CV200 Dash Camera User Manual

4. Manage the local storage

4.1. TF card contents

The product only accepts the TF card that is running the FAT32 file system. All folders will be
generated automatically after the TF card is mounted successfully. Follow the steps to operate
the folders and files.
1) Insert the TF card into card reader, and place it into the computer's USB port.
2) Open the TF card 's disk path, check the folder content.
* Insert the TF card into computer and format it. You may install the specified tools (e.g., Disk
genius) to format it due to the latest windows 10 doesn't support that filesystem formatting.
*Format the TF card into MS-DOS (FAT) filesystem by "Disk Utility" tool if you are using Mac-
OS'.
*We strongly recommend you to format the TF card by QuCam mobile app for more reliable
performance.
*It's better to format the TF card periodically (e.g., 1 month) to avoid the unknow storage
exception.
*All data will be erased after formatting, please carry out the operation with caution.

4.2. Folder definition

1) /queclink/bin
The folder stores the updating applications files, and the file types are shown as below:
File type
enc
apk
*The files will be removed automatically from the TF card folder after updating successfully.
2) /queclink/config
The folder stores the configuration files that is generated after clicking "send all to device"
button by Manage Tool. File format: CV200_MT_CONFIG_YYYYMMDD.txt.
Symbol
YYYYMMDD
3) /queclink/event
The folder stores the related data of all events. File format: YYYYMMDD_hhmmss_tt.qdat,
each file is generated and separated per event.
Symbol
YYYYMMDD
hhmmss
tt
4) /queclink/track
The folder stores the GPS and G-sensor compositive data.
File format: YYYYMMDD_hhmmss.qsen, a file is generated per hour.
Description
MCU software
Application firmware
Description
indicates year, month, and day
Description
indicates year, month, and day
indicates hour, minutes and second
indicates event types
