ASROCK A330ION Brochure

A330ION
NVIDIA MCP7A-ION
®
Product Brief
- Intel Dual-Core Atom™ Processor 330 (1.6 GHz)
®
- ASRock DuraCap (2.5 x longer life time), 100%
Japan-made high-quality Conductive Polymer
Capacitors
- Supports Dual Channel DDR3 1066 (Compatible
with DDR3 1333)
- Multi VGA Output options: D-Sub, DVI-D and
HDMI
- Supports Full HD 1080p Blu-ray (BD) / HD-DVD
playback
- 2 x Powered eSATAII/USB Connectors
- EuP Ready
- Supports ASRock Instant Boot, Instant Flash,
ASRock OC Tuner, OC DNA, Good Night LED
- 7.1 CH HD Audio (VIA
- Free Bundle : CyberLink DVD Suite - OEM and
Trial; Creative Sound Blaster X-Fi MB - Trial
The specification is subject to change without notice. The brand and product names are trademarks of their
respective companies. Any configuration other than original product specification is not guaranteed.
PCIE
2.0 x16
slot
VT2020 Audio Codec)
®
ww w.a s ro ck. c o m

Detail Specification

Platform
- Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm
- All Solid Capacitor design (100% Japan-made high-quality
Conductive Polymer Capacitors)
CPU
- Intel Dual-Core Atom
®
- Supports FSB533 MHz
- Supports Hyper-Threading Technology
- Supports Untied Overclocking Technology
- Supports EM64T
Chipset
- NVIDIA MCP7A-ION
®
- Dual Channel DDR3 memory technology
Memory
- 2 x DDR3 DIMM slots
- Supports DDR3 1066/800 non-ECC, un-buffered memory
- Max. capacity of system memory: 4GB
- 1 x PCI Express 2.0 x16 slot
Expansion Slot
- Integrated NVIDIA
Graphics
- DX10 VGA, Pixel Shader 4.0
- Max. shared memory 512MB
- Multi VGA Output options: D-Sub, DVI-D and HDMI
- Supports HDMI Technology with max. resolution up to
1920x1200 (1080P)
- Supports Dual-link DVI with max. resolution up to 2560x
1600 @ 75Hz
- Supports D-Sub with max. resolution up to 1920x1440
@ 75Hz
- Supports HDCP function
- Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback
Audio - 7.1 CH HD Audio (VIA
LAN
- Gigabit LAN 10/100/1000 Mb/s
- Giga PHY RTL8211CL
- Supports Wake-On-LAN
Rear Panel I/O
I/O Panel
- 1 x PS/2 Keyboard Port
- 1 x VGA/D-Sub Port
- 1 x VGA/DVI-D Port
- 1 x HDMI Port
- 1 x Optical SPDIF Out Port
- 4 x Ready-to-Use USB 2.0 Ports
- 2 x Powered eSATAII/USB Connectors
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
- HD Audio Jack: Rear Speaker / Central / Bass / Line in /
Front Speaker / Microphone
Connector
- 4 x Serial ATAII 3.0 Gb/s connectors, support RAID (RAID 0
and RAID 1), NCQ, AHCI and "Hot Plug" functions
- 1 x IR header
- 1 x COM port header
- 1 x HDMI_SPDIF header
- CPU/Chassis FAN connector
- 24 pin ATX power connector
- Front panel audio connector
- 2 x USB 2.0 headers (support 4 USB 2.0 ports)
BIOS Feature
- 8Mb AMI Legal BIOS
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 Support
- VCCM Voltage Multi-adjustment
- Drivers, Utilities, AntiVirus Software (Trial Version),
Support CD
ASRock Software Suite (CyberLink DVD Suite - OEM
and Trial; Creative Sound Blaster X-Fi MB - Trial)
- ASRock OC Tuner
Unique Feature
- Instant Boot
- ASRock Instant Flash
- ASRock OC DNA
- Hybrid Booster:
- CPU Frequency Stepless Control
- ASRock U-COP
- Boot Failure Guard (B.F.G.)
- Good Night LED
Hardware Monitor - CPU Temperature Sensing
- Chassis Temperature Sensing
- CPU Fan Tachometer
- Chassis Fan Tachometer
- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore
OS
- Microsoft Windows
®
XP / XP 64-bit compliant
Certifications
- FCC, CE, WHQL
- EuP Ready (EuP ready power supply is required)
Accessories - Quick Installation Guide, Support CD, I/O Shield
- 1 x Bundled Intel
- 2 x SATA Data Cables (Optional)
- 1 x SATA 1 to 1 Power Cable (Optional)
Processor 330 (1.6 GHz)
TM
GeForce 9 Series
®
VT2020 Audio Codec)
®
7 / 7 64-bit / Vista / Vista 64-bit /
® TM TM
Dual-Core Atom Processor 330
® TM
