McConnel Twose Series Operator's Manual
Balehandler
Hide thumbs
Also See for Twose Series:
- Operations & parts manual (44 pages) ,
- Instruction & parts manual (39 pages) ,
- Operator's manual (34 pages)
Subscribe to Our Youtube Channel
Related Manuals for McConnel Twose Series
Summary of Contents for McConnel Twose Series
- Page 1 Twose Series BALEHANDLER Models: ABH04 / ABH04E8 Operator Manual Publication 5290 June 2016...
- Page 2 VERIFICATION OF WARRANTY REGISTRATION DEALER WARRANTY INFORMATION & REGISTRATION VERIFICATION It is imperative that the selling dealer registers this machine with McConnel Limited before delivery to the end user – failure to do so may affect the validity of the machine warranty.
-
Page 3: Warranty Policy
12 months, unless a different period is specified. 1.02. All spare parts supplied by McConnel Ltd and purchased by the end user are warranted to be free from defects in material and workmanship from the date of sale to the original purchaser for a period of 6 months. -
Page 4: Limitation Of Liability
McConnel Ltd web site and confirms the registration to the purchaser by completing the confirmation form in the operator’s manual. 2.02. Any fault must be reported to an authorised McConnel Ltd dealer as soon as it occurs. Continued use of a machine, after a fault has occurred, can result in further component failure for which McConnel Ltd cannot be held liable. -
Page 5: Declaration Of Conformity
DECLARATION OF CONFORMITY Conforming to EU Machinery Directive 2006/42/EC McCONNEL LIMITED, Temeside Works, Ludlow, Shropshire SY8 1JL, UK Hereby declare that: The Product; Tractor Mounted Bale Handling Attachment Product Code; TBAL Serial No. & Date ………………………………… Type ………………………… Manufactured in; United Kingdom Complies with the required provisions of the Machinery Directive 2006/42/EC The machinery directive is supported by the following harmonized standards;... - Page 6 No responsibility will be accepted by McConnel Limited for any injury, damage or loss arising from the improper use or lack of maintenance of any machinery supplied by them...
- Page 8 No responsibility will be accepted by McConnel Limited for any injury, damage or loss arising from the improper use or lack of maintenance of any machinery supplied by them or from any failure of the user to comply with all instructions published by Tractor or Loader manufacturers, particularly with regard to maximum load capacities, tyre pressures and stability, or with instructions and regulations pertaining to Tractor Cabs.
- Page 9 5290 2- GENERAL INFORMATION 0604 *HQHUDO 7KH $%+ %DOH +DQ GOHU LV G HVLJQHG WR KDQGOHVWDFN URXQG ZUDSSHG RU X QZUDSSHG EDOHV 7KH UROOLQJ DFWLRQ RI WK H EDOH WLQHV HOLPLQDWHV GDPDJH WR SODVWLF ZUDSSH G EDOHV FDXVHG E\ GUDJ EHWZHHQ WKH V XUIDFHV $OWKRXJK GHVLJQHG IRU P RXQWLQJ RQ D VXLWDEOH IURQW ORDGHU WKH KDQGOHU PD\ DOVR EH ILWWHG RQ WKH WUDFWRU OLQNDJH XVLQJ VXLWDEOH EUDFNHWV 7KH $%+ %DOH +DQGOHU 7KH EDOH KDQGOHU IHDWXUHV VOLGH RII UROOHUV WR UHYHDO WKH VSLNHV :LWK WKH UROOHUV DWWDFKHG WKH PDFKLQH LV GHVLJQHG WR OLIW RQH...
-
Page 10: Health And Safety
5290 3 - SAFETY 0604 SAFETY NOTES AND WARNINGS Throughout the handbook the following sub headings are used to draw attention to various points of importance. This is to draw attention to very important instructions which MUST be followed precisely to avoid injury or death. CAUTION This is used to draw attention to instructions which MUST be followed to avoid damage to operator, machine, process or the environment. - Page 11 5290 3 - SAFETY 0604 Never drive machinery at speeds that could cause danger to other persons or properties, or in a manner that may cause accidents. UNSUPPORTED MACHINES Always ensure the machine is fully supported before getting underneath or working on the machine. Use suitable blocks or packing.
-
Page 12: Machine Capacity
5290 3 - SAFETY 0604 HIGHWAY USE When transporting machinery on the Highways the “Local Highways Department” should be consulted for approval and notification, as rules and regulations vary from local authority area to area. Allow time for walkers and cyclists to clear site. Also when using on the Highway consult the ‘Lighting Regulations’ for correct procedures. - Page 13 5290 3 - SAFETY 0604 Do not carry bales in a position that will obstruct your vision Lower loader while transporting bales. Ensure that the tractor and loader are suitably counterbalanced CAUTION ‘PARKING UP’ MACHINE When machine is being removed and being ‘parked up’ it is essential that a good firm base and level site be found. Always chock and prop machine to ensure a good firm position to leave parked.
-
Page 14: General Instructions
5290 3 - SAFETY 0604 GENERAL INSTRUCTIONS Before attaching any machine to a tractor or loader make sure that implement is still standing firmly on good solid - level site as it will be, providing unit was previously parked correctly. - Check that any wheels are ‘chocked’... - Page 15 5290 4 - FITTING BALE HANDLER TO A LOADER 0604 General Before starting ensure that the machine is on a flat, level hard standing with plenty of room to manoeuvre. Measure the centre distance of both loader arms and crowd links. Position the lift b rackets (not provided) on th e bale handler frame to suit the dimension above and ensure they are equal distance from each end of the frame.
-
Page 16: Maintenance
5290 5 - MAINTENANCE AND STORAGE 0604 MAINTENANCE Regular maintenance will prolong the life of the machine and ensure it remains in a safe condition. DAILY Grease all pivot points. Check all nuts and bolts for tightness WEEKLY Check hydraulic ram for leaks and hoses for damage and wear and replace if necessary. EVERY 2 MONTHS Check plastic bushes for wear. - Page 18 McConnel Limited, Temeside Works, Ludlow, Shropshire SY8 1JL. England. Telephone: 01584 873131. Facsimile: 01584 876463. www.mcconnel.com...
