BINMASTER NCR-86 Quick Setup Manual

Radar sensor for continuous level measurement of liquids and bulk solids
Hide thumbs Also See for NCR-86:
Table of Contents

Advertisement

Quick Links

Download this manual
Quick setup guide
Radar sensor for continuous level
measurement of liquids and bulk solids
NCR-86
Two-wire 4 ... 20 mA/HART
Document ID: 1031455

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NCR-86 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BINMASTER NCR-86

Summary of Contents for BINMASTER NCR-86

  • Page 1 Quick setup guide Radar sensor for continuous level measurement of liquids and bulk solids NCR-86 Two-wire 4 … 20 mA/HART Document ID: 1031455...

  • Page 2: Table Of Contents

    This quick setup guide enables quick setup and commissioning of your instrument. sive operating instructions as well as in the Safety Manual for instru- Operating instructions NCR-86 - Two-wire 4 … 20 mA/HART: Document-ID 1031453 Editing status of the quick setup guide: 2023-12-19...

  • Page 3: For Your Safety

    During work on and with the device, the required personal protective equipment must always be worn. Appropriate use NCR-86 is a sensor for continuous level measurement. chapter "Product description". Operational reliability is ensured only if the instrument is properly sible supplementary instructions.

  • Page 4: Mode Of Operation - Radar Signal

    Installations in Canada shall comply with the relevant requirements of the Canadian Electrical Code (CEC Part I) (Canada). A Class 2 power supply unit has to be used for the installation in the USA and Canada. NCR-86 • Two-wire 4 … 20 mA/HART...

  • Page 5: Product Description

    • Technical data • Serial number of the instrument • • Numerical code for Bluetooth access (optional) • Manufacturer information Documents and software Further information can be found on our homepage. the device. NCR-86 • Two-wire 4 … 20 mA/HART...

  • Page 6: Setup - The Most Important Steps

    Adjustment app Parameterize sensor Liquids Bulk solids Enter medium type, application, vessel height, adjustment and mode 100% 100% Check measured value Indicators Output Download via Apple App Store, Google Play Store, Baidu Store NCR-86 • Two-wire 4 … 20 mA/HART...

  • Page 7: Mounting

    This applies especially if buildup on > 200 mm (7.87") Fig. 2: Mounting of the radar sensor on round vessel tops In this case, it is recommended to repeat the false signal suppression at a NCR-86 • Two-wire 4 … 20 mA/HART...
  • Page 8 If you cannot maintain this distance, you should carry out a false signal suppression during setup. This applies especially if buildup on In this case, it is recommended to repeat the false signal suppression at a NCR-86 • Two-wire 4 … 20 mA/HART...

  • Page 9: Connecting To Power Supply

    8. Connect the shielding to the internal ground terminal, connect 9. Tighten the compression nut of the cable entry gland. The seal ring must completely encircle the cable 10. Reinsert the display and adjustment module, if one was installed NCR-86 • Two-wire 4 … 20 mA/HART...

  • Page 10: Wiring Plan, Single Chamber Housing

    Fig. 6: Electronics and connection compartment - single chamber housing Voltage supply, signal output For display and adjustment module or interface adapter For external display and adjustment unit Ground terminal for connection of the cable screening NCR-86 • Two-wire 4 … 20 mA/HART...

  • Page 11: Set Up With The Display And Adjustment Module

    Fig. 7: Installing the display and adjustment module in the electronics compart- ment of the single chamber housing Fig. 8: Installing the display and adjustment module in the double chamber housing In the electronics compartment In the connection compartment NCR-86 • Two-wire 4 … 20 mA/HART...

  • Page 12: Parameter Adjustment

    To avoid possible errors during parameterization in a non-safe user to detect parameterization errors reliably. For this, safety-relevant In normal operating condition, the instrument is also locked against parameter changes through unauthorized access. NCR-86 • Two-wire 4 … 20 mA/HART...
  • Page 13 In this case, you have to carry out a function test. Function test: During a function test, you have to test the safety function of the instrument in the vessel with the original medium. "Functional safety (SIL)" of the operating instructions. Verify parameter: NCR-86 • Two-wire 4 … 20 mA/HART...
  • Page 14 Since the radar sensor is a distance measuring instrument, it is the distance from the sensor to the medium surface that is measured. To indicate the actual level, the measured distance must be assigned to During adjustment, enter the respective measuring distance when NCR-86 • Two-wire 4 … 20 mA/HART...
  • Page 15 Fig. 10: Parameterisation example min./max. adjustment - bulk solids Min. level = max. meas. distance (distance B) Max. level = min. meas. distance (distance A) Reference plane carried out with the distances of 10 % and 90 %. NCR-86 • Two-wire 4 … 20 mA/HART...
  • Page 16 [+] and save with [OK]. The cursor now jumps to the distance value. 6.2.3 Extended settings Mode This menu item contains operational settings of the sensor. Mode: mined via the operating mode. NCR-86 • Two-wire 4 … 20 mA/HART...
  • Page 17 Deleting a created false signal suppression, a user-programma- ble linearisation curve as well as the measured value and echo curve memory Reset - Restart: age. The event and parameter change memories are maintained. NCR-86 • Two-wire 4 … 20 mA/HART...
  • Page 18 For the duration of the reset, the device changes its behaviour from the normal measuring operation. Therefore, observe the following for downstream systems: • The current output outputs the set false signal • The Asset-Management function outputs the message "Mainte- nance" aus NCR-86 • Two-wire 4 … 20 mA/HART...

  • Page 19: Set Up With Smartphone/Tablet

    The message "Connecting …" is displayed. The devices found are listed and the search is automatically contin- ued. Select the requested instrument in the device list. Authenticate authentication, each subsequent connection is made without a new authentication query. NCR-86 • Two-wire 4 … 20 mA/HART...

  • Page 20: Parameter Adjustment

    The sensor adjustment menu is divided into two areas, which are the adjustment tool. • Navigation section • Menu item display The selected menu item can be recognized by the colour change. Close the app to terminate connection. NCR-86 • Two-wire 4 … 20 mA/HART...

  • Page 21: Menu Overview

    120,000 m Extended settings Menu item Parameter Selection Default setting Temperature unit Damping Integration time 0 … 999 s encapsulated antenna system Flange with lens antenna encapsulated antenna system Flange with lens antenna NCR-86 • Two-wire 4 … 20 mA/HART...
  • Page 22 Date/Time Date Actual date Format: 24 h, 12 h 24 h Time Actual time HART mode HART address 0 … 63 Output mode Analogue current rent (4 mA) with HART output with HART NCR-86 • Two-wire 4 … 20 mA/HART...
  • Page 23 See separate menu overview at the end oc the chapter "Menu overview" of the operat- Special parameters ing instructions. Reset Menu item Parameter Selection Default setting Reset Reset Reset to factory settings, Restart NCR-86 • Two-wire 4 … 20 mA/HART...

  • Page 24: Supplement

    12 V < U < 18 V (16 … 400 Hz) for 18 V < U < 35 V (16 … 400 Hz) Load resistor Calculation )/0.022 A = 24 V DC NCR-86 • Two-wire 4 … 20 mA/HART...
  • Page 25 Notes NCR-86 • Two-wire 4 … 20 mA/HART...
  • Page 26 Notes NCR-86 • Two-wire 4 … 20 mA/HART...
  • Page 27 Notes NCR-86 • Two-wire 4 … 20 mA/HART...
  • Page 28 Printing date: All statements concerning scope of delivery, application, practical use and operat- ing conditions of the sensors and processing systems correspond to the information available at the time of printing. Subject to change without prior notice...
