3900 Dr. Greaves Rd.
FSD60-3 and FSD60-3M COMBINATION FIRE AND SMOKE DAMPER
APPLICATION
The FSD60-3 combination fire and smoke damper is designed to
restrict the passage of flame and resist the passage of smoke. The
FSD60-3 is designed for installation with the blades running hori-
zontally. The standard installation is with the leading edge of the
closed blades within the wall, partition, or masonry floor with a fire
resistance rating of 3 hours or more.
FSD60-3 MAXIMUM UL CLASSIFIED SIZES –
OPPOSED BLADE
Single section vertical – 30"w x 48"h (762 x 1219)
Single section horizontal – 30"w x 48"h (762 x 1219)
Multiple sections vertical – 120"w x 96"h (3048 x 2438)
Multiple sections horizontal – 144"w x 96"h (3658 x 2438)
FSD60-3M MAXIMUM UL CLASSIFIED SIZES –
OPPOSED BLADE
Single section vertical – 30"w x 48"h (762 x 1219)
Single section horizontal – 30"w x 48"h (762 x 1219)
Multiple sections vertical – 120"w x 96"h (3048 x 2438)
Multiple sections horizontal – 120"w x 96"h (3048 x 2438)
Note: Dimensions shown in parentheses ( ) indicate millimeters.
SEE COMPLETE
MARKING ON PRODUCT
California State Fire Marshal Listing No.
FSD60-3 and 60-3M - 3235-0245:0126 NYC
Department Of Building MEA 252-05-E
II-FSD60-3-0121/ Replaces II-FSD60-3-316
•
Kansas City, MO 64030
INSTALLATION INSTRUCTIONS
3 HOUR UL555 RATED
60"w x 96"h (1524 x 2438)
60"w x 96"h (1524 x 2438)
ALL STATED SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE OR OBLIGATION.
•
(816) 761-7476
UL555S LEAKAGE CLASS 1 RATED
INSTALLATION SUPPLEMENTS
Refer to the appropriate Ruskin installation instructions supple-
ments for additional information or special requirements:
• Optional Sealant of Dampers in Fire Rated Wall or Floor Openings
• Transfer Openings and Duct Terminations
• Optional FireStop Material
• Extension of Fire and Combination Fire and Smoke Damper
Sleeves
• Fire and Combination Fire and Smoke Damper Installation in
Concrete Floor with Steel Deck
• Drivemate No. 14880 Breakaway Connection
• Flanged System Breakaway Connections
• TS150 FireStat for "Reopenable" Combination Fire and Smoke
Dampers
• SP100 Switch Package
• EFL Electric Resettable "Fuse" Link
• EFL/SP100 Electric Resettable "Fuse" Link and Switch Package
• PFL Pneumatic Fuse Link
• DSDF Flow Rated Duct Smoke Detector
• DSDN No-Flow Rated Duct Smoke Detector
•
FAX (816) 765-8955
© Ruskin January 2021
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Ruskin FSD60-3
Summary of Contents for Ruskin FSD60-3
- Page 1 UL555S LEAKAGE CLASS 1 RATED APPLICATION INSTALLATION SUPPLEMENTS The FSD60-3 combination fire and smoke damper is designed to Refer to the appropriate Ruskin installation instructions supple- restrict the passage of flame and resist the passage of smoke. The ments for additional information or special requirements: FSD60-3 is designed for installation with the blades running hori- zontally.
- Page 2 1" (25). Do not weld or fasten angles shown on the Flanged Systems Breakaway Connections together at corners of dampers. Ruskin fire/smoke dampers may Supplement. be installed using Ruskin PFMA.
-
Page 3: Vertical Installation
7. Caulking Material (may be on either side of damper frame). 8. PFMA mounting angles 9. Duct/sleeve connection. Floor " (6) Min. © Ruskin January 2021 II-FSD60-3-0121/ Replaces II-FSD60-3-316 ALL STATED SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE OR OBLIGATION. - Page 4 4. Consult the authority having jurisdiction for other acceptable framing methods. Figure 1 Metal Stud Framing Shown Figure 2 © Ruskin January 2021 II-FSD60-3-0121/ Replaces II-FSD60-3-316 ALL STATED SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE OR OBLIGATION.
- Page 5 Note: All actuators must be wired to single Note: Installer to run supply power to thermal device. damper assembly thru thermal device. © Ruskin January 2021 II-FSD60-3-0121/ Replaces II-FSD60-3-316 ALL STATED SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE OR OBLIGATION.
- Page 6 3900 Dr. Greaves Rd. Kansas City, MO 64030 (816) 761-7476 FAX (816) 765-8955 www.ruskin.com...
