- Page 1 Twose Series Reach Arms TA320 & TA420 Operation Manual Publication 653 May 2016...
- Page 2 VERIFICATION OF WARRANTY REGISTRATION DEALER WARRANTY INFORMATION & REGISTRATION VERIFICATION It is imperative that the selling dealer registers this machine with McConnel Limited before delivery to the end user – failure to do so may affect the validity of the machine warranty.
- Page 3 12 months, unless a different period is specified. 1.02. All spare parts supplied by McConnel Ltd and purchased by the end user are warranted to be free from defects in material and workmanship from the date of sale to the original purchaser for a period of 6 months.
- Page 4 McConnel Ltd web site and confirms the registration to the purchaser by completing the confirmation form in the operator’s manual. 2.02. Any fault must be reported to an authorised McConnel Ltd dealer as soon as it occurs. Continued use of a machine, after a fault has occurred, can result in further component failure for which McConnel Ltd cannot be held liable.
- Page 5 DECLARATION OF CONFORMITY Conforming to EU Machinery Directive 2006/42/EC McCONNEL LIMITED, Temeside Works, Ludlow, Shropshire SY8 1JL, UK Hereby declare that: The Product; Tractor Mounted Hedgecutter / Grass Mower Product Code; TW32 Serial No. & Date ………………………………… Type ………………………… Manufactured in; United Kingdom Complies with the required provisions of the Machinery Directive 2006/42/EC The machinery directive is supported by the following harmonized standards;...
- Page 6 DECLARATION OF CONFORMITY Conforming to EU Machinery Directive 2006/42/EC McCONNEL LIMITED, Temeside Works, Ludlow, Shropshire SY8 1JL, UK Hereby declare that: The Product; Hydraulic Arm Mounted Flail Head Product Code; TWHD Serial No. & Date ………………………………… Type ………………………… Manufactured in; United Kingdom Complies with the required provisions of the Machinery Directive 2006/42/EC The machinery directive is supported by the following harmonized standards;...
-
Page 8: Table Of Contents
LIST OF CONTENTS Page No. General Information Features and Specifications Safety Information Tractor Requirements Vehicle/Tractor Preparation Closed Centre Conversion Delivery & Pre-Attachment Attachment to Tractor Stabilizer Adjustment PTO Driveshaft Installation Fitting Operator Control Units Hydraulic Oil Flail Motor Hose Installation Detachment Rotor Operation Cable Controls... -
Page 10: General Information
Always read this manual before fitting or operating the machine – whenever any doubt exists contact your dealer or the McConnel Service Department for advice and assistance. Use only Twose Classic Line Parts on Twose Classic Line Equipment and Machines DEFINITIONS –... -
Page 11: Features And Specifications
FEATURES & SPECIFICATIONS All Models ○ Three-point Linkage Mounting System ○ Right or Left Hand Build Options ○ Front Mount Build Options ○ Low Power Requirement ○ High Performance Hydraulic System ○ Parallel Arm Geometry ○ Hydraulic Safety Breakaway ○ Operator Guard ○... -
Page 13: Safety Information
SAFETY SECTION This machine has the potential to be extremely dangerous - in the wrong hands it can kill or maim; It is therefore imperative that both owner and operator of the machine reads and understands the following section to ensure they are fully aware of the dangers that do, or may exist, and their responsibilities surrounding the use and operation of the machine. - Page 14 BEFORE USING THIS MACHINE YOU MUST: ▲ Ensure you read all sections of the operator handbook. ▲ Ensure the operator is, or has been, properly trained to use the machine. ▲ Ensure the operator has been issued with and reads the operator handbook. ▲...
- Page 15 ▲ Always disengage the machine, kill the tractor engine, remove and pocket the key before dismounting for any reason. ▲ Always clear up all debris left at the work area, it may cause hazard to others. ▲ Always ensure when you remove your machine from the tractor that it is left in a safe and stable position using the stands and props provided and secured if necessary.
- Page 16 No advice given here can replace ‘good common sense’ and ‘total awareness’ at all times, but will go a long way towards the safe use of your McConnel machine.
-
Page 17: Tractor Requirements
Minimum Tractor Weights (including ballast weights if necessary) TA320 Models – 1300kg TA420 Models – 2000kg Minimum HP Requirements 25HP for TA320 & TA420 Models with Cutterbar. 30HP for TA320 & TA420 Models with Flailhead. Linkage Type Category 1 or Category 2. -
Page 18: Vehicle/Tractor Preparation
VEHICLE / TRACTOR PREPARATION Guarding: We recommend vehicles are fitted with cabs using safety glass windows and protective guarding when used with machines. Fit Operator Guard (part no. 7313324) using the hooks provided. Shape mesh to cover all vulnerable areas. Remember the driver must be looking through mesh and/or polycarbonate glazing when viewing the flail head in any working position - unless the vehicle/ cab manufacturer can demonstrate that the penetration... -
Page 19: Closed Centre Conversion
CLOSED CENTRE CONVERSION KIT – Semi-Independent models only Closed Centre Conversion Kit 8130059 The Control Valve Conversion Kit (Part No. 8130059) consists of a relief valve blanking plug which should be installed in place of the existing relief valve, and a pressure gallery blanking plug which is installed in place of the standard blanking plug at the valve outlet end next to the lift ram gland connection. -
Page 20: Delivery & Pre-Attachment
DELIVERY & PRE-ATTACHMENT (Dealer Reference) Delivery The machine will be delivered in a partially dismantled condition secured with transport straps and banding. Select a firm level site on which to place the machine before removing the straps, banding and other loose items. Handling the Machine Handling of the machine should always be performed using suitable overhead lifting equipment with a minimum safe lifting capacity over and above the maximum weight of the... -
Page 21: Attachment To Tractor
ATTACHMENT TO TRACTOR Attachment to the tractor should be performed on a firm level site. Reverse tractor squarely to the machine with lower links in line with machine attachment points, fit and secure with lynch pins. Fit machine operation controls in the tractor cab. Offer stabilizer to tractor and mainframe –... - Page 22 Raise machine on linkage until tractor’s PTO (A) and gearbox stub shaft (B) are aligned as near as possible. Secure stabilizer to the machine lower mainframe with nuts and bolts supplied - selecting a suitable hole position that will retain the alignment. Lower tractor linkage until machine’s weight is supported by Measure and fit the PTO shaft –...
-
Page 23: Stabilizer Adjustment
STABILIZER ADJUSTMENT For ease and precision of fitment the stabilizer supplied with the machine features an incremental notched positioning system that allows for both simpler adjustment and precise attachment over a wider range of applications. Loosen retaining nut and bolt. Pull stabilizer arms outwards to free stabilizer head and swivel to required position. Push stabilizer arms inwards to re-engage notches and tighten nut and bolt to secure. -
Page 24: Pto Driveshaft Installation
PTO DRIVESHAFT INSTALLATION The PTO driveshaft attaches between the tractor and the machine gearbox to transfer the power required to the run and operate the machine – it is important to achieve the correct shaft length to avoid risk of it ‘bottoming out’ when raising or lowering the machine. The procedure for measuring and cutting the shaft is as follows: Measuring the PTO Shaft... -
Page 25: Fitting Operator Control Units
FITTING OPERATOR CONTROL UNITS Fitment of the operator controls in the tractor cab will vary depending on the particular model or specification of machine – the information below lists the differing methods of fitment for the various types of controls available. NOTE: Electric control units work within the range of 12v-16v DC and will require a minimum power supply of 12v DC. -
Page 26: Hydraulic Oil
HYDRAULIC OIL Hydraulic Oil Reservoir Fill the tank with oil selected from the chart below or a good quality equivalent to a point where the level is between the minimum and maximum marks on the tank gauge. When the machine is initially run the level will drop as the oil is drawn into the circuit - top back up as required to the correct level on the gauge. -
Page 27: Flail Motor Hose Installation
FLAIL MOTOR HOSE INSTALLATION... -
Page 28: Detachment
DETACHMENT DANGER! Read carefully before attempting to detach the machine from the tractor. WARNING! Do not operate quadrant lever or machine controls through the rear cab window whilst standing on or amongst linkage components – Always seek assistance. Detachment Procedure Select a firm level site on which to park the machine. -
Page 29: Rotor Operation
ROTOR OPERATION DANGER - VERY IMPORTANT It is very important that motor spool and motor spool control lever works in one direction only - From centre (OFF) position to selected (ON) 'rotor cut' direction position – permitting the rotor one direction of cut and the 'OFF' setting only. This eliminates the chance of going from ‘cut-up’... -
Page 30: Cable Controls
CABLE CONTROLS... - Page 31 CABLE CONTROLS – LEVER FUNCTIONS Angle Float...
-
Page 32: Low Pressure Hydraulic Controls
LOW PRESSURE CONTROLS – Operation and Functions (Refer to diagrams) Power ON – Connect Power Plug to battery. Power OFF – Disconnect power from hedgecutter to tractor. Lever Functions 1. Lever - Movement of the lever in a ‘Forward’ and ‘Backward’ direction operates the Main Arm: Forwards –... -
Page 33: Transport Position
TRANSPORT POSITION For transport on the public highway the flailhead, or cutterbar, must be folded within the overall width of the tractor. To allow the machine to be compactly folded the base of the breakaway ram and its fixing pins must be transferred from the outboard work position (A) and relocated to the inboard transport position (B) - see illustration opposite. -
Page 34: Operation
OPERATION Operator Guard Machine Guards Before each period of work, check that all the relevant tractor and machine guards are in place and in good working condition. Small splits and abrasions on the lower edges of the flail head rubber flaps are permissible, but should one or more of these cuts or splits become fifty per cent or more of the flap height they should be replaced immediately as they will have become ineffective for debris containment. -
Page 35: Running Up Procedure
RUNNING UP PROCEDURE CAUTION: Before initial use of a new machine, all lubrication points must be greased and the gearbox and oil tank levels checked and where required topped up before attempting to use the machine. Refer to maintenance section for details. Semi-Independent (SI) Models ... -
Page 36: Reversing Rotation (Semi-Independent Machines)
ROTOR OPERATION – Reversing Rotation TI Machines Depending on the particular build, rotor operation on machines with independent hydraulic systems will either be via a cable operated rotor control lever or by operation of the rotor control switch on the machines control unit – refer to the previous controls section for specific details of operation. -
Page 37: Operating Speeds
OPERATING SPEEDS PTO Operating Speed The correct PTO speeds for operation of these machines is: 500 – 540RPM NOTE: For cutterbars 500 rpm is a guide speed only – it should be run only as fast as necessary perform required job. Never exceed 540 rpm PTO speed. -
Page 38: Breakaway Protection System
BREAKAWAY PROTECTION SYSTEM The machine is fitted with a hydraulic breakaway device which protects the structure of the machine should an unforeseen obstacle be encountered. The breakaway system on these machines is in the form of a pivoted dipper arm and breakaway ram. -
Page 39: Lift Float Kit
LIFT FLOAT (Optional Extra for Ground Work) Work without lift float requires far more concentration and input from the operator to quickly react and re-adjust to the ground contours often resulting in patches of higher cut material where the head is cutting too high and ‘scalping’ of the ground where it is cutting too low – in the case of the latter this can lead to increased flail wear, damage or even loss of flails. -
Page 40: Hazards & Dangers
HAZARDS & DANGERS Adverse Slopes When working with the flailhead high and reach fully in it is possible for the main arm balance to go over centre and take the weight off the lift ram. A restrictor in the gland circuit of the lift ram will prevent sudden unpredictable movements if this should occur - for reasons of safety this restrictor should not be removed. -
Page 41: Overhead Power Lines
OVERHEAD POWER LINES DANGER! It cannot be stressed enough the dangers involved when working in the vicinity of overhead power cables. Some of our machines are capable of reach in excess of 8 metres (26’) therefore they have the potential to well exceed, by possibly 3 metres (9’ 9”), the lowest legal minimum height of 5.2 metres from the ground for 11,000 and 33,000 volt power lines. -
Page 42: Hedgecutting Procedure
HEDGECUTTING PROCEDURE Cut the side and bottom of the field side first. This leaves the maximum thickness of hedge on the road side to prevent the possibility of any debris being thrown through the hedge into the path of oncoming vehicles. Cut the side and bottom of the road side. -
Page 43: General Maintenance
GENERAL MAINTENANCE General Lubrication The illustration below indicates the general locations of lubrication points - all points should be greased on a daily basis and prior storage of the machine. New machines must be greased prior to first use. Gearbox Lubrication Refill the gearbox after an initial 50 hours of use and thereafter at annual or 500 hour intervals, whichever occurs earliest. - Page 44 SERVICE SCHEDULE Every Day Grease machine fully prior to work (and prior to storage). NOTE: New machines must be greased before initial use. Check for broken or damaged flails. Check tightness of flail nuts and bolts. Visually check for oil leaks and damaged hoses. ...
-
Page 45: Hydraulic System
HYDRAULIC SYSTEM Oil Supply Check the oil level in the reservoir daily. Oil Condition & Replacement No fixed time period can be quoted for oil changes as operating conditions can vary widely but a visually inspection of the oil will often indicate its current overall state. Signs of a reduction in its condition will be apparent by changes in colour and appearance when compared to new oil. -
Page 46: Hydraulic Hoses
HYDRAULIC HOSES The condition of all hoses should be carefully checked during routine service of the machine. Hoses that have been chaffed or damaged on their outer casing should be securely wrapped with waterproof adhesive tape to stop the metal braid from rusting. Hoses that have suffered damage to the metal braid should be changed at the earliest opportunity. -
Page 47: Pto Shaft Maintenance
PTO SHAFT MAINTENANCE PTO Shaft Lubrication The PTO shaft should be lubricated on a regular basis using lithium based grease – each end of the shaft has 2 greasing points; one for lubrication of the universal joint and one for lubricating the rotating fixing ring of the shaft shield –... - Page 48 TORQUE SETTINGS FOR FASTENERS The chart below lists the correct tightening torque for fasteners. This chart should be referred to when tightening or replacing bolts in order to determine the grade of bolt and the correct torque unless specific torque values are assigned in the text of the manual. Recommended torque is quoted in Foot-Pounds and Newton-Metres within this manual.
- Page 50 McConnel Limited, Temeside Works, Ludlow, Shropshire SY8 1JL. England. Telephone: 01584 873131. Facsimile: 01584 876463. www.mcconnel.com...
