TrafficX Series Camera User Manual
Version: V1.0
TrafficX Series Camera User Manual
Date: 2024-03-13

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TrafficX Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Milesight TrafficX Series

Summary of Contents for Milesight TrafficX Series

  • Page 1 TrafficX Series Camera User Manual Version: V1.0 TrafficX Series Camera User Manual Date: 2024-03-13...

  • Page 2: Table Of Contents

    Chapter 1. Introduction......................4 1.1 Copyright Statement....................4 1.2 Safety Instruction...................... 4 1.3 Revision History......................5 Chapter 2. Product Introduction..................6 2.1 Product Overview......................6 2.2 Hardware Overview....................7 2.3 Related Documents....................8 Chapter 3. Configuration Flow....................9 Chapter 4. Installation......................11 Installation Angle Recommendations................11 Installation Guide......................13 Chapter 5.
  • Page 3 Contents DDNS........................54 Email........................55 FTP.........................57 VPN........................59 More........................60 Storage.......................... 61 Traffic..........................64 LPR.........................64 Violation Management................... 84 Smart Search......................89 Interface.........................92 Post..........................95 System...........................98 System Setting....................... 98 Security.........................100 Logs........................105 Maintenance......................106 Chapter 9. Services......................110...

  • Page 4: Chapter 1. Introduction

    We will readily improve or update the products or procedures described in the manual. This Manual explains how to use and manage Milesight TrafficX Camera. Please read this manual carefully before the operation and retain it for future reference.

  • Page 5: Revision History

    TrafficX Series Camera User Manual | 1 - Introduction | 5 • If the product does not work properly, please contact your dealer. Never attempt to disassemble the camera by yourself Cautions: Injury or equipment damage may be caused if any of these cautions are neglected.

  • Page 6: Chapter 2. Product Introduction

    24/7. With three robust data supports - 99% capture rate, 98% license plate recognition rate, and high recognizable speed up to 250km/h - the Milesight TrafficX camera provides reliable and accurate surveillance in various traffic scenarios.

  • Page 7: Hardware Overview

    TrafficX Series Camera User Manual | 2 - Product Introduction | 7 complex network cable connections. Built-in GPS facilitates precise location information collection and management, aiding in vehicle tracking, evidence gathering, and crime investigation. • High Compatibility The high compatibility sets this camera apart. Unlike some conventional cameras that only...

  • Page 8: Related Documents

    TrafficX Series Camera User Manual | 2 - Product Introduction | 8 2.3 Related Documents Table 2. Document Link Type TrafficX Camera https://resource.milesight.com/milesight/security/document/datasheet/ipc/traffic/trafficx/milesight- Data sheet trafficx-series-datasheet-en.pdf https://resource.milesight.com/milesight/security/document/user-manual/intelligent-traffic/ Quick Start Guide milesight-trafficx-series-quick-start-guide-en-v1.0.pdf Demo - Detailed https://www.youtube.com/watch?v=NK1sdRAg-bQ AI LPR Attributes...

  • Page 9: Chapter 3. Configuration Flow

    Chapter 3. Configuration Flow The configuration flow of TrafficX Camera is shown in the following figure. More configuration details is shown in the following table. Table 3. Description of flow...
  • Page 10 TrafficX Series Camera User Manual | 3 - Configuration Flow | 10 Configuration Description Reference Connect the network camera. You Setting the Camera over the LAN Network Connection can set the camera over the LAN or (page 25) dynamic IP connection.

  • Page 11: Chapter 4. Installation

    Chapter 4. Installation Installation Angle Recommendations 1. Overhead Installation - Top-mounted - Camera positioned above the lane. • Height: 4-9 m • Pitch angle: 9°-30° 2. Transversal Installation - Side-mounted - Device installed on a utility pole near the road. •...
  • Page 12 TrafficX Series Camera User Manual | 4 - Installation | 12 Note: 1. You can also use the Auxiliary Installation view in the Live Video interface after accessing the camera to determine the installation angle and field of view. For detailed...

  • Page 13: Installation Guide

    TrafficX Series Camera User Manual | 4 - Installation | 13 Installation Guide Note: 1. If the installation environment is column-style, it is recommended to purchase the A01 Pole Mount auxiliary bracket for use. 2. If necessary, loosen the screws on the rain cover to adjust it to the appropriate position.
  • Page 14 TrafficX Series Camera User Manual | 4 - Installation | 14 Note: Only cameras that include a 4G module require the insertion of a SIM card. Installation of the Pedestal Mount Step 2: Loosen the screws on both sides of the bracket as shown in the diagram, and the bracket will be able to rotate.
  • Page 15 TrafficX Series Camera User Manual | 4 - Installation | 15 Step 3: Place the assembled camera with the bracket onto the gantry. Use screws to secure the bracket to the gantry.
  • Page 16 TrafficX Series Camera User Manual | 4 - Installation | 16 Step 4: To adjust the camera angle, loosen the screws indicated on the bracket as shown in the diagram. The bracket can then be rotated for adjustment. Once it is properly adjusted,...
  • Page 17 TrafficX Series Camera User Manual | 4 - Installation | 17 Installation of the Wall Mount Bracket Step 2: Loosen the screws on both sides of the bracket as shown in the diagram, and the bracket will be able to rotate. Align the center hole of the wall mount bracket with the center hole on the bottom of the camera, insert the screws and tighten them to secure it.
  • Page 18 TrafficX Series Camera User Manual | 4 - Installation | 18...
  • Page 19 TrafficX Series Camera User Manual | 4 - Installation | 19 Step 3: According to the instructions on the perforation-assisted stickers, punch holes at the corresponding installation positions on the vertical plane. Note: 1. Inspect the condition of the installation surface to ensure sufficient support and strength, avoiding wall detachment or collapse.
  • Page 20 TrafficX Series Camera User Manual | 4 - Installation | 20 Step 5: To adjust the camera angle, loosen the screws indicated on the bracket as shown in the diagram. The bracket can then be rotated for adjustment. Once it is properly adjusted, tighten the screws to secure the bracket in place.
  • Page 21 TrafficX Series Camera User Manual | 4 - Installation | 21 Step 1: Unscrew the protective cover at the indicated position on the camera, remove the protective covers from the two tail wires, connect them to their respective positions, and tighten the threaded connectors.
  • Page 22 TrafficX Series Camera User Manual | 4 - Installation | 22 Color Function White Blue Orange Black ALARM OUT Gray ALARM OUT Table 5. The options of the multi-functional cables Color Function Pink RS485 A Green RS485 B Light Blue...
  • Page 23 TrafficX Series Camera User Manual | 4 - Installation | 23 Step 2: Remove the waterproof protective cover of the RJ45 interface and take out the rubber ring. Use an Ethernet cable to connect the following two in sequence. Step 3: Insert the Ethernet port into the interface and tighten the waterproof protective...
  • Page 24 TrafficX Series Camera User Manual | 4 - Installation | 24...

  • Page 25: Chapter 5. Network Connection

    Chapter 5. Network Connection Setting the Camera over the LAN Connecting the camera to a switch or a router is the most common connection method. The camera must be assigned an IP address that is compatible with its LAN. Connect the Camera to the PC Directly In this method, only the computer connected to the camera will be able to view the camera.
  • Page 26 TrafficX Series Camera User Manual | 5 - Network Connection | 26 Step3: On the router, set port forwarding. E.g. 80, 8000 and 554 ports. The steps for port forwarding vary depending on different routers. Please look up the router's user manual for assistance with port forwarding;...

  • Page 27: Chapter 6. Accessing The Camera

    Step2: Start Smart Tools, click the IPC Tools page, then enter the device information, such as IP address, MAC address, Status, Port number, Netmask, and Gateway, then all related Milesight network camera in the same network will be displayed. Details are shown as the figure below;...
  • Page 28 TrafficX Series Camera User Manual | 6 - Accessing the Camera | 28 Step3: Select a camera or multiple cameras according to the MAC addresses; Select single camera: Select multiple cameras:...
  • Page 29 TrafficX Series Camera User Manual | 6 - Accessing the Camera | 29 Step4: If the selected camera shows "Inactive" in the status bar, click "Activate" to set the password when using it for the first time. You can also set the security questions when activating the camera in case that you forget the password (You can reset the password by answering three security questions correctly).
  • Page 30 TrafficX Series Camera User Manual | 6 - Accessing the Camera | 30 Step6: By double clicking the selected camera or the browser of interested camera, you can access the camera via web browser directly. The Internet Explorer window will pop up.

  • Page 31: Assigning An Ip Address Via Browser

    Click “Advanced”, and then click “IP settings”--> “IP address”--> “Add”. In the pop-up window, enter an IP address that in the same segment with Milesight network camera ( e.g. 192.168.5.61, but please note that this IP address shall not conflict with the IP address on...
  • Page 32 TrafficX Series Camera User Manual | 6 - Accessing the Camera | 32 Step2: Start the browser. In the address bar, enter the default IP address of the camera:http://192.168.5.190; Step3: You need to set the password first when using it for the first time. And you can also set three security questions for your device after activation.

  • Page 33: Accessing From The Web Browser

    TrafficX Series Camera User Manual | 6 - Accessing the Camera | 33 • Password must be 8 to 32 characters long, contain at least one number and one letter. • You can click the “forget password” in login page to reset the password by answering three security questions when you forget the password, if you set the security questions in advance.

  • Page 34: Chapter 7. Live Video

    Chapter 7. Live Video Welcome to the Live Video interface! In order to make the most of the features in the Live Video interface, please carefully review the relevant instructions and annotations. Auxiliary Installation View When entering the interface for the first time, we recommend clicking on the Auxiliary Installation View icon located at the bottom right corner to access the Auxiliary Installation mode.
  • Page 35 TrafficX Series Camera User Manual | 7 - Live Video | 35 In Auxiliary Installation mode, there are two auxiliary tools available: 1. You can use the Crosshair to assist with adjusting the viewing angle. It’s better to zoom in to cover 2~3 lanes. (If camera is installed at roadside with some angles, it’s better to zoom in to cover 1~2 lanes.)
  • Page 36 TrafficX Series Camera User Manual | 7 - Live Video | 36 The live video is divided into three functional blocks: Module 1: Real-time video stream view captured by two cameras. Here are some quick operations: In this module, you can rapidly switch between the images of the two cameras by clicking the arrow on the thumbnail, or you can directly click anywhere within the video frame for switching.
  • Page 37 TrafficX Series Camera User Manual | 7 - Live Video | 37 Table 7. Description of the buttons Parameter Description Click to access the live view page. Live Video Click to access the configuration page. Settings Click to select system language.
  • Page 38 TrafficX Series Camera User Manual | 7 - Live Video | 38 Parameter Description Choose the options (Hide Detection Region/LPR/Violation Management) to hide/display detection region on the current video window. The optional streaming transmission methods are UDP/TCP/HTTP. The optional video modes are Least Delay/Balanced/Best Fluency.
  • Page 39 TrafficX Series Camera User Manual | 7 - Live Video | 39 Parameter Description LPR Logs Clicking on it will display detailed LPR Logs. On the left side, up to three images can be displayed in the following order: Violation Evidence, Vehicle Snapshot, and Full Snapshot.

  • Page 40: Chapter 8. Settings

    Chapter 8. Settings Media Video TrafficX camera is equipped with two sensors: the LPR Sensor and the Overview Sensor. The LPR sensor is designed specifically for capturing vehicle information, with a primary focus on license plate recognition. Conversely, the Overview sensor offers a broader perspective of the scene, providing a comprehensive view of the surrounding area.
  • Page 41 TrafficX Series Camera User Manual | 8 - Settings | 41 Table 9. Description of the buttons Parameters Function Introduction Click on the 'Enable Parity Flash' checkbox to activate Frame Parity Flashing, which enhances the capture of both reflective and non-reflective license plate information.
  • Page 42 TrafficX Series Camera User Manual | 8 - Settings | 42 Parameters Function Introduction The Overview Sensor supports enabling and configuring two Overview separate video streams, Stream 1 and Stream 2. Video Codec H.265/H.264/MJPEG are available. Options include 5M(2464*2056), 4M(2204*1840), 3M(1910*1592), 2M(1568 *1312), 1M(1104*928), 515P(784*656).

  • Page 43: Image

    TrafficX Series Camera User Manual | 8 - Settings | 43 Image In the 'Image' section, you can configure the general settings, OSD (On-Screen Display), and Privacy Mask for both LPR and Overview images. General In the general configuration, you can adjust the image settings for both LPR and Overview cameras separately for day and night modes.
  • Page 44 TrafficX Series Camera User Manual | 8 - Settings | 44 Parameters Function Introduction Two modes are available: Auto and Customized. Choosing different modes will result in some differences in the exposure parameters below. Auto Mode is suitable for scenes where the surrounding lighting conditions may vary, such as outdoor road scenes.
  • Page 45 TrafficX Series Camera User Manual | 8 - Settings | 45 Table 11. Description of the buttons Parameters Function Introduction When the Image Mode is set to Auto, you can manually adjust the target brightness Target Brightness value to meet your requirements.
  • Page 46 TrafficX Series Camera User Manual | 8 - Settings | 46 Table 12. Description of the buttons Parameters Function Introduction If you have enabled 'Enable Parity Flash' in the video settings, you can adjust the shutter time and gain level of the LPR Sensor here. Stream 1 represents the long exposure frame, while Stream 2 represents the short exposure frame.
  • Page 47 TrafficX Series Camera User Manual | 8 - Settings | 47 Table 13. Description of the buttons Parameters Function Introduction Power Line Frequency Set the power line frequency to 50Hz/60Hz. Click the checkbox to enable DIS (Digital Image Stabilization). Digital Image Stabilisation It is a feature that helps reduce unwanted camera movements or shakes in the captured video footage by electronically compensating for the motion.
  • Page 48 TrafficX Series Camera User Manual | 8 - Settings | 48 Parameters Function Introduction Select LPR and Overview video streams to configure OSD Image Source settings. Smallest/Small/Medium/Large/Largest/Auto are available for Font Size title and date. Font Color Enable to set different color for title and date.

  • Page 49: Network

    TrafficX Series Camera User Manual | 8 - Settings | 49 Table 15. Description of the buttons Parameters Function Introduction Image Source Select LPR and Overview video streams to configure Privacy Mask settings. Enable Check the check box to enable the Privacy Mask function.
  • Page 50 TrafficX Series Camera User Manual | 8 - Settings | 50 Table 16. Description of the buttons Parameters Function Introduction Type: Static Type and DHCP Type are optional for user to get IPv4 address automatically or use fixed IP address.

  • Page 51: Http

    TrafficX Series Camera User Manual | 8 - Settings | 51 HTTP Table 17. Description of the buttons Parameters Function Introduction Enable: Start or stop using HTTP. HTTP Port: Web GUI login port, the default is 80, the same with ONVIF port.
  • Page 52 TrafficX Series Camera User Manual | 8 - Settings | 52 Table 18. Description of the buttons Parameters Function Introduction RTSP Port The port of RTSP, the default is 554. There are Better Compatibility and Better Performance two options, if your camera’s RTP Packet image mess up, please switch this option.

  • Page 53: Upnp

    TrafficX Series Camera User Manual | 8 - Settings | 53 Stream Stream 2 rtsp://IP:RTSP Port/mcastlprstream2 (Enable Parity Flash) Stream 1 rtsp://IP:RTSP Port/mcastoverviewstream1 Overview Stream 2 rtsp://IP:RTSP Port/mcastoverviewstream2 Note: • DSCP refers to the Differentiated Service Code Point; and the DSCP value is used in the IP header to indicate the priority of the data.

  • Page 54: Ddns

    Note: For more details about how to set DDNS, please refer to https:// milesight.freshdesk.com/a/solutions/articles/69000643406. You can choose “ddns.milesight.com” as provider for DDNS. After enabling it, you can access the device via the URL “http://ddns.milesight.com/MAC address”. Table 22. Description of the buttons...

  • Page 55: Email

    Display DDNS running status. Save the configuration. Note: • Please do the Port Forwarding of HTTP Port and RTSP Port before you use Milesight DDNS. • Make sure that the internal and the external port number of RTSP are the same.
  • Page 56 TrafficX Series Camera User Manual | 8 - Settings | 56 Table 23. Description of the buttons Parameters Function Introduction Enable Check the checkbox to enable Email function. User Name The sender's name. It is usually the same as the account name.

  • Page 57: Ftp

    TrafficX Series Camera User Manual | 8 - Settings | 57 Parameters Function Introduction Alarm Snapshot File Name: Default(YYYY-MM-DD) /MM-DD-YYYY/ DD- MM-YYYY/ Add prefix/ Overwrite with the base file name/ Customize are available. Snapshot Settings Timing Snapshot File Name: Default(YYYY-MM-DD) /MM-DD-YYYY/ DD- MM-YYYY/ Add prefix/ Overwrite with the base file name/ Customize are available.
  • Page 58 TrafficX Series Camera User Manual | 8 - Settings | 58 Table 24. Description of the buttons Parameters Function Introduction FTP Type FTP and SFTP are optional. Server Address FTP/SFTP server address. The port of the FTP server. Generally it is 21.

  • Page 59: Vpn

    TrafficX Series Camera User Manual | 8 - Settings | 59 Parameters Function Introduction Multilevel If the storage path is more than two levels, enter Multilevel FTP Folder Name storage path here manually. Alarm Action Choose the default(YYYY-MM-DD) or customize the alarm action file File Name name.

  • Page 60: More

    TrafficX Series Camera User Manual | 8 - Settings | 60 Table 25. Description of the buttons Parameters Function Introduction You can choose between General VPN import or connect to Milesight VPN. For detailed instructions, please refer to the Support article: VPN Settings https://support.milesight.com/support/solutions/articles/69000829102-how-to-use-...

  • Page 61: Storage

    TrafficX Series Camera User Manual | 8 - Settings | 61 Table 26. Description of the buttons Parameters Function Introduction Enable: Enable/disable the Push Message function Push Event Type: You can click to choose the types of Events' message which will be pushed to M-sight Pro App as shown below: Push Message Settings Here you can choose whether to enable or disable camera ONVIF function.
  • Page 62 TrafficX Series Camera User Manual | 8 - Settings | 62 Note: Before you start: • To configure record settings, please make sure that you have the network storage device within the network or the SD card inserted in your camera.
  • Page 63 TrafficX Series Camera User Manual | 8 - Settings | 63 Parameters Function Introduction The network disk should be available within the network and properly configured to store the recorded files, etc. NAS (Network-Attached Storage), connecting the storage devices to the existing network, provides data and files services.

  • Page 64: Traffic

    TrafficX Series Camera User Manual | 8 - Settings | 64 Table 28. Description of the buttons Parameters Function Introduction Record video 1~10 seconds prior to triggering an alarm to capture pre-alarm Pre-record footage. Select the recording source for video capture.
  • Page 65 TrafficX Series Camera User Manual | 8 - Settings | 65 Table 29. Description of the buttons Parameters Function Introduction Enable LPR Enable/disable the LPR detection function. Country/ Region Select country/ region to detect the license plate. The configuration steps for LPR recognition and other general settings are as follows: Step1: Click the checkbox "Enable LPR"...
  • Page 66 TrafficX Series Camera User Manual | 8 - Settings | 66 Note: The detection area can be drawn as an irregular quadrilateral, which greatly enhances the scene adaptability.
  • Page 67 TrafficX Series Camera User Manual | 8 - Settings | 67 Table 30. Description of the buttons Parameters Function Introduction Draw on the screen to select the desired area of interest, then click the "Add" button to add that area. You can add up to four recognition areas, but for optimal performance, we recommend using 2-3 areas.
  • Page 68 TrafficX Series Camera User Manual | 8 - Settings | 68 Parameters Function Introduction Check Plate Color, Vehicle Type, Vehicle Color, Vehicle Brand, Detection Region, Direction, Country/Region, orAll to enable Attributes Identification, it will display the corresponding information on the Smart Search interface.
  • Page 69 TrafficX Series Camera User Manual | 8 - Settings | 69 Table 32. Description of the buttons Parameters Function Introduction Copy the schedule area to another date. Select all schedule. Clear all schedule. Advanced In the Advanced interface, you can configure Snapshot-related settings, including the display of Snapshot OSD and the format of Snapshot File Name.
  • Page 70 TrafficX Series Camera User Manual | 8 - Settings | 70 Table 33. Description of the buttons Parameters Function Introduction Smallest/Small/Medium/Large/Largest are available for OSD information. Font Size Note: Snapshot OSD font size and Image OSD font size are corresponded.
  • Page 71 TrafficX Series Camera User Manual | 8 - Settings | 71 Parameters Function Introduction Customize the OSD content. You can set OSD Information as shown below: OSD Information When license plate is recognized and the alarm is triggered, the snapshot...
  • Page 72 TrafficX Series Camera User Manual | 8 - Settings | 72 Table 34. Description of the buttons Parameters Function Introduction “-”, “_” and Space are available for File Name Separator format. Separator The default separator is “-”. You can customize the snapshot file name according to items chosen.
  • Page 73 TrafficX Series Camera User Manual | 8 - Settings | 73 separator to connect these items name. Also, the content of Position and Device ID items can be customized. When you check all items, the function interface will show as below: Note: You need to check at least one item.
  • Page 74 TrafficX Series Camera User Manual | 8 - Settings | 74 Once license plate is recognized, and the snapshot will be uploaded via FTP or Email or stored on your local LPR Picture File Path. Then, You can see the snapshot file name which...
  • Page 75 TrafficX Series Camera User Manual | 8 - Settings | 75 License plate snapshot Recognized successfully License plate snapshot Recognized failed Note: • If the item checked is not recognized successfully, then the item will be displayed with the specific symbol “#”.
  • Page 76 TrafficX Series Camera User Manual | 8 - Settings | 76 Table 35. Description of the buttons Parameters Function Introduction Click the Add button to add license plates as either Black or White type to the license plate management. You can select the effective time as 'always' or a specific time period.
  • Page 77 TrafficX Series Camera User Manual | 8 - Settings | 77 Parameters Function Introduction Select Plate Type or directly enter the license plate number, click the “Search” button, the corresponding license plate will be displayed in the list below. List Search Click the "Export List"...
  • Page 78 TrafficX Series Camera User Manual | 8 - Settings | 78 Parameters Function Introduction Click the "Edit" button to customize a rule. And then set the license plate to Schedule Mode and choose a custom schedule Schedule Rules rule that can configure the license plate as Black List or White List at different times.
  • Page 79 TrafficX Series Camera User Manual | 8 - Settings | 79 List Event In the List Event section, you can select the schedule and alarm action for configuring List Events. Table 36. Description of the buttons Parameters Function Introduction List Type Select the type of list you want to configure: Black List/White List/Visitor.
  • Page 80 TrafficX Series Camera User Manual | 8 - Settings | 80 Table 37. Description of the buttons Parameters Function Introduction Copy the schedule area to another date. Select all schedule. Clear all schedule. [Alarm Action]...
  • Page 81 TrafficX Series Camera User Manual | 8 - Settings | 81 Table 38. Description of the buttons Parameters Function Introduction Duration: Selected the duration time of alarm. 5s/10s/15s/20s/25s/30s are available. Record Linkage: Save alarm recording files into SD Card or NAS or Upload the recording files via FTP.
  • Page 82 TrafficX Series Camera User Manual | 8 - Settings | 82 [Alarm Trigger] You can configure multiple triggered attributes, including Plate Color, Vehicle Type, Vehicle Color, and Detection Region. The following are the available specific options. Table 39. Description of the buttons...
  • Page 83 TrafficX Series Camera User Manual | 8 - Settings | 83 Table 40. Description of the buttons Parameters Function Introduction Copy the schedule area to another date. Select all schedule. Clear all schedule. [Alarm Action]...

  • Page 84: Violation Management

    TrafficX Series Camera User Manual | 8 - Settings | 84 Table 41. Description of the buttons Parameters Function Introduction Duration: Selected the duration time of alarm. 5s/10s/15s/20s/25s/30s are available. Record Linkage: Save alarm recording files into SD Card or NAS or Upload the recording files via FTP.
  • Page 85 TrafficX Series Camera User Manual | 8 - Settings | 85 [Detection Settings] Step1: Set Detection Region. The detection region in Violation Management is synchronized with the Detection Region settings in LPR - General (page 64).
  • Page 86 TrafficX Series Camera User Manual | 8 - Settings | 86 Step2: Define the lane direction and set trigger line. For all regions you have configured, please specify the Lane Direction as Straight Lane/Left-turn Lane/Right-turn Lane. Click on the selection box of Detection Line, and the corresponding Detection Line will appear on the left-side screen.
  • Page 87 TrafficX Series Camera User Manual | 8 - Settings | 87 Parameters Function Introduction Click on the checkbox to enable the detection of vehicles without license No Plates plate. Trigger Condition: Based on actual traffic requirements, you can select different Trigger Conditions, including In the Lane, Vehicle Front Crossed the Stop Line, Vehicle Tail Crossed the Stop Line, and Reached the Trigger Line.
  • Page 88 TrafficX Series Camera User Manual | 8 - Settings | 88 Parameters Function Introduction Video Analysis: It can recognize the traffic is ON or OFF based on the image analysis. # Click “Set” button to enter the Area Settings interface.

  • Page 89: Smart Search

    TrafficX Series Camera User Manual | 8 - Settings | 89 Table 43. Description of the buttons Parameters Function Introduction Duration: Selected the duration time of alarm. 5s/10s/15s/20s/25s/30s are available. Record Linkage: Save alarm recording files into SD Card or NAS or Upload the recording files via FTP.
  • Page 90 TrafficX Series Camera User Manual | 8 - Settings | 90 To access more filtering options, click the "More" button to expand. Step1: You can select Event Type/Plate Type/Vehicle Attributes/Direction, or directly enter the license plate number, then choose the start time and end time. Simply click the "Search"...
  • Page 91 TrafficX Series Camera User Manual | 8 - Settings | 91 Step3: Click the "Export" or “Export All” button to export the desired files in the current list to a local folder. Step4: Click the "Auto Export" button to automatically export the logs to FTP, Email or...

  • Page 92: Interface

    TrafficX Series Camera User Manual | 8 - Settings | 92 Interface In the Interface settings, you can configure the interfaces and their related settings, including External Input, External Output, and RS485. External Input: This setting allows you to configure the external input interface, which is used to receive signals or data from external devices.
  • Page 93 TrafficX Series Camera User Manual | 8 - Settings | 93 Table 44. Description of the buttons Parameters Function Introduction Input Note: Four input interface numbers: Please review the labels affixed to the Multi-functional Interface Cable before configuring External Input. The labels indicate the colors of the four Input interfaces as shown above.
  • Page 94 TrafficX Series Camera User Manual | 8 - Settings | 94 RS485: You can view and configure the RS485-related information here, such as Baudrate, Data bit, Stop bit, and Parity. Table 45. Description of the buttons Parameters Function Introduction The transmission rate can be configured in bits per second. Available options include Baudrate 2400, 4800, 9600, 19200, and 38400.

  • Page 95: Post

    TrafficX Series Camera User Manual | 8 - Settings | 95 Parameters Function Introduction The data bit defines the number of bits used to transmit data in each data byte. The Data Bit data bit is set to 8, which allows each byte to transmit 8 bits of information.
  • Page 96 TrafficX Series Camera User Manual | 8 - Settings | 96 Parameters Function Introduction Choose the events you want to push, including Regular, List Event, Attributes Event, and Violation Event. When the Select Events selected event is triggered, information will be pushed to third-party devices or software compatible with Milesight.
  • Page 97 TrafficX Series Camera User Manual | 8 - Settings | 97 Table 47. Description of the buttons Parameters Function Introduction Select the information you want to push. The information format can be directly viewed above and copied. Note: Data License Plate Coordinates represent the coordinates of the license plate at the time of event generation.

  • Page 98: System

    TrafficX Series Camera User Manual | 8 - Settings | 98 Parameters Function Introduction Select the snapshots you want to push: • License plate: Snapshot of the license plate Snapshot • Vehicle snapshot: Snapshot of the vehicle • Full snapshot: Complete snapshot •...
  • Page 99 TrafficX Series Camera User Manual | 8 - Settings | 99 Parameters Function Introduction Product Model The product model of the camera. Hardware Version The hardware version of the camera. Software Version The software version of the camera can be upgraded.

  • Page 100: Security

    TrafficX Series Camera User Manual | 8 - Settings | 100 Parameters Function Introduction Current System Time Current date&time of the system. Time Zone: Choose a time zone for your location. Daylight Saving time: Enable the daylight saving time. Synchronize Mode: GPS, NTP server, Manual and Synchronize with computer time are optional.
  • Page 101 TrafficX Series Camera User Manual | 8 - Settings | 101 Parameters Function Introduction Allow anonymous viewing: Check the checkbox to enable visit from whom doesn’t Manage Privilege have account of the device. Click “Edit” button to set three security questions for your camera. In case that you forget the password, you can click “Forget Password”...
  • Page 102 TrafficX Series Camera User Manual | 8 - Settings | 102 Parameters Function Introduction Click “Add” button, it will display Account Management page. You can add an account to the camera by entering Admin Password, User Level, User Name, New Password, Confirm, and edit user privilege by clicking .
  • Page 103 TrafficX Series Camera User Manual | 8 - Settings | 103 Parameters Function Introduction Refresh Click to get latest status of user accessing to camera. Record serial number of user logging in camera. Note: • There are at most 30 records shown at the list.
  • Page 104 TrafficX Series Camera User Manual | 8 - Settings | 104 Parameters Function Introduction Rule: Single, Network and Range are available. IP address: Input the address to get the access to the device. Delete all the access list. Edit the selected IP on access list.

  • Page 105: Logs

    TrafficX Series Camera User Manual | 8 - Settings | 105 User can view some open source software licenses about the camera by clicking the View Licenses button. Logs The logs contain the information about the time and IP that has accessed the camera through web.

  • Page 106: Maintenance

    TrafficX Series Camera User Manual | 8 - Settings | 106 Parameters Function Introduction There are five main log types: All Type, Event, Operation, Information, Main Type Exception and Smart. On the premise that main type has been selected, select the sub type to Sub Type narrow the range of logs.
  • Page 107 TrafficX Series Camera User Manual | 8 - Settings | 107 Parameters Function Introduction Software Version: The software version of the camera. Local Upgrade: Click the “Browse” button and select the upgrading file, then click the “Upgrade” button to upgrade. After the system reboots successfully, the update is done.
  • Page 108 TrafficX Series Camera User Manual | 8 - Settings | 108 Parameters Function Introduction Reset: Click “Reset” button to reset the camera to factory default settings. Keep the IP Configuration: Check this option to keep the IP configuration when resetting the camera.
  • Page 109 TrafficX Series Camera User Manual | 8 - Settings | 109 Set the date and time to enable Auto Reboot function, the camera will reboot automatically according to the customized time in case that camera overload after running a long time.

  • Page 110: Chapter 9. Services

    Chapter 9. Services Milesight provides customers with timely and comprehensive technical support services. End-users can contact your local dealer to obtain technical support. Distributors and resellers can contact directly with Milesight for technical support. Technical Support Mailbox: support@milesight.com Web: http://www.milesight.com Online Problem Submission System: http://www.milesight.com/service/feedback.asp...

This manual is also suitable for:

Ts5510-ghTs5511-gh
