30" slide-in electric range
Hide thumbs Also See for SLER 30423SS:

Advertisement

30" Slide-In Electric Range
Safety & Installation Instructions
SLER 30423SS
WARNING: Read all safety
instructions before using the
product. If the information in
this manual is not followed
exactly, a fire or explosion
may result causing property
damage, personal injury or
death.
285.6003.25 / R.AD / 27.09.2023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SLER 30423SS and is the answer not in the manual?

Questions and answers

Summary of Contents for Beko SLER 30423SS

  • Page 1 Safety & Installation Instructions WARNING: Read all safety instructions before using the product. If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or death. SLER 30423SS 285.6003.25 / R.AD / 27.09.2023...
  • Page 2 TO PREVENT TIPPING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or death. DO NOT OPERATE THE RANGE WITHOUT ANTI-TIP DEVICE IN PLACE AND ENGAGED This appliance is intended for normal household use only. It is not approved for outdoor or other non-household uses (including sea or air-going vessels).
  • Page 3 PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE INSTALLATION OR USING YOUR APPLIANCE ! SAVE THESE INSTRUCTIONS Save these instructions for the local electrical inspectors use. This product can only be used in the rooms which incorporates a properly adjusted and functioning Carbon Monoxide sensor. Make sure the Carbon Monoxide sensor works properly and its maintenance done frequently.
  • Page 4: Technical Information

    TECHNICAL INFORMATION General Overall Height 36" (914 mm) Overall Width 29 - 13/16" (757 mm) Overall Depth 26 - 3/4" (679 mm) Total electric power 12.6 kW / 9,5 kW Electrical connection 120/240 V~;60 Hz 2AC~N Cable type / Cross section / Fuse SRDT 10/3 + 12/1 AWG / min.
  • Page 5: Important Safety Information

    IMPORTANT SAFETY INFORMATION Be sure to observe all listed warnings • If the supply cord damaged, it must be replaced by a special cord or assembly and cautions. Look particularly for the available from the manufacturer or icons with exclamation marks inside. its service agent or similarly qualified The information icon will also provide persons.
  • Page 6 IMPORTANT SAFETY INFORMATION Warning: Depending on the usage, the Warning: Accessible parts may become hob surface may cool down at varying hot during use. Young children should periods of time. Hob surface may be be kept away. hot even if the indicator lamps are not Warning: Do not use harsh abrasive illuminated.
  • Page 7 IMPORTANT SAFETY INFORMATION • Do Not Heat Unopened Food Containers Warning: Metallic objects such as build-up of pressure may cause knives, forks, spoons and lids should container to burst and result in injury. not be placed on the hob surface since they can get hot.
  • Page 8 IMPORTANT SAFETY INFORMATION • Ensure that no flammable materials are immersed in water. adjacent to the appliance as the sides • Do not use the oven for a storage area. be-come hot during use. Items stored in an oven can ignite. Caution: Do not store or use flammable Warning: Flammable materials should materials in an oven or near the cook...
  • Page 9 IMPORTANT SAFETY INFORMATION • Do not leave empty pots or pans on into/from your oven. Do not let burners that are switched on. They might potholder touch hot heating elements. get damaged. Warning: Never cover any slots, holes or • Since it may be hot, do not leave plastic passages in the oven bottom or cover or aluminum dishes on the surface of an entire rack with materials such as...
  • Page 10 IMPORTANT SAFETY INFORMATION SAFETY FOR CHILDREN SAFETY FOR ELECTRICITY Warning: Do Not leave children alone Warning: Before installing, turn power Children should not be left alone or OFF at the service panel. Lock service unattended in area where appliance is panel to prevent power from being in use.
  • Page 11 IMPORTANT SAFETY INFORMATION FUTURE TRANSPORTATION • This appliance is not intended to use at mobile homes, recreational vehicles. • Do not carry out cleaning or maintenance Warning: Do not obstruct the flow of ventilation air. operations on the appliance without having previously disconnected it from •...
  • Page 12: Installation

    INSTALLATION SAFETY FOR CHILDREN INSTALLATION AND CONNECTION Material damage! Material damage! Clearances & Dimensions...
  • Page 13 INSTALLATION...
  • Page 14 INSTALLATION ANTI-TIP STABILITY DEVICE Caution: To eliminate the risk of burns or fire by reaching over heated surface INSTALLATION INSTRUCTIONS units, cabinet storage space located above the surface units should be avoided. If cabinet storage is to be Warning: Verify the anti-tip device has provided, the risk can be reduced by been properly installed and engaged.
  • Page 15 INSTALLATION...
  • Page 16 INSTALLATION ANTI-TIP STABILITY DEVICE Bracket Installation Option 2 INSTALLATION INSTRUCTIONS 1. Adjust your oven feets according to your counter. 2. Measure the dimension ‘A’ in Figure 3 . Warning: Verify the anti-tip device has been properly installed and engaged. 3. Mount the bracket to the wall as •...
  • Page 17 INSTALLATION...
  • Page 18 INSTALLATION HOW TO MOVE THE APPLIANCE Warning: Electrical shock hazard! Use extreme caution when drilling holes into the wall or floor. There may Movement of your appliance is most be concealed electrical wires located easily achieved by lifting the front as behind the wall or under the floor.
  • Page 19 INSTALLATION CONNECTION TO THE MAIN Observe all governing codes and local SUPPLY ordinances • A 3 wire or 4 wire single phase 120/240 or 120/208 Volt, 60 Hz AC only electrical Warning: Electrical shock hazard! supply is required on a separate circuit Electrical installation must comply with fused on both sides of the line (red and national and local codes.
  • Page 20 INSTALLATION • Amper cord is used it must be marked 3 & 4 -wire electrical wall receptacle for use with a 1 3/8 inches (35 mm) types & recommended mounting diameter opening. Cord must have either orientation on wall 3 or 4 conductors to match electric receptacle (Use copper or Aluminum •...
  • Page 21 INSTALLATION Power cord strain relief installation • Purchase a strain relief before installation. 1. Using the 1-1/8 in. or 7/8 in. diameter opening insert the strain relief and power cord through the opening and secure the strain relief as directed in this instructions.
  • Page 22 INSTALLATION Conduit Installation 3 & 4-wire permanent wire connections • Purchase a squeeze connector Warning: For 3-wire permanent matching the diameter of the conduit connection read carefully and follow and assemble it in the hole. Insert the steps 2 and 5 below. conduit through the squeeze connector Warning: For 4-wire permanent and tighten.
  • Page 23 INSTALLATION 3 wire connection figure 4 wire connection figure 1. Terminal block 1. Terminal block 2. Squeeze connector 2. Squeeze connector 3. Washer 3. Washer 4. Nut 4. Nut 5. Grounding screw 5. Grounding screw BK. Black BK. Black WH. White WH.
  • Page 24: Package Contents And Accessories

    PACKAGE CONTENTS AND ACCESSORIES HEIGHT-ADJUSTABLE Accessories supplied can vary depending on the product model. Not TELESCOPIC ROLLER-RACK every accessory described in the user WITH WIRE SHELF manual may exist on your product. • Used for roasting and for easily placing the food to be baked, roasted or cooked OWNER'S MANUAL in casserole dishes to the desired rack.
  • Page 25 PACKAGE CONTENTS AND ACCESSORIES How to reattach the wire shelf with How to remove the wire shelf with telescopic roller-rack telescopic roller-rack • To reattach the wire self with telescopic • You can remove the wire self with rails, the procedures applied when telescopic rails by first lifting it up and removing it must be repeated from the then pulling it towards you.
  • Page 26 NOTES...
  • Page 27 NOTES...
  • Page 28 1-888-352 BEKO (2356) beko.com/us-en ©2022 Beko U.S., Inc. All rights reserved.
