Maximize signal strength and quality

Adjust the antenna placement to
•
maximize the number of green signal
strength indicator LEDs. Optionally, signal
strength and quality can be viewed in the
OptConnect Summit web portal.
Physically connect your equipment
Ethernet - if using Ethernet
•
to connect your equipment,
route Ethernet cord(s) from
your desired equipment to
one of the LAN ports on the
max aware device.
Ethernet WAN - if using
•
Ethernet WAN to connect to
an on-site router/Internet
Service Provider (ISP), route
the Ethernet cord from ISP
router to WAN Ethernet port
on max aware device.
Wi-Fi - To connect your
•
equipment to the max aware
device via Wi-Fi, you may
need to verify/set up Wi-
Fi settings in the Summit
web portal. See "Wi-Fi
Connectivity" section on page
7 for further information.
CELL
WAN
Failover
Wi-Fi
7
