Furuno FAR-2218 Installation Manual

Furuno FAR-2218 Installation Manual

Marine radar
Hide thumbs Also See for FAR-2218:
Table of Contents

Advertisement

Quick Links

Model
FAR-2318/2328(-NXT)/FAR-2238S(-BB/-NXT/-NXT-BB)/
FAR-2338S(-NXT)/2328W/2338SW/2258/2268DS
SAFETY INSTRUCTIONS ........................i
SYSTEM CONFIGURATION ..................iv
EQUIPMENT LISTS..............................xvi
1. INSTALLATION...............................1-1
1.3 Monitor Unit.......................................1-23
1.4 Control Unit .......................................1-23
1.5 Power Supply Unit ............................1-30
1.6 Processor Unit ..................................1-31
1.7 Transceiver Unit................................1-32
1.8 Intelligent Hub (option)......................1-33
1.9 Switching Hub (option)......................1-34
1.10 Junction Box (option) ........................1-34
2. WIRING............................................2-1
2.1 Overview .............................................2-1
2.6 Power Supply Unit ............................2-46
2.7 Transceiver Unit................................2-54
2.8 Processor Unit ..................................2-60
2.9 Monitor Unit.......................................2-66
2.10 LAN Signal Converter .......................2-68
2.11 Junction Box (option) ........................2-71
2.12 Intelligent HUB (option).....................2-72
2.13 VDR Connection ...............................2-72
3. ADJUSTMENTS ..............................3-1
3.1 Radar Installation Menu ......................3-3
3.2 How to Align the Heading ...................3-3
Installation Manual
FAR-2218(-BB)/2228(-BB/-NXT/-NXT-BB)/
FAR-2018-MARK-2/2028-MARK-2
3.5 Other Settings .....................................3-5
3.6 How to Control Charts.......................3-27
4. INPUT/OUTPUT DATA ...................4-1
4.1 Processor Unit ....................................4-1
4.2 Sub Monitor.........................................4-3
APPX. 1 JIS CABLE GUIDE............AP-1
APPX. 2 DIGITAL INTERFACE.......AP-2
APPX. 3 ALERT LIST ....................AP-15
PACKING LIST(S)............................... A-1
OUTLINE DRAWING(S)...................... D-1
INTERCONNECTION DIAGRAM(S) ... S-1
MARINE RADAR

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FAR-2218 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Furuno FAR-2218

Summary of Contents for Furuno FAR-2218

  • Page 1: Table Of Contents

    Installation Manual MARINE RADAR FAR-2218(-BB)/2228(-BB/-NXT/-NXT-BB)/ Model FAR-2318/2328(-NXT)/FAR-2238S(-BB/-NXT/-NXT-BB)/ FAR-2338S(-NXT)/2328W/2338SW/2258/2268DS FAR-2018-MARK-2/2028-MARK-2 SAFETY INSTRUCTIONS ......i 3.3 How to Adjust the Sweep Timing ..3-4 3.4 How to Suppress Main Bang ....3-5 SYSTEM CONFIGURATION ....iv 3.5 Other Settings ........3-5 EQUIPMENT LISTS......xvi 3.6 How to Control Charts.......3-27 1.

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS...
  • Page 4 SAFETY INSTRUCTIONS...
  • Page 5 SAFETY INSTRUCTIONS...

  • Page 6: System Configuration

    SYSTEM CONFIGURATION Standard connection Basic configuration is shown with solid line. For footnotes, see "Notes" on page xi. X-band (TR-UP, CF Antenna), 12 kW/25 kW/600 W (or 500 W)
  • Page 7 SYSTEM CONFIGURATION X-band (TR-UP, AF Antenna), 12 kW/25 kW...
  • Page 8 SYSTEM CONFIGURATION X-band (TR-UP), 50 kW...
  • Page 9 SYSTEM CONFIGURATION S-band (TR-UP), 30 kW/250W)
  • Page 10 SYSTEM CONFIGURATION S-band (TR-UP), 60 kW viii...
  • Page 11 SYSTEM CONFIGURATION X-band (TR-DOWN)
  • Page 12 SYSTEM CONFIGURATION S-band (TR-DOWN)
  • Page 13 • CAT 2 and CAT 2H: effective diameter of 250 mm or higher • CAT 3: effective diameter of 180 mm or higher Category Manufacturer Model Viewing distance CAT 1 and FURUNO MU-231 1.20 m CAT 1H MU-270W 1.02 m Hatteland Technology JH 23T14 FUD 1.20 m...
  • Page 14 7) Some antenna configurations do not have an in-built Performance Monitor. This type of anten- na is not usable for IMO-type radars. 8) For connecting non-FURUNO ECDIS only. For connection of radars or plotters, the connection must be done at the radar antenna (or the transceiver unit) via the sub monitor connector.
  • Page 15 SYSTEM CONFIGURATION Radar Component Combinations TRANSCEIVER Band RADAR MODEL ANTENNA UNIT Remarks UP/DN UNIT FAR-2218(-BB), RTR-105 FAR-2318 XN12CF-RSB128 FAR-2228(-BB), RTR-106 XN20CF-RSB128 FAR-2328 XN24CF-RSB128 FAR-2228-NXT(-BB), RTR-123 TR-UP FAR-2328-NXT FAR-2018-MARK-2 RTR-131 XN12AF-RSB146 XN20AF-RSB146 FAR-2028-MARK-2 RTR-132 XN24AF-RSB146 XN24AF-RSB139 NOT available on FAR-2258 RTR-122...
  • Page 16 SYSTEM CONFIGURATION Note 3: If the software with version 01.**/03.** is changed to the software with version 50.**, the RP board in the processor unit is required and the software update of the RP board required as well. The table below shows those functions which are limited to a specific radar type (Available: , Not available: –).
  • Page 17 CAT 1 FAR-2318, FAR-2328, FAR-2328W, FAR-2338S, 24 rpm FAR-2338SW, FAR-2338-NXT CAT 1H Same models as above 42 rpm CAT 2 FAR-2218, FAR-2228, FAR-2238S, FAR-2238S-NXT 24 rpm CAT 2H Same models as above 42 rpm CAT 3 FAR-2218, FAR-2228, FAR-2238S, 24 rpm...

  • Page 18: Equipment Lists

    EQUIPMENT LISTS Standard supply < X-band TR-UP (CF Antenna)> • Magnetron radar: FAR-2218(-BB)/2228(-BB)/2318/2328 • Solid state radar: FAR-2228-NXT(-BB)/2328-NXT Name Type Code No. Remarks Antenna XN12CF-RSB128-105 4 ft, 12 kW w/ PM-32A* Unit XN12CF-RSB128-106 4 ft, 25 kW (Magnetron XN20CF-RSB128-105 6.5 ft, 12 kW...
  • Page 19 EQUIPMENT LISTS Name Type Code No. Remarks Spare SP03-17641 001-249-740 Fuse for RPU-025 of AC power Parts • FGBO-A 250V 7A PBF, 2 pcs. (000-178-084-10) SP03-17681 001-558-560 Fuse for RPU-025 of DC power • FGBO 125V 20A, 2 pcs. (000-155-780-10) SP03-19701 001-531-630 Fuse for Antenna Unit w/de-icer...
  • Page 20 EQUIPMENT LISTS Name Type Code No. Remarks Spare SP03-17641 001-249-740 Fuse for RPU-025 of AC power Parts • FGBO-A 250V 7A PBF, 2 pcs. (000-178-084-10) SP03-17681 001-558-560 Fuse for RPU-025 of DC power • FGBO 125V 20A, 2 pcs. (000-155-780-10) SP03-19701 001-531-630 Fuse for RSB-146 w/de-icer...
  • Page 21 EQUIPMENT LISTS Name Type Code No. Remarks Accessories FP03-09880 001-574-480 For RCU-014 FP03-09860 001-419-140 For RCU-015/016 Spare SP03-17641 001-249-740 Fuse for RPU-025 Parts • FGBO-A 250V 7A PBF, 2 pcs. (000-178-084-10) SP03-15501 008-572-730 For PSU, 100 VAC • FGBO-A 250V 5A PBF, 2 pcs.
  • Page 22 EQUIPMENT LISTS Name Type Code No. Remarks Accessories FP03-09880 001-574-480 For RCU-014 FP03-09860 001-419-140 For RCU-015/016 Spare SP03-17641 001-249-740 Fuse for RPU-025 of 24 rpm radar Parts • FGBO-A 250V 7A PBF, 2 pcs. (000-178-084-10) SP03-17651 001-249-750 Fuse for RPU-025 of 42 rpm radar •...
  • Page 23 EQUIPMENT LISTS Name Type Code No. Remarks Spare Parts SP03-17641 001-249-740 Fuse for RPU-025 of 24 rpm radar • FGBO-A 250V 7A PBF, 2 pcs. (000-178-084-10) SP03-15501 008-572-730 For PSU, 100 VAC • FGBO-A 250V 5A PBF, 2 pcs. (000-155-840-10) SP03-15502 008-572-740 For PSU, 220 VAC...
  • Page 24 EQUIPMENT LISTS < S-band TR-DOWN > • Magnetron radar: FAR-2338SW Name Type Code No. Remarks Antenna Unit SN36CF-RSB131 12 ft, w/PM-52A* Transceiver Unit RTR-109 Processor RPU-025 Unit Monitor Unit MU-231 23.1-inch monitor MU-270W 27-inch monitor Control Unit RCU-014 Standard type RCU-015 Trackball type Installation...
  • Page 25 EQUIPMENT LISTS Name Type Code No. Qty. Remarks Spare Parts SP03-19200 000-034-305 For X-band radar, S-band (24rpm) radar, without HUBs. SP03-19210 000-034-306 For S-band (42rpm) radar, without HUBs. SP03-19220 000-034-307 For X-band radar, S-band (24rpm) radar, w/ HUB-100. SP03-19230 000-034-308 For S-band (42rpm) radar, w/ HUB-100.
  • Page 26 EQUIPMENT LISTS Name Type Code No. Remarks Monitor Unit MU-190 19-inch monitor MU-231 23.1- inch monitor MU-270W 27-inch wide monitor HD19T22-FUD-MA4- 19-inch monitor FAGA HD19T22-FUD-MA1- 19-inch monitor FAGA Hood Assembly OP26-6 001-080-930 For MU-190/190HD OP26-16 001-116-740-01 For MU-231 Hood Assembly OP26-32 001-439-090 For MU-270W...
  • Page 27 EQUIPMENT LISTS Name Type Code No. Remarks LAN Cable MOD-Z072-020+ 001-167-880-10 For LAN cable between RPU-025 Assembly and HUB-100, 2 m MOD-Z072-050+ 001-167-890-10 For LAN cable between RPU-025 and HUB-100, 5 m Cable Assy. DSUB9P-X2-A-L5M 001-252-580 Brilliance control cable for Hat- teland monitor, 5 m DSUB9P-X2-A-L10M 001-252-590...
  • Page 28 EQUIPMENT LISTS Name Type Code No. Remarks Cable Extension OP03-251-1 001-496-600 For RSB-133 OP03-251-2 001-496-610 For RSB-129 OP03-251-3 001-496-620 For RSB-128, magnetron radar OP03-251-4 001-568-950 For RSB-128, solid state radar OP03-251-5 001-631-860 For RSB-146 PM Installation Kit OP03-254-1 001-505-240 For RSB-133 OP03-254-2 001-505-250 For RSB-129...
  • Page 29 EQUIPMENT LISTS Name Type Code No. Remarks Magnetron Re- J32-02110-* 000-199-612-** Japanese, placement Instruc- for RSB-128/129/130/131/133 tion Manual E32-02110-* 000-199-611-** English, for RSB-128/129/130/131/133 Wave Analyzer WV-100 001-562-500 WV-100ST 001-562-510 w/ SEA-TRIAL mode SSD Replace- OP03-263 001-576-900 ment Kit PM Modification OP03-265 001-585-810 Lubrication Kit...
  • Page 30 EQUIPMENT LISTS This page is intentionally left blank. xxviii...

  • Page 31: Installation

    INSTALLATION Antenna Unit (X-band Radar) 1.1.1 Installation Considerations • The Antenna Unit is generally installed either on top of the wheelhouse or on the radar mast, on a suitable platform. Locate the Antenna Unit in an elevated position to permit maximum target visibility. •...
  • Page 32 1. INSTALLATION • Install the Antenna Unit away from interfering high-power energy sources and TX radio antennas. • Keep the lower edge of the Antenna Unit above the safety rail by at least 500 mm. • Install two Antenna Units as shown in the figure below. •...
  • Page 33 1. INSTALLATION • For X-band radar, if it is necessary to lay down the radiator before you fasten it to the Antenna Unit, lay it down with the wave- guide up, to prevent dam- age to the cylinder that surrounds the waveguide. •...
  • Page 34 1. INSTALLATION 5. Loosely fasten the four bolts from the side (3 to 6 in the right figure). Then fasten first the inside bolts (3 and 4 in the right figure), and fasten the outside bolts (5 and 6 in the right figure).
  • Page 35 1. INSTALLATION Upright hoisting Sideways hoisting Lay the antenna unit down and attach it to its mast on the deck. Then, hoist the an- tenna unit including the mast. Attach a shackle (local supply) to each lifting fixture. Using two belt slings (local supply), pass one through the stern side of the radiator bracket with the bow side facing upward, and pass the other through two shackles.
  • Page 36 1. INSTALLATION • The reinforcement rib must be installed diagonally. 2. Referring to the outline drawing at the back of this manual, drill four mounting holes ( 15 mm) in the mounting platform. 3. Place the Antenna Unit on the platform, then orient the unit so the bow mark on its base is facing the ship’s bow.
  • Page 37 1. INSTALLATION plied) between the grounding point and ground terminal on the Antenna Unit. Coat the hardware of the ground system with the supplied adhesive (marine sealant). Antenna chassis side Mounting platform side Arrange a ground terminal as close as possible to Antenna Unit. There are two methods to connect the ground wire for mounting platform side.
  • Page 38 1. INSTALLATION 3. Coat the grayed area shown below with the supplied adhesive (marine sealant). 4. Coat the supplied O-ring with a grease (local supply) and set it to the O-ring groove of the radiator flange. 5. Set the antenna radiator to the radiator bracket, taking care the orientation of the radiator.
  • Page 39 1. INSTALLATION There are two methods to hoist the Antenna Unit. Hoist the Antenna Unit slowly. Hoist- ing it swiftly may damage the antenna radiator or the radiator chassis. After hoisting the Antenna Unit, remove the shackles (local supply) used to attach the belt sling(s). Protect the parts where the antenna unit and the belt slings come into contact with cloth to prevent scratches.
  • Page 40 1. INSTALLATION 3. Insert four sets of hex bolts (supplied, M12 60) attached the seal washers to the mounting holes of the antenna chassis from the top side, referring to the installation guide (C3900Y01) at the back of this manual. Lift the anten- na chassis slightly then insert the sup- plied insulation sheets to the bolts.
  • Page 41 1. INSTALLATION 3. Coat the grayed area shown below with the supplied adhesive (marine sealant). 4. Coat the supplied O-ring with a grease (local supply) and set it to the O-ring groove of the radiator flange. 5. Set the antenna radiator to the radiator bracket, taking care the orientation of theradiator.
  • Page 42 1. INSTALLATION Also, hoist the Antenna Unit slowly. Hoisting swiftly may cause a damage to the an- tenna radiator or damage the radiator chassis. Protect the parts where the antenna unit and the belt slings come into contact (dashed area) with cloth to prevent scratches. Upright hoisting Note: Do not hoist the Antenna Unit by hanging belt slings around the radiator directly.
  • Page 43 1. INSTALLATION How to fasten the Antenna Unit to the mounting platform 1. Construct a suitable mounting platform referring to the outline drawing at the end of this manual. Note: The mounting platform must be flat, level and firmly secured. 2.

  • Page 44: Antenna Unit (S-Band Radar)

    1. INSTALLATION Antenna Unit (S-band Radar) For installation considerations regarding the Antenna Unit, see section 1.1.1. 1.2.1 Installation precaution for S-band Antenna Unit Due to the S-band radiator length, there may be excessive stress placed on the radi- ator caused by vibrations, rolling and general ship movement. To prevent damage to the Antenna Unit and radiator, do not install the antenna near the end of a platform.
  • Page 45 1. INSTALLATION logo of the radiator to the side with bow mark on the bracket. If reversely oriented, the radiator cannot be set to the bracket.) 3. Coat the threads of eight hex bolts (M12 50, supplied) with the supplied adhesive (marine sealant).
  • Page 46 The Antenna Unit may be assembled before hoisting it to the mounting platform. Ori- ent the FURUNO logo of the radiator to the bow side of the antenna unit. Hoist the an- tenna unit with belt slings and shackles of hole diameter 20 mm (supplied locally with required quantities according to hoisting).
  • Page 47 1. INSTALLATION scratches. After the antenna unit is hoisted in place, remove the all shackles and the lifting fixtures at the upper chassis (A, two places). Sideways hoisting The antenna unit is fastened sideways to a mast, etc. and together with the mast installed at a high position on the vessel.
  • Page 48 1. INSTALLATION • The reinforcement ribs must be installed diagonally shown in the following fig- ure. 2. Referring to the outline drawing, drill eight mounting holes ( 16 mm) in the mount- ing platform. 3. If two insulation sheets (type: 03-183- 3106) are supplied in the installation ma- terials, place these sheets as aligned with eight mounting holes.
  • Page 49 1. INSTALLATION 6. Using a hex bolt (M6 25), nut (M6), spring washer (M6) and flat washer (M6), es- tablish the ground system on the mounting platform as shown in the following fig- ure. The location must be within 340 mm of the ground terminal on the Antenna Unit.
  • Page 50 1. INSTALLATION 3. Orient the FURUNO logo of the radiator to the side with the sticker on the bracket. If re- versely oriented, the radiator cannot be set to the bracket. Set the radiator so the guide pins fit into the guide holes on the radiator bracket.
  • Page 51 1. INSTALLATION 2. Attach four shackles to both sides of two belt slings. Attach the shackles to the four lifting fixtures on the chassis so that the belt slings passes over the radiator. 3. Lift while tilting the antenna unit so that the front and rear loads of the belt slings are even.
  • Page 52 1. INSTALLATION 2. Lay the corrosion-proof rubber mat (supplied) on the mounting platform, aligning the holes on the rubber mat with the fixing holes on the mounting platform. 3. Lay the antenna unit on the rubber mat, orienting it so the cable gland is directed toward ship's bow.

  • Page 53: Monitor Unit

    1. INSTALLATION Monitor Unit See the appropriate operator’s manual for the following MU series monitors for the in- stallation procedure. Monitor unit Manual type Monitor unit Manual type MU-190 OMC-44670 MU-231 OMC-44690 MU-190HD OMC-44570 MU-270W OMC-44930 Keep in mind the following points when selecting a location. •...
  • Page 54 1. INSTALLATION • Locate the unit away from heat sources because of heat that can build up inside the cabinet. • Locate the equipment away from places subject to water splash and rain. • Leave sufficient space at the sides and rear of the unit to facilitate maintenance. •...
  • Page 55 1. INSTALLATION 3. Attach a ground wire (IV-1.25sq, supplied locally) to the ground terminal at the bottom of the unit. 4. Secure the control unit the KB fixture, using four binding screws (M5 20, sup- plied). 5. Attach four bolt hole caps (supplied). How to mount the unit flush with mounting surface <RCU-014/015/016>...
  • Page 56 1. INSTALLATION 2. Fix the Control Unit with four screws (M4) from the underside of the desktop. (The M4 screws with a sufficient length for the thickness of the desktop should be pro- vided locally.) Control Unit RCU-014 Control Unit RCU-015/RCU-016 <RCU-031>...
  • Page 57 1. INSTALLATION 5. Fasten the four wing nuts (supplied) to the stud bolts from the rear side of the mounting surface. 1.4.2 Flush mount Installation Note: For flush mounting in a panel, the mounting surface must be flat. Do not install the unit on an uneven surface.
  • Page 58 1. INSTALLATION 5. Fasten each wing screw and then fasten the hex. nuts as shown in figure below. Side view of Control Units Flush mount, using with panel (for RCU-014 only) Use the optional flush mount kit OP03-245 to mount the control unit to a console panel using with the panel.
  • Page 59 1. INSTALLATION 1.4.3 Installation of RCU-016 connected with RCU-014 1.4.4 How to change the cable entry of RCU-015/016 To change the cable entry from the side (default) to the bottom, modify the unit as shown in the following procedure. 1. Turn the chassis upside-down and remove four screws (M3 8) to open the back cover.

  • Page 60: Power Supply Unit

    1. INSTALLATION Power Supply Unit This unit can be installed on a bulkhead, wall or on the floor. 1.5.1 Installation considerations Keep in mind the following points when selecting a location. • Locate the Processor Unit away from heat sources because of heat that can build up inside the cabinet.

  • Page 61: Processor Unit

    1. INSTALLATION 1.5.2 How to install the Power Supply Unit Use four bolts (M6, local supply) to fasten the Power Supply Unit. For bulkhead mounting, fasten two bolts for the lower notches, leaving 5 mm of thread exposed from the bolt head.

  • Page 62: Transceiver Unit

    1. INSTALLATION • Install the Processor Unit on the floor, or on a bulkhead with the following direction. For bulkhead, the cable entry must face the deck. • Connect the ground wire (IV-8sq, local supply) between the earth terminal on the chassis and the ship’s earth, using the supplied crimp-on-lug FV2-M3 BLU.

  • Page 63: Intelligent Hub (Option)

    1. INSTALLATION • Locate the equipment away from places subject to water splash and rain. • Leave sufficient space at the sides and rear of the unit to facilitate maintenance. • Determine the location considering the length of the cable between the transceiver unit and the Antenna Unit and the cable between the transceiver unit and the Power Supply Unit.

  • Page 64: Switching Hub (Option)

    1. INSTALLATION 2. Fasten four self-tapping screws ( 4 20, supplied) to secure the unit. Switching Hub (option) Use the HUB-100 to connect sensor networks. This network cannot be connected to the shipborne LAN network. Further do not connect a commercial PC to this network, other than for the maintenance.

  • Page 65: Wiring

    WIRING Overview The procedure explanations in this chapter mainly use illustrations of the magnetron radar. Some parts are omitted in the illustrations for clarity. Cable considerations To lessen the chance of picking up electrical interference where possible, avoid rout- ing the antenna cable (power and LAN lines) near other onboard electrical equipment (radars, TX radio antennas, etc.).
  • Page 66 2. WIRING 2.1.1 Standard wiring A Cat 5e LAN cable (RW-00135, RW-00339) connects between the Antenna Unit (Power Supply Unit for FAR-2258/2268DS) and the Processor Unit. The maximum length of the cabling between the Processor Unit and the Antenna Unit is 80 m. Retrofit (using antenna cable RW-96006895/4896) or foremast installation is also pos- sible, with the installation of a pair of LAN Signal Converters, one in the Antenna Unit, the other in the Processor Unit.
  • Page 67 2. WIRING X/S-band radars for FAR-2258/2268DS radars...
  • Page 68 2. WIRING X-band/S-band (TR-DOWN) radars The appropriate radars are FAR-2328W and FAR-2338SW.
  • Page 69 2. WIRING WAGO connector A terminal opener is provided on the circuit board as below. FAR-2x18/2x28/2x38S/20x8-MARK-2 radars FAR-2258/2268DS radars...

  • Page 70: Antenna Unit (X-Band, Tr-Up)

    2. WIRING Antenna Unit (X-band, TR-UP) 2.2.1 How to fabricate the cables LAN cable RW-00135 (antenna cable, RSB-128/130/146) For X-band radar, the end of the antenna cable RW-00135 which connects to the An- tenna Unit is pre-fabricated. RW-0013/RW-0030/03CA00099 (antenna cable, RSB-139) •...
  • Page 71 2. WIRING • RW-0030: With armor RW-9600/6895/4873 (for retrofit or foremast installation, RSB-128/146) The existing cable (RW-9600/6895/4873) can be used for the following cases. • Cable extension for foremast installation (only for RW-9600 cable) • Retrofit Depending on your installation, one or more of the following kits (available as optional extras) may be required.
  • Page 72 2. WIRING For wiring the RW-9600 cable via the cable cover, the cable fabrication is shown be- low. In other cases, see the installation manual in the optional kit. The unused power lines are tied up and attached to a crimp-on lug FV5.5-S4 (LF), supplied locally.
  • Page 73 2. WIRING TPYCY-2.5 (Motor power cable for RSB-139) 2.2.2 How to connect the cables (RSB-128) 1. Loosen four bolts from the rear cover to remove the rear cover. If the de-icer is already installed, loosen two bolts inside the antenna to remove the front cover. Note 1: The cable for the performance monitor is connected between the rear cover and the RF-TB Board in the Antenna Unit.
  • Page 74 2. WIRING 2. Disconnect the performance monitor connector (J807) and the motor drive con- nectors (J803, J804 and J808) from the RF-TB Board. 3. Unfasten the six bolts in the figure below to enable removal of the transceiver unit. Then, pull the handle on the transceiver unit to remove the unit. For magnetron radar, lay the unit on its side or on top of non-ferrous material, to prevent demagnetization of the magnetron 4.
  • Page 75 2. WIRING unfasten the four screws circled in the following figure, then orient the cable en- trance in the required direction. Refasten the screws. 5. Unfasten the two screws fixing the cable clamp for antenna cable, then pass the antenna cable through the cable entrance. If applicable, unfasten the two screws fixing the cable clamp for the sub monitor and de-icer power cable, then pass the cables through the cable entrance.
  • Page 76 2. WIRING 7. Re-mount the transceiver unit then reconnect the connectors for the motor (J803, J804 and J808). 8. Attach the appropriate WAGO connectors (pre-attached) to the appropriate ca- bles, and then connect the antenna and sub monitor cables to the RF-TB Board as shown in the following figure.
  • Page 77 2. WIRING 9. For DE-ICER INSTALLATION, connect the de-icer power cable to the de-icer board 03P9573 attached on the front cover. If the de-icer is not provided, go to step 10. 1) Remove four screws from the motor and disconnect connectors J875 and J876 to remove the motor.
  • Page 78 2. WIRING 3) Pass the de-icer power cable through the cable band. Connect the cable to TB901 on the DE-ICER board (03P9573), using the supplied crimp- on lugs. 4) Attach the motor and connectors re- moved at step 1). 5) Set the Voltage Setting switch accord- ing to the power source for the de-icer;...
  • Page 79 2. WIRING 11. Coat the hinge with the supplied adhesive (marine sealant) to waterproof the hinge then close the cable entrance cover. Fix the cable cover with four screws, then coat the screws with the supplied adhesive (marine sealant). 12. Reconnect the performance monitor connector (J807) to the rear cover. 13.
  • Page 80 2. WIRING 2.2.3 How to connect the cables (RSB-146) 1. Loosen four bolts from the rear cover to remove the rear cover. Note: If the performance moni- tor is installed, disconnect the XH connector on the rear cover. 2. Loosen four screws on the cable cover at the starboard side to open the cable cov- er.
  • Page 81 2. WIRING LAN cable: LAN connector through the wiring clamps (A, B) Shield of LAN cable: Screw (D) <For RW-9600> Disconnect the connector between the BNC case and the converter, connect the coaxial cable to the BNC case. After connection, fasten the BNC case to the chassis (Tightening torque: 1.2 N•m).
  • Page 82 2. WIRING 6. Close the cable cover, then coat the screws with the supplied adhesive (ma- rine sealant). The torque must be 4.1 N•m. 7. Hook the safety rope to the rope groove on the chassis, then attach the rear cover (Tightening torque: 21 N•m).
  • Page 83 2. WIRING 2. Release the cable clamp and remove the dummy plug, which may be discarded, shown in the figure below. Attach the de-icer cable and clamp the armor with the cable clamp with two screws (Tightening torque: 4.1 N•m). 3.
  • Page 84 2. WIRING 2.2.4 How to connect the cables (RSB-139) 1. Loosen 12 bolts from both covers to remove the covers. Note 1: If the performance monitor is installed, the cable for the performance monitor is connected between the cover for the RF unit side and the RF-TB Board in the Antenna Unit.
  • Page 85 2. WIRING 3. Unfasten the two bolts circled in the figure below to enable removal of the RF unit. Then, pull RF unit to remove it with the handle. To move the RF unit, use two han- dles on the RF unit. Note: The magnetron in the transceiv- er module will demagnetize if it con- tacts ferrous material.
  • Page 86 2. WIRING 6. Push the flat washer against the armor then sandwich in the armor between two flat washers. 7. Trim the armor so that it does not extend past the flat washers. 8. Pass the antenna and power cables through each cable entrance and attach the appropriate connectors to the appropriate cables.

  • Page 87: Antenna Unit (X-Band, Tr-Down)

    2. WIRING 3) Remove the TNC junction box from the RF unit and then connect the coaxial cable of the antenna cable to the BNC case. 4) Re-mount the TNC junction box to the RF unit. 9. Apply the supplied adhesive (marine sealant) to the threads of the cable glands, and then fasten it tightly with the hook spanner.
  • Page 88 2. WIRING DPYCY-1.5 (for the optional de-icer) • Before beginning any work on the Antenna Unit, turn off the breaker for the de-icer at the mains switchboard. (Turning off the display unit has no effect.) • The de-icer activates when the temperature becomes 0 °C, and shuts down when the temperature reaches 5 °C.
  • Page 89 2. WIRING 2.3.2 How to connect the cables (RSB-130) 1. Loosen four bolts from the rear cover to remove the rear cover. If the de-icer is already installed, loosen two bolts inside the antenna to remove the front cover. Note 1: The cable for the performance monitor is connected between the rear cover and the RF-TB Board in the Antenna Unit.
  • Page 90 2. WIRING 3. Unfasten four screws to open the cable entrance cover. Note: The orientation of the cable entrance can be changed. See "How to change the orientation" on page 2-10. 4. Unfasten the two screws fixing the cable clamp for the serial cable, then pass the serial cable (TTYCYSLA-10) through the cable entrance.
  • Page 91 2. WIRING 6. Attach the appropriate WAGO connectors (pre-attached) to the serial cable, and then connect the serial cable to the RF-TB Board as shown in the following figure. For how to connect the WAGO connector, see "WAGO connector" on page 2-5. For pin arrangement, see the interconnection diagram at the back of this manual.
  • Page 92 2. WIRING 1) Remove four screws from the motor and disconnect connectors J875 and J876 to remove the motor. 2) Set a wiring clamp (supplied) at locations (B) and (C) shown in the following figure. Pass the de-icer power cable from cable entrance through the wiring clamps (A), (B) and (C) and pull it to the front side.
  • Page 93 2. WIRING 8. Position the cables so their armors lie beneath their respective cable clamps in the cable entrance. Fasten the cable clamps. 9. Coat the hinge with the supplied adhesive (marine sealant) to waterproof the hinge then close the cable entrance cover. Fix the cable cover with four screws, then coat the screws with the supplied adhesive (marine sealant).

  • Page 94: Antenna Unit (S-Band, Tr-Up)

    2. WIRING 4) Connect the waveguide flange and then fix with the bolt. 5) Wipe off the excess adhesive (marine sealant) from the flange. 12. Hold the rear cover at the lower part (near the intake), and the push it horizontally to- wards the chassis until the gasket between the front and rear covers is about 5 mm wide.
  • Page 95 2. WIRING RW-0013/03CA00099 (Antenna cable, RSB-144) RW-9600/6895/4873 (for retrofit) To use the existing cable (RW-9600/6895/4873) for the retrofit, two optional kits are required. For the LAN Coaxial Converter, see section 2.10 "LAN Signal Converter" for details. • LAN Signal Converter: Type: OP03-247-2 (for RSB-129) Type: OP03-247-1 (for RSB-133) •...
  • Page 96 2. WIRING DPYCY-1.5 (for the optional de-icer) • Before beginning any work on the Antenna Unit, turn off the breaker for the de-icer at the mains switchboard. (Turning off the display unit has no effect.) • The de-icer activates when the temperature becomes 0 °C, and shuts down when the temperature reaches 5 °C.
  • Page 97 2. WIRING 1. Loosen four bolts on the rear cover to remove the rear cover. If the de-icer is al- ready installed, loosen also four bolts on the front cover to remove the front cover. If the lifting fixtures are still attached, they should be removed. For how to remove the lifting fixtures, see "How to hoist the Antenna Unit"...
  • Page 98 2. WIRING 3. Disconnect the coaxial cable and unfasten the four bolts as shown below. Then, remove the RF unit with the handle. Note: For magnetron radars, lay the unit on its side or on top of non-ferrous material, to prevent demagnetization. 4.
  • Page 99 2. WIRING 8. Pass the antenna cable through the cable entrance. If applicable, unfasten the appropriate cable glands and pass the sub monitor and de-icer power cables through the cable entrance. Pass the cables through their respective wiring clamp. 9. All other cables are connected to the RF unit and should be pulled out of the chas- sis after passing them through their respective cable entrances.
  • Page 100 2. WIRING Note: For the antenna cable RW-9600/6895/4873, connect the crimp-on lug (that binds unused wires) together with the shield of the power line. Destination of sub monitor cable Note: Remove (or Loosen) four bolts as shown in the following figure to re- move the RF-TB Board from the RF unit.
  • Page 101 2. WIRING Note: For the antenna cable RW-9600/6895/4873, connect the crimp-on lug (that binds unused wires) together with the shield of the power line. Destination of sub monitor cable Signal line: TB803 through the wiring clamp (A), see the figure for the "Desti- nation of Antenna cable:"...
  • Page 102 2. WIRING 2) Pass the de-icer power cable through the cable band. Connect the cable to TB901 on the DE-ICER board (03P9573), using the supplied crimp-on lugs. 3) Set the Voltage Setting switch according to the power source for the de-icer; 115 V or 230 V.
  • Page 103 2. WIRING 2.4.3 How to connect the cables (RSB-144) 1. Remove 10 bolts from the cover, right side viewed from the cable entry side, to remove the cover. Note: The safety rope is attached to this cover to prevent falling the cover. 2.
  • Page 104 2. WIRING Antenna cable Connect the wires of the antenna cable to the appropriate WAGO connectors(pre- attached on the RF-TB board), according to wiring stickers. • Signal lines: TB801, TB802 and TB803, through the wire saddles (A), (B). • Coaxial cable: TB902 on the TNC Junction Box, through the wire saddles (A), (B).

  • Page 105: Antenna Unit (S-Band, Tr-Down)

    2. WIRING 5. Apply the supplied adhesive (marine sealant) to the threads of the cable glands, and then fasten it tightly with the hook spanner. Note: Use the wrench of the correct size referring to cable gland size below. If youdo not have the hook spanner, contact your dealer.
  • Page 106 2. WIRING Microwave coaxial cable See the supplied instruction manual (C32-01904) in Antenna Unit for details. 2.5.2 How to connect the cables (RSB-131) Three cables are connected to the Antenna Unit: serial cable from the transceiver unit, microwave coaxial cable and de-icer power cable (option). The procedure shows how to connect all cables.
  • Page 107 2. WIRING 2. Disconnect the performance monitor connector (J807) from the RF-TB Board. 3. Unfasten the cable gland for the serial cable (TTYCSLA-10) and remove the gas- ket and three flat washers and remove the protector. 4. Slide the cable gland, the gasket and three flat washers onto the cable.
  • Page 108 2. WIRING Shield of serial line: Screw (C) 10. For DE-ICER INSTALLATION, connect the de-icer power cable the de-icer board 03P9573 attached on the front cover. If the de-icer is not provided, go to step 11. 1) Unfasten two bolts to remove the RF-TB assembly, then pass the de-icer power cable through the cable entrance.
  • Page 109 2. WIRING 3) Pass the de-icer power cable through the cable band. Connect the cable to TB901 on the DE-ICER board (03P9573), using the supplied crimp-on lugs. 4) Set the Voltage Setting switch according to the power source for the de-icer; 115 V or 230 V.

  • Page 110: Power Supply Unit

    2. WIRING 13. Fasten the coaxial connector to the waveguide flange with three sets of M6 20 hex bolts, M6 spring washers and M6 nuts. 14. Tape the cable with two or more turns of self-bonding tape then wrap with PVC tape. 15.
  • Page 111 2. WIRING RW-0013/RW-0030/03CA00099 (for Antenna cable) <RW-0013/03CA00099> <RW-0030> TPYCY-2.5 (for Motor power cable) 2-47...
  • Page 112 2. WIRING DPYC-2.5 cable (for Power) Clamp the sheath with the cable clamp. RW-00339 (for Processor Unit) The end of the cable RW-00339 which connects to the Power Supply Unit is prefabri- cated. Clamp the cable at the outer shield which is wrapped on the outer sheath. RW-4864/00136 (for sub monitor) The ends of the sub monitor cable are prefabricated.
  • Page 113 2. WIRING Cable entrance There are two layers at the cable entrance on the front side of the Power Supply Unit, upper and lower entrances. Remove the six M4 screws of total to set the cables on the cable entrances. The lane for each cable is as shown below, referring to the Wiring Label attached on the reverse side of the top cover.
  • Page 114 2. WIRING • Shield line: Screw (C) • Coaxial cable: J716 through the wiring clamp (D). Then clamp the shield part of the coaxial cable with the cable clamp (E). Connection of Motor power cable (From Antenna Unit) 1. Connect the lines of the cable to the appropriate WAGO connectors (TB713), re- ferring to the interconnection diagram at the back of this manual.
  • Page 115 2. WIRING Connection of Power cable 1. Loosen four screws on the front plate, then unfasten two screws on the cable clamp to set the power cable. 2. Set the power cable on the cable entrance, and fasten the sheath part of the pow- er cable with the cable clamp.
  • Page 116 2. WIRING 3. Connect the lines of the cable for Processor Unit as shown below through the wir- ing clamp (B). • Serial lines: TB704 • Shield line: Screw (A) • LAN cable: J503 Connection of cable for Control Unit 1.
  • Page 117 2. WIRING 3. Connect the cable for Control Unit to the connectors (TB711 and TB712) through the appropriate wiring clamps (A) and (B). Connection of cable for sub monitor Up to four cables (RW-00136, RW- 4864) can be uses as sub monitor ca- bles.

  • Page 118: Transceiver Unit

    2. WIRING Transceiver Unit The TR-DOWN radar requires the transceiver unit as follows: • Transceiver Unit RTR-108 for X-band radar (FAR-2328W) • Transceiver Unit RTR-109 for S-band radar (FAR-2338SW) 2.7.1 How to fabricate the cables For how to connect the LAN modular plug, see "LAN cable" on page 2-6. For how to connect the WAGO connector, see "WAGO connector"...
  • Page 119 2. WIRING RW-00135 S03-92-15/30/40/50 (RW-00136 + connector, for a sub monitor) Note: The maximum cable length is 50 m. Clamp the armor with the cable clamp. 2.7.2 How to connect the cables from X-band radar antenna Antenna cable, serial cable, sub monitor cable 1.
  • Page 120 2. WIRING • Destination of Antenna cable Power line: TB801 through the wiring clamp (A). LAN cable: J821 through the wiring clamps (A and B, three places.) Shield of power line: Screw (C) Shield of LAN cable: Screw (D) • Destination of cable for the sub monitor Signal line: TB803 through the wiring clamp (A).
  • Page 121 2. WIRING 4. Bind all cables with cable ties supplied locally (two places). 5. Check that armor of cables are lying in their respective cable slots then fasten the cable clamp. Flexible waveguide (FR-9) The RF interconnection between the Antenna Unit and the transceiver can be made with a flexible waveguide (FR-9).
  • Page 122 2. WIRING 2.7.3 How to connect the cables from S-band radar antenna Antenna cable, serial cable, sub monitor 1. Loosen eight bolts then remove the cover of the unit. 2. Unfasten three bolts from the cable clamp. Lay the cables in their cable slots so their armors rest in the slots.
  • Page 123 5. Check that armor of cables are lying in their respective cable slots then fasten the cable clamp. Microwave coaxial plug Attach the microwave coaxial plug to the coaxial cable. See the applicable FURUNO technical information for the procedure. Attach the coaxial cable assembly to the transceiver unit as follows: 1.

  • Page 124: Processor Unit

    2. WIRING Processor Unit 2.8.1 How to fabricate cables For locations of cables and cores, see the sticker on the reverse side of the top cover. (All dimensions in millimeters) For how to connect the LAN modular plug, see "LAN cable" on page 2-6. For how to connect the WAGO connector, see "WAGO connector"...
  • Page 125 2. WIRING DPYC-2.5/6 cable (for Power) Clamp the sheath with the cable clamp. For the supplied crimp-on lugs, use FV2-4 for AC power cable, FV5.5-4 for DC power cable. TTYCSLA series cable (for serial) 2.8.2 How to connect cables inside the Processor Unit Connect the ground wire between the ground termi- nal on the chassis and the ship’s earth.
  • Page 126 2. WIRING Connection of Antenna cable For existing antenna cable, see section 2.10 "LAN Signal Converter". 1. Remove the spacers to pass the antenna cable on the upper plate. 2. Fasten the cable to the post part of the plate with a cable tie (local supply). Con- nect the inner/outer shields and the extra wires of the existing cable to the ground terminal.
  • Page 127 2. WIRING 4. Remount the plastic cover and the power cable cover. Connection of cables for serial, contact signal lines and sub monitors of EC- 1. Unfasten the four bolts dashed circled below to remove the upper plate of the ca- ble clamp.
  • Page 128 2. WIRING 4. Pass the cables to the TB board 03P9648 and 03P9562 through the wiring clamps (A, B and C) in the figure shown right. For the cables on the upper plate, use wiring clamps (A and B). For the cables on the lower plate, use wiring clamps (A, B and C).
  • Page 129 2. WIRING Fasten the cable to the post part of the plate with a cable tie (local supply). Note: Be sure the vinyl sheath on the post. 4. Pass the cables to the TB board 03P9648 and clamp the shield of the cable with the cable clamp (A) shown in the following figure.

  • Page 130: Monitor Unit

    2. WIRING Fastening of USB connector (for C-type radars) The USB connector of the RP board should be fas- tened as shown in the figure to the right. Use three cable ties (local supply) to secure the connector of the USB cable to the upper cable entrance of the Processor Unit.
  • Page 131 2. WIRING RGB signal from the DVI-I. See the operator’s manual supplied with the VDR. Ad- justment of the output is necessary. Menu Setting (For MU series monitors) The [INSTALLATION SETTING] menu appears only when the power is turned on for the first time after installation of the monitor unit.

  • Page 132: Lan Signal Converter

    2. WIRING 2.10 LAN Signal Converter The LAN Signal Converter allows the use of existing antenna cable RW-9600/6895/ 4873 for TR-UP radar. If the LAN Signal Converter is not attached in the antenna and Processor Units, the LAN Signal Converter Kit (optional supply) is required. For X-band radar only, you can select a specification with the LAN Signal Converter pre-installed at the factory.
  • Page 133 2. WIRING Method 2: Using antenna cable RW-9600 2.10.2 Wiring in the Antenna Unit with LAN Signal Converter pre-in- stalled (X-band radar only) Note: If the Antenna Unit does not included the LAN Signal Converter, the converter kit (available as an optional extra) is required. See "LAN Signal Converter Kit (option)"...
  • Page 134 2. WIRING 2.10.3 Wiring in the Processor Unit installed the LAN Signal Convert- er already (X-band radar only) 1. Disconnect the connection (A) between the converter and BNC case. Unfasten two screws (B) on the BNC case assembly to remove the BNC case assembly from the Processor Unit.

  • Page 135: Junction Box (Option)

    2. WIRING State Meaning Link down Lighting green 100 M link up Flashing green 100 M active Lighting orange 10 M link up Flashing orange 10 M active Coax/PLC Link down Lighting green Link up Master/Slave Lighting green Master mode Lighting orange Slave mode Note: The TEST button is for factory use.

  • Page 136: Intelligent Hub (Option)

    2. WIRING 2.12 Intelligent HUB (option) Secure the LAN cables to the cable clamps on the HUB-3000 with cable ties (sup- plied). 2.13 VDR Connection The Processor Unit has the DVI-I port or the LAN port for connection of a VDR. 2.13.1 DVI-I (Analog RGB) port connection •...

  • Page 137: Adjustments

    ADJUSTMENTS Note: After completing the settings and adjustments, copy the setting data to a SD- card* (USB flash memory* for C-type radars), referring to the Operator's Manual. This will allow easy restoration of setting data after the MAIN Board is replaced, etc. *: The SD card slot is in front of the Processor Unit, and the USB flash memory slot is connected to the RP board 03P9657.
  • Page 138 3. ADJUSTMENTS RCU-015/016 RCU-031 How to Use the Menu 1. Press the Power key to turn on the unit. 2. Press the MENU key or click the [MENU] box to open the main menu. The [RADAR INSTALLATION] menu does not ap- pear when the unit is first turned on.

  • Page 139: Radar Installation Menu

    3. ADJUSTMENTS Radar Installation Menu The [RADAR INSTALLATION] menu has various items through two pages for adjust- ment of the radar. To show this menu; For RCU-014/031: Press and hold the HL OFF key, then press the MENU key five times.

  • Page 140: How To Adjust The Sweep Timing

    3. ADJUSTMENTS In practice, you will probably observe some small bearing error on the display because of the difficulty in achieving accurate initial positioning of the Antenna Unit. The follow- ing adjustment will compensate for this error. 1. Select a stationary target echo at a range between 0.125 and 0.25 NM, preferably near the heading line.

  • Page 141: How To Suppress Main Bang

    3. ADJUSTMENTS How to Suppress Main Bang Main bang is the clutter at the center of the screen that you typically see on the radar display, and it may mask close-in targets. If main bang appears at the screen center, suppress it as follows.
  • Page 142 3. ADJUSTMENTS When using the number keys, the indication is first selected as a whole. At this time, you can toggle between plus "+" or minus "-". Press the 8 key for "-", press the 2 key for "+". If single digits are highlighted, toggle is not possible. In this case, press the CANCEL/TRAILS key to re-highlight the whole indication.
  • Page 143 3. ADJUSTMENTS [CLOSE TGT ES LEVEL] Select the effect level of the echo stretch around own ship which is selected in [CLOSE TGT ES MODE] among six enlarging patterns. The higher the number the greater the amount of stretch. To disable echo stretch, select [OFF] (default). The six enlarging patterns are shown in the table below, “Distance 1”...
  • Page 144 3. ADJUSTMENTS 3.5.2 [OWN SHIP INFO] menu Enter the length and width of the ship, and scanner, GPS antenna and conning posi- tions, referring to the description and figure below. Note: This radar uses [CONNING POSITION] for CCRP and [SCANNER POSITION] for ANT as reference points for measurements and calculations.
  • Page 145 3. ADJUSTMENTS 3.5.3 [SCANNER] menu Open the main menu then select [RADAR INSTALLA- TION] [SCANNER] to open the [SCANNER] menu. [SECTOR BLANK1(2)] Set area(s) where to prevent transmission. Heading must be properly aligned (see section 3.2) before setting any blind sector. For example, set the area where an interfer- ing object at the rear of the antenna would produce a dead sector (area where no echoes appear) on the display.
  • Page 146 3. ADJUSTMENTS [DUAL RADAR SETTINGS] When installing two FAR-2xx8 series radars, the im- age from both radars (main radar and external radar) may be shown together on one radar display. Note 1: This function is NOT available between the FAR-2xx8 radar and other radars. Note 2: This function is available only for A/B type radars using software version 01.**/03.**.
  • Page 147 3. ADJUSTMENTS • [COMBINE SECTOR]: Set the start position and angle of the sector, referring to the exam- ple to the right. [START]: Start point of the sector (default: 000°, 000°to 359°) [ANGLE]: Horizontal width of the sector (de- fault: 001°, 001°to 360°) •...
  • Page 148 FAR-2258/2268DS radars. For FAR-2258/2268DS radars, set the ra- dar model properly. If this setting is different from your model, the radar will not function properly. • [12]: For FAR-2218(-BB)/2318 • [25UP]: For FAR-2228(-BB)/2328 • [25DOWN]: For FAR-2328W...
  • Page 149 3. ADJUSTMENTS • [30UP]: For FAR-2238S(-BB)/2338S • [30DOWN]: For FAR-2338SW • [S-NXT]: For FAR-2238S-NXT(-BB)/2338S-NXT • [50]: For FAR-2258 • [60]: For FAR-2268DS • [X-NXT]: For FAR-2228-NXT(-BB)/2328-NXT [TYPE] Select the type of radar. Software version Type Contents 01.**/03.** 50.** [IMO] IMO specifications Near-IMO specifications —...
  • Page 150 3. ADJUSTMENTS 2. Select [PM GAIN ADJ] then spin the scrollwheel so that the outer arc faintly ap- pears. The setting range is 0 to 255 (default: 255). Wait at least eight scans then right click to set. Note: Turn off a stern blind sector before adjusting the PM gain, to display the echo from the performance monitor properly.
  • Page 151 3. ADJUSTMENTS [ANT CABLE] Select the method of connection between the radar sensor and the Processor Unit. [LAN] (LAN cable only) or [LAN+COAXIAL] (LAN and coaxial cables). Select [LAN+COAXIAL] when the optional LAN Signal Converter is installed. [ICE MODE SETTINGS] For the radars using software version 01.**/03.**.
  • Page 152 3. ADJUSTMENTS Note: [48NM] is available only for the [MODEL] setting is set to [50] or [60] (see "[MODEL]" on page 3-12). [TT ECHO LEVEL] Set the detection level of echoes. The setting range is 1 to 31 (default: 13). [QV DISPLAY] This function is used for diagnostic purposes.
  • Page 153 3. ADJUSTMENTS [TRACK PRESET] • [GATE SIZE]: Set the gate size among [S], [M], [L] or [LL] (default: [M]) • [FILTER RESPONSE]: Set the filter response function. The setting range is 1 to 4. [1]: Filter response is improved (default). [4]: Filter stability is improved.
  • Page 154 3. ADJUSTMENTS Alert Unit For software version 03.** For software version 50.** Antenna Unit • LOST AZIMUTH SIG • NO AZIMUTH SIGNAL Transceiver Unit • LOST HEADLINE • NO HEADLINE SIGNAL • LOST TRIGGER SIG • NO TRIGGER SIGNAL • LOST VIDEO SIG •...
  • Page 155 3. ADJUSTMENTS The available alerts are as follows: <For IMO-type radars using software version 01.**/03.**> <For Fishing specifications radars using software version 50.**> To monitor for Processor Unit failure, connect SYS_FAIL and PWR_FAIL from ter- minal J613 in the Processor Unit to the AMS. ALERT DATA OUT Select the alert output format, [ALR] or [ALF] (default).
  • Page 156 3. ADJUSTMENTS LOG(BT) ALERT Select [ON] to activate alert "NO LOG(BT) SIGNAL" for signal loss of speed over ground. LOG(WT) ALERT Select [ON] to activate alert "NO LOG(WT) SIGNAL" for signal loss of speed through water. 3.5.8 [INPUT PORT SETTINGS] menu The input signals to the ports on the Processor Unit are shown below.
  • Page 157 3. ADJUSTMENTS Open the main menu then select [RADAR INSTALLA- TION] [INPUT PORT SETTINGS] to open the [IN- PUT PORT SETTINGS] menu. How to set the port setting of each data; 1. Select the data for port setting in the [INPUT PORT SETTING] menu.
  • Page 158 3. ADJUSTMENTS [LOG], [HEADING] The speed data and heading data have two ports to input the source data shown in the follow- ing figure. • Speed data: [LOG1] and [LOG2] ports in [LOG]. For multiple signal input, set the ports as follows: [LOG1 SERIAL SETTINGS] [LOG] [LOG2 SERIAL SETTINGS]...
  • Page 159 3. ADJUSTMENTS 3.5.9 [NET WORK SETTINGS] menu Open the main menu then select [RADAR INSTAL- LATION] [NEXT] [NETWORK SETTINGS] to open the [NETWORK SETTINGS] menu. Note 1: Network settings should be done while the radar is disconnected from the LAN network, as a standalone radar.
  • Page 160 3. ADJUSTMENTS For the program version 03.**, select network class [CLASS B] or [CLASS C]. If [DE- FAULT] is selected, reboot the system with [CLASS C] and the IP address is set to 192. 168. 000. 001. CLASS B CLASS C* Radar SFID LAN2...
  • Page 161 3. ADJUSTMENTS [RX SETTINGS] Select [ON] to receive the following data signals: • [MISC]: Other equipment data (sensor of engine etc.) • [TGTD]: Target data • [SATD]: Satellite data • [NAVD]: Navigation data • [TIME]: Time • [PROP]: Specified data by manufacturer or user •...
  • Page 162 3. ADJUSTMENTS [DEMO ECHO] Select the type of simulated echo to use. [EG-3000] (Echo Generator), [TT-TEST], [PC] or [EG-4000]. Select [OFF] to deactivate this feature (default: [OFF]). [EAV W/O GYRO] The echo averaging feature can be used without a gyrocompass. Select [ON] to use the feature without a gyrocompass (default: [OFF]).

  • Page 163: How To Control Charts

    3. ADJUSTMENTS [SHUTTLE FERRY SWITCH] Note: This menu is NOT available on the radars with software version 50.**. Select a port to detect a navigation direction of a shuttle ferry (default: [RS-232C]). [ECDIS ROUTE DISPLAY] Note: This menu is NOT available on the radars with software version 50.**. Select [NORMAL] to show the routes with a straight lines, [LEGACY] to show the routes with a curve lines.
  • Page 164 3. ADJUSTMENTS 5. Select [RUN]. The message "PROCESS- ING. PLEASE WAIT." appears, then the [CHART ADMINISTRATION] menu ap- pears. 6. Select [COPY CHART FROM USB DE- VICE] to display the list for data in the USB flash memory. 7. Select the chart data to copy. 8.
  • Page 165 3. ADJUSTMENTS 1. Connect the USB flash memory with chart data on it in the USB drive from the RP board. 2. Press the MENU key to open the main menu. 3. Select [INITIAL SETTINGS]. 4. Select [UPDATE CHART]. The following message appears. 5.
  • Page 166 3. ADJUSTMENTS This page is intentionally left blank. 3-30...
  • Page 167 INPUT/OUTPUT DATA Processor Unit Input and output data are shown in the table below. Note: This radar accepts position data fixed by WGS-84 geodetic datum only. Set the datum to WGS-84 on the EPFS (GPS, etc.) connected to this radar. If other type of datum is input, the error message "DATUM"...
  • Page 168 4. INPUT/OUTPUT DATA Output Data Specification Contents Remarks Radar system IEC 61162-1, RSD, OSD, TLL For ECDIS, PC plotter data RS-232C, IEC 61162-450 TT data** IEC 61162-1, TTD, TTM, TLB For ECDIS IEC 61162-450 Alert handling IEC 61162-1, ALR, ALF, ALC, For BAMS signal IEC 61924-2,...

  • Page 169: Sub Monitor

    4. INPUT/OUTPUT DATA : THS and HDT are IEC 61162-2. All other sentences are IEC 61162-1 ed5. : For retrofit. : To priority of GLL data, see "[PRIORITIZE GLL]" on page 3-21. : NOT for IMO-type radars installed with software version 01.**/03.**. : For C-type radars.
  • Page 170 4. INPUT/OUTPUT DATA Signal Specification Signal and timing Name OP_TRIG_ • Voltage (V): 0 to 12 V • Impedance: 110 • Pulse width (PW): 5 to 15 s (magnetron radar) 8 s (solid state radar) 5 s (ECDIS overlay) OP_VIDEO •...
  • Page 171 APPX. 1 JIS CABLE GUIDE AP-1...

This manual is also suitable for:

Far-2218-bbFar-2228Far-2228-bbFar-2228-nxtFar-2228-nxt-bbFar-2318 ... Show all

Table of Contents
