTION For installations in particular environments or climates (ex. wet, add saline) consult sales office first 5/16 - 1/2 0°-80° Inch 14 °F 39" 220lb 122 °F Hydraulic hinge, including brake and closing speed adjustment and the end click of the leaf.
- Page 3 CRL Patch Fitting Hydraulic Door Hinge For standard applications place the plate to the TECHNICAL SPECIFICATIONS wall (1) 5/16" BASE PLATE 1-3/4" 1/2" 29/32 29/32" 39" Ø5/16" / Ø3/8" 220lb 14°F 1- 19/32" 122°F Place the base plate and mark the location of the hole Drill using a Ø...
- Page 4 CRL Patch Fitting Hydraulic Door Hinge Enter the door, possibly sloping for easier insertion. Use the gasket supplied to compensate for different thicknesses of Then place the notch in the hinge seat. glass (1) and tighten the 4 screws with (Ch3) key (2). See table.
