Ready to use - interpreting the LED flashing pattern
You can tell the status of the device monitoring the fence from the light patterns of the 3 LEDs on the
front of the device. The Fence Control usually has one of the following three statuses:
Status Fence Control
Internal battery voltage too low
Indicates that the Fence Control's internal battery is not
sufficiently charged for use. Feed the Fence Control with power
and wait until the Fence Control switches to "Network Search"
status.
This is often the case when the Fence control is put into use
after a long time.
Charging time is up to 2 hours.
This voltage is not the same as the supply voltage of your
energizer.
Status Fence Control
Network search
In this status, the Fence Control searches for available mobile
phone base stations and tries to connect to them. Once a
connection to a base station has been established, the Fence
Control switches to the "Ready to use" status.
Make sure a supported and activated SIM card with
deactivated PIN is inserted.
Signing up usually takes up to five minutes.
If problems occur during this step, you can look for
suggested solutions on page 8.
Status Fence Control
Ready to use
The Fence Control is connected to a mobile phone base station
and can now be configured and queried via SMS. In this status,
each of the 3 LEDs must be evaluated separately.
Make sure your phone number is registered in Fence
Control's phone list (see "abo" command on page 9).
While receiving and sending an SMS, the signal strength
indicator flashes 5 times in a very short time.
Other flashing patterns may also occur during a firmware
update
4
