Zoeller 2000 Series Installation Instructions

Product information presented
here re fl ects con di tions at time
of publication. Consult factory
re gard ing dis crep an cies or
in con sis ten cies.
INSTALLATION INSTRUCTIONS
2000 SERIES HIGH TEMPERATURE INTERMITTENT PUMPS
SERIES
2057 Series
2098 Series
2137 Series
2282 Series
PREINSTALLATION CHECKLIST - ALL IN STAL LA TIONS
1. Inspect your pump. Occasionally, products are damaged during shipment. If the unit is damaged, contact your dealer before using. DO NOT remove the test plugs in the cover nor the motor housing.
2. Carefully read the literature provided to familiarize yourself with specifi c details regarding in stal la tion and use. These materials should be retained for future reference.
1. Make sure there is a properly grounded re cep ta cle avail able. All pumps are furnished
with provisions for proper grounding to protect you against the possibility of electrical shock.
(SEE WARN ING BELOW)
2. Make certain that the receptacle is within the reach of the pump's pow er supply cord.
DO NOT USE AN EXTENSION CORD. Extension cords that are too long or too light do not deliver
suffi cient voltage to the pump motor. But, more important, they could present a safety haz ard if the
insulation were to become damaged or the con nec tion end were to fall into the sump.
3. Make sure the pump electrical supply circuit is equipped with fuses or circuit
breakers of proper capacity. A separate branch circuit is rec om mended, sized ac cord ing to the
"National Elec tri cal Code" for the current shown on the pump nameplate.
4. Testing for ground. As a safety measure, each electrical outlet should be checked
for ground using an Underwriters Laboratory Listed circuit analyzer which will indicate if the power,
neutral and ground wires are correctly connected to your outlet. If they are not, call a qualifi ed
licensed electrician.
5. For Added Safety. Pumping and other equipment with a 3-prong grounded plug must
be connected to a 3-prong grounded receptacle. For added safety the receptacle may be protected
with a ground-fault circuit interrupter. When a pump needs to be connected in a watertight junction
box, the plug can be removed and spliced to the supply cable with proper grounding. For added
safety this circuit may be protected by a ground-fault circuit in ter rupt er. The complete in stal la tion
must comply with the National Electrical Code and all applicable local codes and ordinances.
6. FOR YOUR PROTECTION, ALWAYS DISCONNECT PUMP FROM ITS POW ER SOURCE BE FORE
HANDLING. Single phase pumps are sup plied with a 3-prong ground ed plug to help protect you
against the possibility of electrical shock. DO NOT UNDER ANY CIRCUM STANCES RE MOVE THE
GROUND PIN. The 3-prong plug must be inserted into a mating 3-prong grounded receptacle.
If the in stal la tion does not have such a receptacle, it must be changed to the prop er type, wired
and ground ed in ac cor dance with the National Elec tri cal Code and all applicable local codes and
or di nanc es. Three phase pumps require motor starting devices with motor overload pro tec tion. See
FM0514 for simplex in stal la tions or FM0486 for duplex in stal la tions. Pumps must be in stalled in
ac cor dance with the National Electrical Code and all ap pli cable local codes and ordinances. Pumps
are not to be installed in locations clas si fi ed as hazardous in accordance with National Electrical
Code, ANSI/NFPA 70.
7. "Risk of electrical shock" Do not remove power supply cord and strain relief or connect conduit
directly to the pump.
8. Installation and servicing of electrical circuits and hardware should be performed by a qualifi ed
li censed electrician.
9. Pump installation and servicing should be performed by a qualifi ed person.
10. Risk of electric shock - These pumps have not been investigated for use in swimming pool areas.
11. According to the state of California (Prop 65), this product contains chemicals known to the state
of California to cause cancer and birth defects or other reproductive harm.
MAIL TO: P.O. BOX 16347 • Louisville, KY 40256-0347
SHIP TO: 3649 Cane Run Road • Louisville, KY 40211-1961
(502) 778-2731 • 1 (800) 928-PUMP • FAX (502) 774-3624
AVAILABLE MODELS
H.P. DISCHARGE
1½"
1
3
½ 1½"
½ 1½"
½ 2" or 3"
SEE BELOW FOR
LIST OF WARNINGS
© Copyright 2008 Zoeller Co. All rights reserved.
SOLIDS PH
1/2" 1
1/2" 1
5/8" 1
2" 1
1. Check to be certain your power source is capable of han dling the volt age re quire ments of the motor,
as indicated on the pump name plate.
2. Check valves used in High Temperature service must be all metal swing type check valves.
3. Dewatering and effl uent sump pumps are not designed to han dle raw sew age.
4. Maximum intermittent operating temperature for high tem per a ture pumps must not ex ceed 200°F
- 93°C.
5. The installation of automatic pumps with variable level fl oat switch es or nonautomatic pumps using
auxiliary variable level fl oat switches is the re spon si bil i ty of the in stall ing party and care should be
tak en that the tethered fl oat switch will not hang up on the pump apparatus or pit peculiarities and
is secured so that the pump will shut off. It is recommended to use rigid piping and fi ttings and the
pit be 18" or larger in diameter.
6. Information - vent hole purpose. It is necessary that all sub mers ible sump, effl uent, and sewage
pumps capable of handling various sizes of solid waste be of the bottom intake design to reduce
clog ging and seal failures. If a check valve is incorporated in the installation, a vent hole (approx.
3/16") must be drilled in the discharge pipe below the check valve and pit cover to purge the unit
of trapped air. Trapped air is caused by agitation and/or a dry basin. Vent hole should be checked
periodically for clogging. The 50 or 90 Series pumps have a vent lo cated in the pump housing
opposite the fl oat, ad ja cent to a housing lug, but an additional vent hole is recommended. The
vent hole on some applications may cause too much turbulence. You may not want to drill one.
If you choose not to drill a vent hole, be sure the pump case and impeller is covered with liquid
before connecting the pipe to the check valve and no inlet carries air to the pump intake. NOTE:
THE HOLE MUST ALSO BE BELOW THE BASIN COVER AND CLEANED PERIODICALLY. Water
stream will be visible from this hole during pump run periods.
7. Pump should be checked frequently for debris and/or build up which may interfere with the fl oat "on"
or "off" position. Repair and service should be performed by Zoeller Pump Company Authorized
Service Station only.
8. Do not operate a pump in an ap pli ca tion where the Total Dynamic Head is less than the minimum
Total Dynamic Head listed on the Pump Performance Curves.
REFER TO WARRANTY ON PAGE 2.
SECTION: 6.10.054
Supersedes
visit our web site:
www.zoeller.com
MATERIAL
Cast Iron/Stainless Steel
Cast Iron/Stain less Steel
Cast Iron/Stain less Steel
Cast Iron/Stainless Steel
SEE BELOW FOR
LIST OF CAUTIONS
FM1923
0908
1204
