Whalen VWM-1 Manual

Tilting wall mount / satin black / 100lbs / 23"-46" tv's

Advertisement

Quick Links

TWO ADULTS REQUIRED FOR ASSEMBLING
If you have any questions regarding assembly or if you are missing parts,
do not return this item to the Retailer Store
Please call our customer service number and have your instructions and
parts list ready to provide the model name, part name or factory number:
Pacific Standard Time: 8:30 am - 4:30 pm Monday to Friday
or visit our web site 24 hours a day, 7 days a week for product
or e-mail your request to
MODEL No.: VWM-1
LOT No.:
DATE OF PURCHASE:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
VWM-1
1-866-942-5362
assistance at
www.whalenfurniture.com
VAS Furniture Mfg. Inc.
Factory No. 64-12209
Page # 1
parts@whalenfurniture.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the VWM-1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Whalen VWM-1

  • Page 1 24 hours a day, 7 days a week for product assistance at www.whalenfurniture.com or e-mail your request to parts@whalenfurniture.com MODEL No.: VWM-1 LOT No.: DATE OF PURCHASE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
  • Page 2: Quality Guarantee

    QUALITY GUARANTEE We are confident that you will be delighted with your VAS Furniture purchase. Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to 1 year from date of purchase. Every VAS Furniture product is designed to meet your highest expectations.
  • Page 3: Hardware Kit

    Step One: Included in the Box Included with your mount is all of the hardware required for installation. Please read completely through the instructions before beginning installation. Layout all of the items to verify that all parts listed are present and undamaged. Never use defective parts.
  • Page 4 Step Two: Required Installation Tools To install your mount you will need a Stud Finder w/Level (provided), Large Philips head screwdriver, Mallet, Power Drill, 3/16” Wood Drill Bit, 7/16” Masonry Drill Bit, Socket wrench adapter with 1/2” socket, Pencil, and Tape Measure. Step Three: Selecting a Location Find the optimal place to mount your flat panel television.
  • Page 5 Use the wall mount plate as a template to determine the hole positions in the studs. Set the included Stud Finder with Level on the mount to verify that the mount is level before marking the hole positions. Use a pencil to mark where the studs and mount plate slots intersect. Pre-drill mounting holes 3 1/2"...
  • Page 6 For Brick, Solid Concrete, or Cinder Block Wall Using the Wall Mount Plate (MP) as a template, mark six hole locations on the wall, always use the Leveler to double check the holes level with each other. Drill these holes 3 1/4” deep using a 7/16”...
  • Page 7 Step Five: Attaching the Monitor Brackets to the TV Select the proper bolts from the included set by hand-threading them into the inserts on the back of your TV. The proper bolt should screw in without resistance. Attach the Monitor Brackets (MB) to the back of the television ensuring the tilt adjustment knob facing outer side.
  • Page 8 Step Six: Hanging the TV Ask for assistance when lifting TV to attach the Monitor Brackets (MB) onto the Wall Mount Plate (MP). Make sure the Safety Lock Controls pre-attached under the Monitor Bracket (MB) are in unlocked position when attaching. Once the TV with the Monitor Brackets (MB) is positioned on the Wall Mount Plate (MP), loosen the Lock Bolt under...
