Deploy the ExtraHop Discover 10200
Appliance
Published: 2020-04-16
This guide explains how to install the rack-mounted EDA 10200 ExtraHop Discover appliance.
Installation prerequisites
To install the Discover appliance, your environment must meet the following requirements:
Appliance
2U of rack space and electrical connections for 2 x 1100 W power supplies.
Management
One 10/100/1000 BASE-T network port or one 10G BASE-SR port for appliance management.
Monitoring (capture)
High-performance interfaces: One to four network ports for connection to 100 GbE, 40 GbE, 25 GbE,
or 10 GbE sources of packet data, depending on the ordered configuration.
Management + monitoring interfaces: One to three network ports for connection to 1 GbE sources of
packet data.
Network Access
The TCP 443 port must be open between the Discover appliance and any system that connects to the
appliance for administration through the ExtraHop Admin UI.
For more information about the interfaces on the ExtraHop appliance, see the
Rear panel ports
EDA 10200
•
One iDRAC interface port
•
One RS-232 serial port to connect a console device
•
One VGA port to connect an external display
•
Two USB 3.0 ports to connect input devices such as a keyboard and mouse
•
Two power ports to connect the appliance to an AC power source
Appliance Hardware FAQ
©
2020 ExtraHop Networks, Inc. All rights reserved.
.
Advertisement
Related Manuals for ExtraHop EDA 10200
Summary of Contents for ExtraHop EDA 10200
- Page 1 Deploy the ExtraHop Discover 10200 Appliance Published: 2020-04-16 This guide explains how to install the rack-mounted EDA 10200 ExtraHop Discover appliance. Installation prerequisites To install the Discover appliance, your environment must meet the following requirements: Appliance 2U of rack space and electrical connections for 2 x 1100 W power supplies.
- Page 2 Set up the appliance Rack mount the Discover appliance. Install the Discover appliance in your data center with the included rack-mounting kit. The mounting kit supports most four-post racks with either round or square holes. Deploy the ExtraHop Discover 10200 Appliance...
- Page 3 Configure the management IP address DHCP is enabled by default on the ExtraHop system. When you power on the system, interface 3 attempts to acquire an IP address through DHCP. If successful, the IP address appears on the home screen of the LCD.
- Page 4 RS-232 serial cable and a terminal-emulator program. The terminal emulator must be set to 115200 bps with 8 data bits, no parity, 1 stop bit (8N1), and hardware flow control should be disabled. Establish a connection to the ExtraHop system. At the login prompt, type shell and then press ENTER.
- Page 5 After you configure an IP address for the Discover appliance, open a web browser and navigate to the ExtraHop Web UI through the configured IP address. Accept the license agreement and then log in with the setup user account. The password is the system serial number that appears in the Info section of the LCD display and on the label on the back of the appliance..
