Deploy the ETA 9350 packetstore
Published: 2024-05-28
This guide explains how to install the rack-mounted ETA 9350 packetstore.
Installation prerequisites
Important: For maximum performance and compatibility, deploy sensors and packetstores in the
same datacenter.
To install the ETA 9350, your environment must meet the following requirements:
Appliance
2U of rack space and electrical connections for 2 x 800 W power supplies.
Management
One 10/100/1000 BASE-T network port or one 10G BASE-SR port for appliance management.
Monitoring (capture)
High performance interfaces: One to four network ports for connection to 25 GbE, or 10 GbE
sources of packet data, depending on the ordered configuration.
Management + monitoring interfaces: One to three network ports for connection to 1 GbE sources
of packet data.
Network Access
TCP 443 must be open between the packetstore and any connected console or sensors, including
any system that connects to the system for administration.
For more information about the interfaces on the ExtraHop system, see the
Rear panel ports
ETA 9350
1.
Power supply unit (PSU1) to connect the packetstore to an AC power source
2.
Two 25 GbE-capable ports on one network adapter. Ports 5 and 6 are the high-performance
monitoring (capture) interfaces.
3.
Four SAS ports to connect extended storage units (ESU).
Note: You cannot connect older ESUs to this packetstore.
4.
One RS-232 serial port to connect a console device
5.
Power supply unit (PSU2) to connect the packetstore to an AC power source
ExtraHop Hardware FAQ
©
2024ExtraHop Networks, Inc. All rights reserved.
.
