Ruskin Air Management Limited
OPERATING AND MAINTENANCE MANUALS.
1.0 INTRODUCTION.
1.1 This manual covers series ES35, ES36,& ES50 Air Control Dampers and
should always be followed. Any deviation from this manual should always
be agreed with the manufacturer Actionair.
1.2 The ES series Air Control Dampers are designed to control airflows in
ducts, wall, ceilings and floors. The product offers numerous control
options and features, as required and specified by contractors, local fire
and or hospital authorities and consultants.
1.3 There are four casing variants: Flanged, square/rectangular, Spigot
square/rectangular, Circular and Flat oval.
1.4 All dampers are manufactured in compliance with the company's quality
control and quality assurance procedures.
2.0 Description and Operation.
2.1 The E35 and 36 series Air Control Dampers have galvanised triple V blade
profile that operate through an opposed blade linkage system within a 1.2
thick galvanised casing.
2.2 The ES0 series Air Control Dampers have Aerofoil Aluminium blades that
operate through an opposed blade linkage system within a 1.2 thick
galvanised casing
ES series
AIR CONTROL DAMPERS.
Advertisement
Table of Contents
Related Manuals for Ruskin actionair ES Series
Summary of Contents for Ruskin actionair ES Series
- Page 1 Ruskin Air Management Limited ES series AIR CONTROL DAMPERS. OPERATING AND MAINTENANCE MANUALS. 1.0 INTRODUCTION. 1.1 This manual covers series ES35, ES36,& ES50 Air Control Dampers and should always be followed. Any deviation from this manual should always be agreed with the manufacturer Actionair.
- Page 2 2.3 The Linkage will provide the blade pivoting system to open and close the blades through a rotation of 90 degrees. Refer to the ES catalogue for the max operating parameters. 2.4 The ES damper can be operated by a manual quadrant or via a ∅ ½ drive spindle for motorisation by Actionair or others.
- Page 3 4.3 It is assumed that the atmosphere which the damper controls meet national and international standard’s for filtration and humidification conditions. 5.0 Maintenance 5.1 The ES series control damper have been designed incorporating galvanised coated mild steel casings and drive components as standard, to give a high degree of resistance to corrosion within filtered temperature and humidity controlled conditions.
