- Page 1 HVLP PAINT GUN SET INSTRUCTIONS Item #15214...
-
Page 2: Safety Information
• Always disconnect gun from pressurized air source when adding paint, cleaning and servicing or when not in use. • Use only approved Eastwood solvents, acetone or lacquer thinner to clean guns. Use of chlorinated or halogenated hydrocarbon solvents can corrode aluminum gun components or emit hazardous reactive gasses. - Page 3 (1) 1000ml. aluminum Paint Cup (1) 600ml. aluminum Paint Cup (1) 250ml. aluminum Paint Cup (3) 100 Micron gun Cup Filters (2) Regulator/Gauges (1) Paint Gun Wrench (4) Paint Gun Cleaning Brushes (1) Heavy-Duty Plastic Case To order parts and supplies: 800.345.1178 >> eastwood.com...
- Page 4 2. Before First Use – Following Gun Cleaning Procedure, clean out the paint cup, nozzle as well as the paint gun internal air and paint passages with a solvent such as, Eastwood PRE (10041Z) or Aerosol Injected Cleaner (12846Z) to remove any residual manufacturing impurities or lubricants that may be present.
- Page 5 4. Pour a small amount of a solvent compatible with the paint being used in the Paint Cup then attach Paint Cup, reconnect air supply then spray solvent through HVLP Gun in a safe area until it fl ows clear. Note: Eastwood Aerosol Injected Gun Cleaner (12846Z) is excellent for this purpose.
- Page 6 • Replace Nozzle by threading into front of Gun Body and tighten fi rmly with included wrench. (Caution: do not-over tighten). • Replace Air cap by threading onto Gun Body. Make sure the air horns of the Air Cap are oriented properly. Eastwood Technical Assistance: 800.544.5118 >> techelp@eastwood.com...
- Page 7 Fluid Control Knob Needle Control Knob Nozzle Air Cap Control Knob To order parts and supplies: 800.345.1178 >> eastwood.com...
-
Page 8: Troubleshooting
13 Piece Mixing Cup Set If you have any questions about the use of this product, please contact The Eastwood Technical Assistance Service Department: 800.544.5118 >> email: techelp@eastwood.com PDF version of this manual is available online >> eastwood.com/20124manual The Eastwood Company 263 Shoemaker Road, Pottstown, PA 19464, USA US and Canada: 800.345.1178...
