4 | NS7x50 Sensors

Deployment of an NS-series Sensor

Deployment of a Sensor requires knowledge of your network to help determine the level of configuration and the number of
installed Sensors. You also need to determine the number of Trellix ePolicy Orchestrator - On-prem servers required to protect
your network. The Sensor is purpose-built for the monitoring of traffic across one or more network segments.
Following is an example of a network topology using Gigabit Ethernet throughput. In the illustration, Trellix Intrusion Prevention
System provides IPS protection to outsourced servers. High port-density and virtualization provides a highly scalable solution,
while Trellix IPS protects against web and eCommerce mail server exploits.
A sample NS-Series deployment
:

NS7x50 Sensor physical description

The high-port density NS-series Sensor is designed for high bandwidth links. This section gives a physical description of the
NS7x50 Sensors.
The NS7350, NS7250, and NS7150 Sensor models are a mid-range offering that provide 5 Gbps, 3 Gbps, and 1.5 Gbps throughput
respectively.
:

Components of an NS7x50 Sensor

The NS7x50 front and rear panel details are described below.
168 Trellix Intrusion Prevention System NS-series Sensor Product Guide
