- Page 1 USER MANUAL ocularcharging.com.au sales@ocularcharging.com.au Version 2.0 1300 912 650...
-
Page 2: Table Of Contents
CONTENTS Warning ......................2 Product Features .....................3 Protect Functions.....................3 Applicable Scope....................3 Product Parameters..................4 Product Outline....................5 Dimension....................5 Working Environment .................5 Definition of LED Indicators................6 Cable Connection..................6 Operational Instructions ..................7 Operation Area ...................7 Operation Instructions ................7 Storage and Transportation................10 Storage and Transportation of Equipment ..........10 Maintenance of Charge.................11 Maintenance.....................11... -
Page 3: Warning
WARNING 1. When operating the charger, please make sure the charger sits in a well-ventilated area and avoid direct sunlight to prevent it from overheating. 2. Please make sure the input voltage from the 5-pin socket has a line to neutral voltage above 216V, or line to line voltage above 374V, as low input voltage may cause the charger to over draw current. -
Page 4: Product Features
PRODUCT FEATURES • Portable, compact and user friendly • High efficiency and reliable • Built-in 4G modem and antenna • OCPP 1.6J • 4.3 inch touch screen • Type B RCD, Short circuit, Undervoltage, Overtemperature, Overcurrent and Overvoltage protection • Working ambient temperature ranges from -25℃ to + 55℃ Please scan QR Code or CLICK HERE to watch this video on how to connect your charger and start charging! -
Page 5: Product Parameters
PRODUCT PARAMETERS Parameters Requirements EV charger Type Charger Capacity 20kW 30kW Model No. ENC-DCX020A ENC-DCX030A Portable Mounting 5 meters Power Cable Length 5 meters CCS2 Cable Length Three Phase AC Supply System AC400V +10%/-6% Nominal Input voltage 45-65Hz Input frequency -25 to 55°C Ambient Temperature Range 5 to 95%... -
Page 6: Product Outline
PRODUCT OUTLINE DIMENSION WORKING ENVIRONMENT Parameters Typical Unit Remarks Working Temp. Range ℃ Working Humidity Range RH % No condensation Altitude 2000 Atmospheric Pressure Cooling No Air cooling... -
Page 7: Definition Of Led Indicators
PRODUCT OUTLINE DEFINITION OF LED INDICATOR Place Function Description Remarks When the light is on, it indicates POWER indicator Yellow LED that the input AC voltage has been turned on. RUN indicator Green LED When the light is on, it indicates that the charger is charging. -
Page 8: Operational Instructions
OPERATIONAL INSTRUCTIONS CHARGER SCREEN The charger has a 480x272 resolution colour touch screen displays charging parameters and is used to operate the charger. CHARGING INSTRUCTIONS Power on for the charger, and then click on the screen to enter the main interface, please choose the gun and select charge-discharge power, as shown below. - Page 9 After choosing the charging connector/ charging power, click the confirmation button to initiate the EV charging process, as shown below. After initiating, the charge monitoring interface will be displayed. It will show various battery information and the information output by the charger. The charging can be stopped manually after user pressed stop button.
- Page 10 In case of fault and abnormal behavior during normal operation, please take a photo or video of the fault and contact Ocular Charging at your earliest convenience. Please do not dismantle or fix the charger by yourself. You can reach out to us at: Phone: 1 300 912 650 E-mail: help@ocularcharging.com.au...
-
Page 11: Storage And Transportation
STORAGE AND TRANSPORTATION STORAGE AND TRANSPORTATION OF EQUIPMENT During transportation, please make sure the charger is packed securely in a packing box, and the direction of loading and unloading should be marked. The charger should not be stored and transported upside down. Please avoid strong vibration and bump damage to equipment. -
Page 12: Maintenance Of Charge
MAINTENANCE OF CHARGER MAINTENANCE • Shading and rainproof measures should be taken for chargers. It is suggested to use the charger under shades and well-ventilated area to prevent it from overheating. • Check regularly whether all bolts on the charger are tightened. •...
