MOTHERBOARD
775V88

User Manual

Version 1.0
Published August 2004
Copyright©2004 ASRock INC. All rights reserved.

Advertisement

Table of Contents
loading

Related Manuals for ASROCK 775V88

Summary of Contents for ASROCK 775V88

  • Page 1: User Manual

    MOTHERBOARD 775V88 User Manual Version 1.0 Published August 2004 Copyright©2004 ASRock INC. All rights reserved.

  • Page 2: Copyright Notice

    (including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock has been advised of the possibility of such damages arising from any defect or error in the manual or product.

  • Page 3: Table Of Contents

    2.6 Onboard Headers and Connectors ......18 2.7 Serial ATA (SATA) Hard Disks Installation ..... 21 2.8 Hot Plug and Hot Swap Functions for SATA HDDs ..21 2.9 Making An SATA Driver Diskette ........22 3. BIOS SETUP UTILITY ......... 23 3.1 Introduction ..............
  • Page 4 4.1 Install Operating System ..........38 4.2 Support CD Information ..........38 4.2.1 Running Support CD ..........38 4.2.2 Drivers Menu ............38 4.2.3 Utilities Menu ............38 4.2.4 “LGA 775 CPU Installation Live Demo” Program .. 38 4.2.5 Contact Information ..........38...

  • Page 5: Introduction

    ASRock’s commitment to quality and endurance. In this manual, chapter 1 and 2 contain introduction of the motherboard and step-by- step guide to the hardware installation. Chapter 3 and 4 contain the configuration guide to BIOS setup and information of the Support CD.

  • Page 6: Specifications

    1.2 Specifications Platform: ATX Form Factor: 12.0-in x 9.2-in, 30.5 cm x 23.4 cm CPU: 775-Pin Socket Supporting Intel ® Pentium ® 4 / Celeron ® processor (in 775-land LGA package) Chipsets: North Bridge: VIA PT880, FSB @ 800/533 MHz, ®...
  • Page 7 To improve heat dissipation, remember to spray thermal grease between the CPU and the heatsink when you install the PC system. Do NOT use a 3.3V AGP card on the AGP slot of this motherboard! It may cause permanent damage! Power Management for USB 2.0 works fine under Microsoft...

  • Page 8: Motherboard Layout

    775-Pin CPU Socket Clear CMOS Jumper (CLRCMOS1) North Bridge Controller USB 2.0 Header (USB67, Blue) 2 x 184-pin DDR DIMM Slots Floppy Connector (FLOPPY1) (Dual Channel A: DDR1, DDR3; Blue) Internal Audio Connector: CD1 (Black) 2 x 184-pin DDR DIMM Slots JR1 Jumper / JL1 Jumper (Dual Channel B: DDR2, DDR4;...

  • Page 9: Asrock I/O Plus

    2 x USB 2.0 Ports (USB0, USB1) RJ-45 Port 2 x USB 2.0 Ports (USB2, USB3) Line In (Light Blue) Serial Port: COM1 Line Out (Lime) PS/2 Keyboard Port (Purple) Microphone (Pink) PS/2 Mouse Port (Green) 2 x Shared USB 2.0 Ports (USB4, USB5)

  • Page 10: Installation

    2. Installation 775V88 is an ATX form factor (12.0-in x 9.2-in, 30.5 cm x 23.4 cm) motherboard. Before you install the motherboard, study the configuration of your chassis to en- sure that the motherboard fits into it. Pre-installation Precautions Take note of the following precautions before you install motherboard com- ponents or change any motherboard settings.

  • Page 11: Cpu Installation

    Before you insert the 775-LAND CPU into the socket, please check if the CPU surface is unclean or if there is any bent pin on the socket. Do not force to insert the CPU into the socket if above situation is found.
  • Page 12 PnP cap to assist in removal. It is recommended to use the cap tab to handle and avoid kicking off the PnP cap. Step 4. Close the socket: Step 4-1.

  • Page 13: Installation Of Cpu Fan And Heatsink

    CPU and the heatsink to improve heat dissipation. Ensure that the CPU and the heatsink are securely fastened and in good contact with each other. Then connect the CPU fan to the CPU_FAN connector (CPU_FAN1, see page 8, No.

  • Page 14: Installation Of Memory Modules (Dimm)

    (the same brand, speed, size and chip- type) DDR DIMM pair in the slots of the same color. In other words, you have to install identical DDR DIMM pair in Dual Channel A (DDR1 and DDR3; Blue slots;...

  • Page 15: Installing A Dimm

    DIMMs or the system components. Step 1. Unlock a DIMM slot by pressing the retaining clips outward. Step 2. Align a DIMM on the slot such that the notch on the DIMM matches the break on the slot. notch break...

  • Page 16: Expansion Slots (Pci And Agp Slots)

    PCI slots: PCI slots are used to install expansion cards that have the 32-bit PCI interface. AGP slot: The AGP slot is used to install a graphics card. The ASRock AGP slot has a special design of clasp that can securely fasten the inserted graphics card.

  • Page 17: Jumpers Setup

    Note: To select +5VSB, it requires 2 Amp and higher standby current provided by power supply. (see p.8, No. 21) (see p.8, No. 21) Note: If the jumpers JL1 and JR1 are short, both the front panel and the rear panel audio connectors can work. Clear CMOS (CLRCMOS1, 2-pin jumper) 2-pin jumper (see p.8, No.

  • Page 18: Onboard Headers And Connectors

    FLOPPY1 Pin1 (see p.8, No. 19) the red-striped side to Pin1 Note: Make sure the red-striped side of the cable is plugged into Pin1 side of the connector. Primary IDE Connector (Blue) Secondary IDE Connector (Black) (39-pin IDE1, see p.8, No. 8) (39-pin IDE2, see p.8, No.
  • Page 19 ASRock I/O Plus provides you 6 ready-to-use USB 2.0 ports on (9-pin USB67) DUMMY the rear panel. If the rear USB (see p.8, No. 18) ports are not sufficient, this USB 2.0 header is available to USB_PWR support 2 extra USB 2.0 ports.
  • Page 20 (see p.8, No. 14) CHA_FAN_SPEED ground pin. CPU Fan Connector You may connect either a 3-pin or a 4-pin CPU fan cable to this (4-pin CPU_FAN1) connector, then match the black (see p.8, No. 29) wire to the ground pin.

  • Page 21: Serial Ata (Sata) Hard Disks Installation

    STEP 3: Connect one end of the SATA data cable to the motherboard’s SATA connector. STEP 4: Connect the other end of the SATA data cable to the SATA hard disk. 2.8 Hot Plug and Hot Swap Functions for SATA HDDs 775V88 motherboard supports Hot Plug and Hot Swap functions for SATA Devices.

  • Page 22: Making An Sata Driver Diskette

    2.9 Making An SATA Driver Diskette If you want to install Windows 2000 or Windows XP on your SATA HDDs, you will need to make an SATA driver diskette before you start the OS installation. STEP 1: Insert the ASRock Support CD into your optical drive to boot your system.

  • Page 23: Bios Setup Utility

    Power-On-Self-Test (POST) to enter the BIOS SETUP UTILITY, otherwise, POST will continue with its test routines. If you wish to enter the BIOS SETUP UTILITY after POST, restart the system by pressing <Ctl> + <Alt> + <Delete>, or by pressing the reset button on the system chassis.

  • Page 24: Navigation Keys

    To save changes and exit the BIOS SETUP UTILITY <ESC> To jump to the Exit Screen or exit the current screen 3.2 Main Screen When you enter the BIOS SETUP UTILITY, the Main screen will appear and display the system overview BIOS SETUP UTILITY BIOS SETUP UTILITY...

  • Page 25: Advanced Screen

    3.3 Advanced Screen In this section, you may set the configurations for the following items: CPU Configuration, Chipset Configuration, ACPI Configuration, IDE Configuration, PCIPnP Configuration, Floppy Configuration, SuperIO Configuration, and USB Configuration. BIOS SETUP UTILITY H/W Monitor Boot Security Exit...

  • Page 26: Chipset Configuration

    If it shows “Locked”, then the item Ratio CMOS Set- ting will be hidden. If you use the ratio value to time the CPU frequency, it will be equal to the core speed of the installed processor.
  • Page 27 The default value of this feature is set to [Auto]. If you install an 8X-AGP card on this motherboard, you may select [Auto], [8X] or [4X] as the AGP mode. If the installed AGP card is a 4X-AGP card, then you may set the AGP mode as [Auto], [4X], [2X], or [1X].

  • Page 28: Acpi Configuration

    Use this item to enable or disable COM Port Modem to turn on the system from the power-soft-off mode. PCI Devices Power On Use this item to enable or disable PCI devices to turn on the system from the power-soft-off mode. PS/2 Keyboard Power On Use this item to enable or disable PS/2 keyboard to turn on the system from the power-soft-off mode.

  • Page 29: Ide Configuration

    [Disabled], [Primary], [Secondary], [Both]. IDE Device Configuration You may set the IDE configuration for the device that you specify. We will use the “Primary IDE Master” as the example in the following instruction, which can be applied to the configurations of “Primary IDE Slave”, “Sec- ondary IDE Master”, and “Secondary IDE Slave”...
  • Page 30 [ARMD]: This is used for IDE ARMD (ATAPI Removable Media Device), such as MO. LBA/Large Mode Use this item to select the LBA/Large mode for a hard disk > 512 MB under DOS and Windows; for Netware and UNIX user, select [Disabled] to disable the LBA/Large mode.

  • Page 31: Pcipnp Configuration

    Exit v02.54 (C) Copyright 1985-2003, American Megatrends, Inc. PCI Latency Timer The default value is 32. It is recommended to keep the default value unless the installed PCI expansion cards’ specifications require other settings. PCI IDE BusMaster Use this item to enable or disable the PCI IDE BusMaster feature.

  • Page 32: Super Io Configuration

    Use this item to enable or disable floppy drive controller. Serial Port Address Use this item to set the address for the onboard serial port or disable it. Configuration options: [Disabled], [3F8 / IRQ4], [2F8 / IRQ3], [3E8 / IRQ4], [2E8 / IRQ3].

  • Page 33: Usb Configuration

    OnBoard Game Port Use this item to enable the Game Port or disable it. OnBoard MIDI Port Use this itme to select the address for the MIDI Port or disable it. Configura- tion options: [Disabled], [300], and [330]. 3.3.8 USB Configuration...

  • Page 34: Hardware Health Event Monitoring Screen

    3.4 Hardware Health Event Monitoring Screen In this section, it allows you to monitor the status of the hardware on your system, including the parameters of the CPU temperature, motherboard temperature, CPU fan speed, chassis fan speed, and the critical voltage.

  • Page 35: Boot Settings Configuration

    Boot From Network Use this item to enable or disable the Boot From Network feature. Boot Up Num-Lock If this item is set to [On], it will automatically activate the Numeric Lock function after boot-up. 3.5.2 Boot Device Priority In this section, you may specify the boot sequence from the available devices in your system.

  • Page 36: Security Screen

    3.6 Security Screen In this section, you may set or change the supervisor/user password for the system. For the user password, you may also clear it. BIOS SETUP UTILITY Main Advanced H/W Monitor Boot Security Exit Security Settings Install or Change the password.

  • Page 37: Exit Screen

    BIOS SETUP UTILITY. Discard Changes and Exit When you select this option, it will pop-out the following message, “Dis- card changes and exit setup?” Select [OK] to exit the BIOS SETUP UTILITY without saving any changes. Discard Changes When you select this option, it will pop-out the following message, “Dis-...

  • Page 38: Software Support

    “LGA 775 CPU Installation Live Demo”. We hope you may check this live demo program before you start the installation of LGA 775 CPU in order to reduce the risks of CPU and motherboard damages caused by any improper handling. To see this Live ®...
