2 | NS9x00 Sensors

Remove a transceiver module

Perform these tasks if you need to remove a module.
Steps:
1. Disconnect the network fiber-optic cable from the module.
2. Release the module from the slot by pulling the bail clasp out of its locked position.
3. Slide the module out of the slot.
4. Insert the module plug into the module optical bore for protection.
:

Attaching cables to the Sensor

Follow the steps outlined in this chapter to connect the cables to the various ports of your Sensor.
:

Connect the cable to the Console port

The Console port on the NS-series Sensor is used for setup and configuration of the Sensor.
Steps:
1. For console connections, plug the DB9 Console cable supplied by Trellix into the Console port on the Sensor.This port is
labeled Console in the Sensor front panel.
2. Connect the other end of the Console port cable directly to a COM port of the computer or terminal server you will use
to configure the Sensor, for example, a computer running correctly configured Windows HyperTerminal software.You must
connect directly to the console for initial configuration; you cannot configure the Sensor remotely. Terminal servers are
provided for console access. Required settings for HyperTerminal are listed below:
Name
Baud rate
Number of bits
Parity
Stop bits
Flow control
Trellix Intrusion Prevention System NS-series Sensor Product Guide
Setting
115200
8
None
1
None
