Whalen TGXLGT46DW Manual

Genesis gaming theater 3-in-1 mixed media tv stand
Hide thumbs

Advertisement

Quick Links

Download this manual
Genesis Gaming Theater
Model # TGXLGT46DW
ADULT ASSEMBLY REQUIRED
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our toll-free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
1-866-942-5362
www.whalenfurniture.com
ONLINE:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE
READ AND KEEP FOR FUTURE REFERENCE.
Whalen Furniture Mfg., Inc.
8:30 a.m. - 4:30 p.m. PST, Monday - Friday
Video Instruction Guides
Go to http://whalen.showuhow.com to view step-by-step instructional
videos for assembling and installing your product. Enter the following
product number on the ShowUhow homepage.
TGXLGT46DW
LOT NUMBER:
DATE PURCHASED:
TM
3-in-1 Mixed Media TV Stand
EMAIL:
Page 1
parts@whalenfurniture.com
Factory # 56-12089
/
/

Advertisement

loading
Need help?

Need help?

Do you have a question about the TGXLGT46DW and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Whalen TGXLGT46DW

Summary of Contents for Whalen TGXLGT46DW

  • Page 1 ONLINE: EMAIL: Video Instruction Guides Go to http://whalen.showuhow.com to view step-by-step instructional videos for assembling and installing your product. Enter the following product number on the ShowUhow homepage. TGXLGT46DW THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
  • Page 2 M A X I M U M R E C O M M E N D E D W E I G H T L O A D S MANUFACTURER: Whalen Furniture CATALOG: Genesis Gaming Theater 3-in-1 Mixed Media TV Stand (TGXLGT46DW) DATE OF MANUFACTURE: January 2012 MADE IN CHINA MAXIMUM LOAD 15 lb.
  • Page 3 Model # TGXLGT46DW Parts and Hardware List Please read completely through the instructions and verify that all parts listed are present before beginning assembly. A- Top Shelf Frame (1) B- Bottom Shelf Frame (1) C- Left Front Post (1) D- Right Front Post (1)
  • Page 4 Model # TGXLGT46DW Parts and Hardware List Please read completely through the instructions and verify that all parts listed are present before beginning assembly. (4) 1” Bolt (8+1 extra) (5) 1-1/4” Bolt (6+1 extra) (6) 2-1/4” Bolt (4+1 extra) (7) Lock Washer (38+1 extra) (8) Flat Washer (38+1 extra)
  • Page 5 Model # TGXLGT46DW Assembly Instructions Note: Please do not fully tighten all bolts until you finish assembling all parts. Once assembled, go back and fully tighten all bolts. This will make it easier during assembly of unit. 1. Unpack the unit and confirm that you have all the hardware and required parts listed.
  • Page 6 Model # TGXLGT46DW Assembly Instructions 4. Align and attach Left and Right Front Posts (C and D) to the front corners of Shelf Frames (A and B). Make sure the gaps and offsets between the wooden front rail of Top Shelf Frame (A) and the Posts are equal.
  • Page 7 Model # TGXLGT46DW Assembly Instructions 5. Stand the unit upright. 6. Attach 2 Wood Back Supports (F) to the back rail of Metal Frames. Make sure all the threaded inserts for Glass Clamps are level with each other. BACK 1” Bolt...
  • Page 8 Model # TGXLGT46DW If you choose Table-top configuration, continue to STEP 7. If mounting TV with the Swinging Floater, skip ahead to PAGE 12. Assembly Instructions 7. Attach 2 Cable Wheels (P) onto the backside of Spine (E). You can use the cable wheels to help keep your entertainment center’s cables and cords organized.
  • Page 9 Model # TGXLGT46DW Assembly Instructions 9. Go back and tighten all bolts with the Allen Wrench provided. 10. Put the Suction Cups (1) firmly into the top holes of Top and Bottom Shelf Frames (A and B). Attach the Glass Clamps (9) to the threaded inserts on both Front Posts (C and D) and Wood Back Supports (F).
  • Page 10 Model # TGXLGT46DW Assembly Instructions 13. Remove the tape of Acrylic Stopper (13) and place it on the cut-out of the warning label on the front of Top Glass (G). Make sure it is aligned before applying pressure. 14. Remove the warning label for Acrylic Stopper carefully.
  • Page 11 Model # TGXLGT46DW Assembly Instructions 15. Position the assembled Table-top in your desired location against the wall. Now follow the instructions printed on the plastic bag containing the Tipping Restraint Hardware to mount the tipping restraint to one Wood Back Support (F) and the wall.
  • Page 12 Model # TGXLGT46DW A s s e m b l y I n s t r u c t i o n s f o r F l o a t i n g S w i v e l M o u n t 17.
  • Page 13 Model # TGXLGT46DW Assembly Instructions 18. Align and attach the Swiveling Bracket (J) to the top of Swiveling Floater Post (I) making sure the pivoting bolt head is up. Tighten the bolts with enclosed M4 Allen Wrench. 3/4” Bolt Lock Washer...
  • Page 14 Model # TGXLGT46DW Assembly Instructions 19. The Sensor/Sound Shelf (N) provides two options: position gaming accessories above TV or sound bar below TV. Choose the option you prefer, slide SSS Spine (M) onto the XYZ Mounting Frame (K) properly. Adjust the height of SSS Spine and attach in place. Make sure the Sensor/Sound Shelf (N) will not hit your TV.
  • Page 15 Model # TGXLGT46DW Assembly Instructions 20. Hold and attach the flat side of XYZ Mounting Frame (K) onto the Swiveling Bracket (J). Make sure the recess holes on the XYZ Mounting Frame are at the bottom. Securely tighten with enclosed Allen Wrench.
  • Page 16 Model # TGXLGT46DW Assembly Instructions 21. Pick up Sensor/Sound Shelf (N) and securely fit the back tabs into the small slots of SSS Spine (M). Tighten both lock bolts pre-attached on the SSS Spine with a Phillips Screwdriver until they hit the back tabs of Sensor/Sound Shelf.
  • Page 17 Model # TGXLGT46DW Mounting Monitor Brackets to a television with a flat back Note: For televisions with a curved back or recessed back proceed directly to step #24. 22. Determine the correct diameter of the bolt your TV requires by hand threading them into the threaded insert on the back of the TV.
  • Page 18 Model # TGXLGT46DW Mounting Monitor Brackets to a television with a curved / recess back 24. Determine the correct diameter of the bolt your TV requires by hand threading them into the threaded insert on the back of the TV. If you encounter any resistance, stop immediately. If you are unable to find the correct bolt consult a local hardware store.
  • Page 19 Model # TGXLGT46DW Assembly Instructions for Floating Swivel Mount MAKE SURE ALL BOLTS ARE TIGHT AND SPINE IS AT A 90 DEGREE ANGLE AND USING A QUALITY LEVEL TO VERIFY THE MOUNTING FRAME IS LEVEL PRIOR TO INSTALLATION OF TV.
  • Page 20 Model # TGXLGT46DW Assembly Instructions for Floating Swivel Mount 28. The Monitor Brackets (LL/LR) can tilt up to 11˚ downward and 5˚ upward, depending on your optimum viewing position. Have your assistant hold the TV steady before you start to adjust the tilt.
  • Page 21 Model # TGXLGT46DW Assembly Instructions 29. Repeat steps 7 thru 12 to attach the Gaming Guitar Clip (O) and Cable Wheels (P) onto the Swiveling Floater Post (I) and install Top Glass (G) and Glass Shelves (H) into place. 30. Carefully move the console and position in your desired location against a wall. Now follow the instructions printed on the plastic bag containing Tipping Restraint Hardware Kit to mount the tipping restraint to the Swiveling Floater Post (I) and the wall.
  • Page 22 Model # TGXLGT46DW The following steps are only for those who wish to mount their TV directly to the wall. If you have already mounted your TV to the Swinging Floater or plan to display your TV on the top surface of the stand, disregard the following steps.
  • Page 23 Model # TGXLGT46DW Assembly Instruction for installing XYZ Mounting Frame onto BRICK, SOLID CONCRETE OR CONCRETE BLOCK NOTE: If you are mounting your TV to a wall with wooden studs, skip this section. This assembly requires an electric drill and level (not included).
  • Page 24 Model # TGXLGT46DW Assembly Instructions 38. The Sensor/Sound Shelf (N) provides two options: position gaming accessories above TV or sound bar below TV. Choose the option you prefer, slide SSS Spine (M) onto the XYZ Mounting Frame (K) properly. Adjust the height of SSS Spine and attach in place. Make sure the Sensor/Sound Shelf (N) will not hit your TV.

  • Page 25: Care And Maintenance

    Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from the date of purchase. Every Whalen Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
