A330GC
®
Intel
945GC+ ICH7 Chipsets
Product Brief
Standard Mini-ITX motherboard for
Mini-ITX and Micro-ATX case
- Solid Capacitor for CPU power
®
- Supports Intel
Dual-Core Atom
330
- Supports Dual Channel DDR2 533, Max.
capacity up to 4GB
®
- Intel
Graphics Media Accelerator 950,
DirectX 9.0 and Max. shared memory 224MB
- PCIE Gigabit LAN
- Supports ASRock Instant Boot, Instant Flash,
Smart BIOS, ASRock OC Tuner
The specification is subject to change without notice. The brand and product names are trademarks of their
respective companies. Any configuration other than original product specification is not guaranteed.
Detail Specification
Platform
CPU
Chipset
Memory
Expansion Slot
Graphics
Audio
LAN
Rear Panel I/O
Connector
BIOS Feature
TM
Processor
Support CD
Unique Feature
Hardware Monitor
OS
Certifications
Accessories
ww w.a s ro ck. c o m
- Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm
- Solid Capacitor for CPU power
®
TM
- Intel
Dual-Core Atom
Processor 330 (1.6 GHz)
- Supports FSB533 MHz
- Supports Hyper-Threading Technology
- Supports Untied Overclocking Technology
- Supports EM64T CPU
- Northbridge: Intel
®
945GC
- Southbridge: Intel
®
ICH7
- Dual Channel DDR2 memory technology
- 2 x DDR2 DIMM slots
- Supports DDR2 533 non-ECC, un-buffered memory
- Max. capacity of system memory: 4GB
- 1 x PCI slot
- Intel
®
Graphics Media Accelerator 950
- Pixel Shader 2.0, DirectX 9.0
- Max. shared memory 224MB
- 5.1 CH Windows
®
Vista
TM
Premium Level HD Audio
(Realtek ALC662 Audio Codec)
- PCIE x1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111DL
- Supports Wake-On-LAN
I/O Panel
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x Parallel Port (ECP/EPP Support)
- 1 x Serial Port: COM1
- 1 x VGA Port
- 4 x Ready-to-Use USB 2.0 Ports
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and
SPEED LED)
- HD Audio Jack: Line in / Front Speaker / Microphone
- 2 x SATAII 3.0 Gb/s connectors
(No support for RAID and "Hot Plug" functions)
- 1 x ATA100 IDE connector (supports 2 x IDE devices)
- CPU/Chassis FAN connector
- 24 pin ATX power connector
- CD in header
- Front panel audio connector
- 2 x USB 2.0 headers (support 4 USB 2.0 ports)
- 4Mb AMI BIOS
- AMI Legal BIOS
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 Support
- CPU, VCCM, NB, VTT Voltage Multi-adjustment
- Supports Smart BIOS
- Drivers, Utilities, AntiVirus Software (Trial Version)
- ASRock OC Tuner
- Instant Boot
- ASRock Instant Flash
- Hybrid Booster:
- CPU Frequency Stepless Control
- ASRock U-COP
- Boot Failure Guard (B.F.G.)
- CPU Temperature Sensing
- Chassis Temperature Sensing
- CPU Fan Tachometer
- Chassis Fan Tachometer
- CPU Quiet Fan
- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore
- Microsoft
®
Windows
®
2000 / XP / XP 64-bit / Vista
Vista
TM
64-bit compliant
- FCC, CE, WHQL
- Quick Installation Guide, Support CD, I/O Shield
®
TM
- 1 x Bundled Intel
Dual-Core Atom
- 1 x ATA 100 Cable
- 1 x SATA Data Cable (Optional)
TM
/
Processor 330
