- Page 1 Doc. no. J**-OMQ0032-B PRODUCT NAME ＦＬＯＡＴＩＮＧ ＪＯＩＮＴ MODEL/ Series ＪＣ ＳＥＲＩＥＳ...
- Page 2 Contents 1. Safety Instrctions 2. Specifications 3. Construction 4. Replacement Parts...
- Page 3 Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations.
- Page 4 Safety Instructions Caution We develop, design, and manufacture our products to be used for automatic control equipment, and provide them for peaceful use in manufacturing industries. Use in non-manufacturing industries is not covered. Products we manufacture and sell cannot be used for the purpose of transactions or certification specified in the Measurement Act.
- Page 5 Play approx. 0.06mm in axial center direction. (3) Play in the axial direction JC series has play in the axial direction. (Default: 0.06 mm or less) When positioning the driven object, avoid the influence of play using a knock pin or external stopper.
- Page 6 Installation Warning ！ (1) Maintenance space Allow sufficient space for maintenance and inspection. (2) When screwing the male threads of the rod into the female threads of the socket or the case, make sure that it does not contact the stud sphere. When the rod is screwed into the socket or case female thread, mount the rod end so that it does not contact the stud sphere.
- Page 7 Operating Environment ！ Warning (1) Avoid using in a location where the product could be splashed by liquids such as coolants and water. Also, avoid locations where exposed to a large amount of dust or foreign matter. If liquid or dust gets inside the floating joint from the gap of the dust cover, it may cause a malfunction.
- Page 8 2. Specifications JC series Maximum Applicable Applicable Allowable operating cylinder bore size eccentricity Rotating angle tension and nominal Model compression I.D. thread size force Standard JC20-8-125 M8×1.25 JC30-10-125 M10×1.25 25・32 +/-5 JC40-14-150 M14×1.5 1250 0.75 JC63-18-150 M18×1.5 3100 50・63 Semi-standard JC20-8-100 M8×1...
- Page 9 4. Replacement part (1) Dust cover When the dust cover is broken or deteriorated, please order the replacement with part number below. Only the basic type dust cover is replaceable. Part no. for dust Applicable models cover P215215 JC20 P215225 JC25,JC30,JC32 P215235 JC40...
- Page 10 Revision history A: Revision to (3) and addition to (4) on page 5, Revision to (1) and part numbers corrected in (2) on page 9 B: Change of the note on the Safety Instructions. 2024.3 Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 URL https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer.
