BINMASTER NCR-30 Operating Instructions Manual

Radar sensor for continuous level measurement of liquids
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Operating Instructions
Radar sensor for continuous level
measurement of liquids
NCR-30
4 ... 20 mA/HART - two-wire
Document ID: 36511
925-0378

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NCR-30 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BINMASTER NCR-30

Summary of Contents for BINMASTER NCR-30

  • Page 1 Operating Instructions Radar sensor for continuous level measurement of liquids NCR-30 4 … 20 mA/HART - two-wire Document ID: 36511 925-0378...

  • Page 2: Table Of Contents

    Saving the parameterisation data ................... 59 Setup with PACTware ......................60 Connect the PC ......................60 Parameter adjustment ....................60 Saving the parameterisation data ................... 62 Set up with other systems ....................63 NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 3 11.4 Trademark ........................92 Safety instructions for Ex areas Take note of the Ex specific safety instructions for Ex applications. These instructions are attached as documents to each instrument with Ex approval and are part of the operating instructions manual. Editing status: 2018-06-25 NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...

  • Page 4: About This Document

    This arrow indicates a single action. Sequence of actions Numbers set in front indicate successive steps in a procedure. Battery disposal This symbol indicates special information about the disposal of bat- teries and accumulators. NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...

  • Page 5: For Your Safety

    During work on and with the device the required personal protective equipment must always be worn. Appropriate use NCR-30 is a sensor for continuous level measurement. You can find detailed information about the area of application in chapter "Product description". Operational reliability is ensured only if the instrument is properly used according to the specifications in the operating instructions manual as well as possible supplementary instructions.

  • Page 6: Eu Conformity

    It is hence approved for use inside closed vessels in countries of the Use is also approved in EFTA countries, provided the respective standards have been implemented. For operation inside of closed vessels, points a to f in annex E of EN 302372 must be fulfilled. NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...

  • Page 7: Radio License For Usa

    • Open Air Environment: For operation outside of closed vessels, the following condition must be fulfilled: This device shall be installed and maintained to ensure a vertically downward orienta- tion of the transmit antenna's main beam. Furthermore, the use of NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 8 à garantir une orientation verticale vers le bas du faisceau principal de l’antenne émettrice. De plus, l’utilisation de tout mécanisme ne permettant pas l’orientation ver- ticale vers le bas du faisceau principal de l’émetteur est interdite NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...

  • Page 9: Installation And Operation In The Usa And Canada

    Protection of the environment is one of our most important duties. That is why we have introduced an environment management system with the goal of continuously improving company environmental pro- tection. The environment management system is certified according to DIN EN ISO 14001. NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 10 2 For your safety Please help us fulfil this obligation by observing the environmental instructions in this manual: • Chapter "Packaging, transport and storage" • Chapter "Disposal" NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...

  • Page 11: Product Description

    Download the VEGA Tools app from the "Apple App Store" or the "Google Play Store" • Scan the Data Matrix code on the type label of the instrument or • Enter the serial number manually in the app NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...

  • Page 12: Principle Of Operation

    The respective scope of delivery results from the order specification. Principle of operation Application area The NCR-30 is a radar sensor for continuous level measurement of aggressive liquids or with hygienic requirements. It is suitable for applications in storage tanks, process vessels, dosing vessels and reactors.

  • Page 13: Packaging, Transport And Storage

    PC/notebook with Bluetooth USB adapter (Windows operating system) You can find further information in the operating instructions "Display and adjustment module PLICSCOM" (Document-ID 36433). VEGACONNECT The interface adapter VEGACONNECT enables the connection of communication-capable instruments to the USB interface of a PC. For NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 14 You can find further information in the supplementary instructions "Overvoltage arrester B81-35" (Document-ID 50708). Protective cover The protective cover protects the sensor housing against soiling and intense heat from solar radiation. NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 15 The supplementary electronics is a replacement part for 4 … 20 mA/ Supplementary electron- ics for double chamber HART sensors with double chamber housing. housing You can find further information in the operating instructions "Supple- mentary electronics for 4 … 20 mA/HART - two-wire" (Document-ID 42764). NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...

  • Page 16: Mounting

    The instrument is suitable for standard and extended ambient condi- conditions tions acc. to IEC/EN 61010-1. Mounting instructions Sealing to the process The PTFE washer of the antenna encapsulation serves also as process seal. NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 17 "Technical data", "Torques". The emitted radar impulses of the radar sensor are electromagnetic Polarisation waves. The polarisation is the direction of the electrical wave compo- nent. By turning the instrument in the connection flange or mounting boss, the polarisation can be used to reduce the effects of false echoes. The position of the polarisation is marked on the process fitting of the instrument. NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 18 4 Mounting Fig. 3: Position of the polarisation Marking hole Reference plane The measuring range of NCR-30 begins physically at the end of the antenna; the adjustment, however, begins at the reference plane. The reference plane is different depending on the sensor version. • Flange with encapsulated antenna system: The reference plane is the lower edge of the flange plating •...
  • Page 19 Fig. 6: Mounting of the radar sensor on vessels with conical bottom Inflowing medium Do not mount the instruments in or above the filling stream. Make sure that you detect the product surface, not the inflowing product. NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 20 Fig. 8: Deviating socket dimensions The below charts specify the max. socket length h depending on the diameter d. Socket diameter d Socket length h 50 mm ≤ 100 mm 80 mm ≤ 300 mm 100 mm ≤ 400 mm NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 21 They are included in the scope of delivery of the instrument and are intended for the flange screws. To seal effectively, the following requirements must be fulfilled: 1. Make sure the number of flange screws corresponds to the num- ber of flange holes 2. Use of disc springs as previously described Fig. 10: Use of disc springs Disc spring Sealing surface NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 22 1. Remove and clean the device, see section "Dismounting steps" and cleaning instructions in section labeled "Maintenance" 2. Loosen the PTFE washer manually and detach it Fig. 11: NCR-30 - Loosening the PTFE washer Note: Protect the thread against contamination 3.
  • Page 23 If foams are causing measurement errors, the biggest possible radar antennas, the electronics with increased sensitivity or low frequency radar sensors (C band) should be used. NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...

  • Page 24: Measurement Setup - Pipes

    Under these prerequisites, the measurement of products with low dielectric values (ε value ≤ 1.6) is possible. Note the following illustrations and instructions for measurement in a surge pipe. Information: Measurement in a surge pipe is not recommended for extremely adhesive products. NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 25 4 Mounting Configuration surge pipe 100% Fig. 15: Configuration surge pipe NCR-30 Radar sensor Polarisation marking 3 Thread or flange on the instrument Vent hole Holes 6 Welding connection through U-profile Ball valve with complete opening Surge pipe end 9 Reflector sheet 10 Fastening of the surge pipe NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 26 • A false signal suppression with the installed sensor is recom- mended but not mandatory • The measurement through a ball valve with unrestricted channel is possible NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 27 • An extension via welding neck flanges or pipe collars is not recom- mended. Measurement in the An alternative to measurement in a surge pipe is measurement in a bypass tube bypass tube outside of the vessel. NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 28 • A false signal suppression with the installed sensor is recom- mended but not mandatory • The measurement through a ball valve with unrestricted channel is possible NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 29 Flanges are welded to the tube according to the orientation of the polarisation • Gap size with junctions ≤ 0.1 mm, for example, when using a ball valve or intermediate flanges with single pipe sections • The antenna diameter of the sensor should correspond to the inner diameter of the tube • Diameter should be constant over the complete length NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...

  • Page 30: Connecting To Power Supply

    In the case of instrument housings with metric thread, the cable glands are screwed in at the factory. They are sealed with plastic plugs as transport protection. You have to remove these plugs before electrical connection. NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...

  • Page 31: Connecting

    Connection procedure Proceed as follows: 1. Unscrew the housing lid 2. If a display and adjustment module is installed, remove it by turn- ing it slightly to the left NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...

  • Page 32: Wiring Plan, Single Chamber Housing

    10. Reinsert the display and adjustment module, if one was installed 11. Screw the housing lid back on The electrical connection is finished. Wiring plan, single chamber housing The following illustration applies to the non-Ex as well as to the Ex-ia version. NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...

  • Page 33: Wiring Plan, Double Chamber Housing

    The following illustrations apply to the non-Ex as well as to the Ex-ia version. Electronics compartment 4...20mA 6 7 8 Fig. 20: Electronics compartment - double chamber housing Internal connection to the terminal compartment For display and adjustment module or interface adapter NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 34 Ground terminal for connection of the cable screen Terminal compart- ment - Radio module PLICSMOBILE 81 Status Send Fig. 22: Terminal compartment - Radio module PLICSMOBILE 81 Voltage supply You can find detailed information for connection in the operating instructions "PLICSMOBILE". NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...

  • Page 35: Wiring Plan, Ex-D-Ia Double Chamber Housing

    Ground terminal for connection of the cable screen Plug M12 x 1 for external display and adjustment unit Fig. 25: Top view of the plug connector Pin 1 Pin 2 Pin 3 Pin 4 NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...

  • Page 36: Double Chamber Housing With Bindisc-Adapter

    Pin 1 Pin 2 Pin 3 Pin 4 Contact pin Colour, connection ca- Terminal, electronics ble in the sensor module Pin 1 Brown Pin 2 White Pin 3 Blue Pin 4 Black NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...

  • Page 37: Wiring Plan - Version Ip 66/Ip 68 (1 Bar)

    As soon as a plausible measured value is found, the corresponding current is outputted to the signal cable. The value corresponds to the actual level as well as the settings already carried out, e.g. factory setting. NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...

  • Page 38: Set Up With The Display And Adjustment Module

    The display and adjustment module is powered by the sensor, an ad- ditional connection is not necessary. Fig. 29: Installing the display and adjustment module in the electronics compart- ment of the single chamber housing NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...

  • Page 39: Adjustment System

    • Key functions [OK] key: – Move to the menu overview – Confirm selected menu – Edit parameter – Save value • [->] key: – Change measured value presentation – Select list entry NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...

  • Page 40: Measured Value Indication - Selection Of National Language

    Approx. 60 minutes after the last pressing of a key, an automatic reset to measured value indication is triggered. Any values not confirmed with [OK] will not be saved. Measured value indication - Selection of national language Measured value indica- With the [->] key you move between three different indication modes. tion NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...

  • Page 41: Parameter Adjustment

    "Setup", "Diagnosis" and "Additional settings" are described. The general parameters in these menu sec- tions are described in the operating instructions manual "Display and adjustment module". NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 42 [OK] and jump to the next menu item with the [ESC] and the [->] key. Setup - Application In addition to the medium, also the application, i.e. the measuring site, can influence the measurement. NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 43 – Short reaction time of the sensor not required Storage tank, circulation: • Setup: large-volumed, upright cylindrical, spherical • Medium speed: slow filling and emptying • Installations: small, laterally mounted or large, top mounted stirrer • Process/measurement conditions: – Relatively smooth product surface NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 44 – Fast filling and emptying – Vessel is filled and emptied very often • Vessel: tight installation situation • Process/measurement conditions: – Condensation, buildup on the antenna – Foam generation • Properties, sensor: – Measurement speed optimized by virtually no averaging – Sporadic false echoes are suppressed NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 45 – In outdoor facilities, water and snow on vessel top possible • Properties, sensor: – False signals outside the vessel are not taken into consideration – False signal suppression recommended Transportable plastic tank: • Vessel: NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 46 – Stable and reliable measured values through frequent averaging – Insensitive in the close range Demonstration: • Adjustment for all applications which are not typically level measurement – Instrument demonstration – Object recognition/monitoring (additional settings required) NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 47 6 Set up with the display and adjustment module • Properties, sensor: – Sensor accepts all measured value changes within the measur- ing range immediately – High sensitivity to interference, because virtually no averaging Caution: If liquids with different dielectric constants separate in the vessel, for example through condensation, the radar sensor can detect under certain circumstances only the medium with the higher dielectric constant.
  • Page 48 2. Edit the percentage value with [OK] and set the cursor to the requested position with [->]. 3. Set the requested percentage value with [+] and save with [OK]. The cursor jumps now to the distance value. NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 49 Depending on the sensor type, the factory setting is 0 s or 1 s. Setup - Current output, In the menu item "Current output mode" you determine the output mode characteristics and reaction of the current output in case of fault. NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 50 When the PIN is active, adjustment via PACTware/DTM as well as other systems is also blocked. In delivery status, the PIN is "0000". Display - Language This menu item enables the setting of the requested national lan- guage. NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 51 The respective min. and max. measured values of the electronics tem- temperature perature are saved in the sensor. These values as well as the current temperature value are displayed in the menu item "Peak values". NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 52 Diagnosis - Curve indica- The "Echo curve" shows the signal strength of the echoes over the tion measuring range in dB. The signal strength enables an evaluation of the quality of the measurement. NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 53 Additional settings - False The following circumstances cause interfering reflections and can signal suppression influence the measurement: • High mounting sockets • Vessel internals such as struts • Agitators • Buildup or welded joints on vessel walls NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 54 "Extend", the distance to the product surface of the created false signal suppression is displayed. This value can now be changed and the false signal suppression can be extended to this range. Additional settings - Lin- A linearization is necessary for all vessels in which the vessel volume earization does not increase linearly with the level - e.g. a horizontal cylindri- NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 55 Additional settings - Date/ In this menu item, the internal clock of the sensor is set. Time After a reset, certain parameter adjustments made by the user are Additional settings - Reset reset. NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 56 Max. adjustment 0,000 m(d) Damping 0.0 s Current output mode 4 … 20 mA, < 3.6 mA Current output, min./max. Min. current 3.8 mA, max. current 20.5 mA Lock adjustment Released NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 57 In the menu "Additional settings" the items "Distance unit, tem- perature unit and linearization" • The values of the user-programmable linearisation curve The 4 … 20 mA signal of the sensor is switched off. The sensor uses a constant current of 4 mA. The measuring signal is transmitted exclusively as a digital HART signal. NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 58 PC. Instrument features In this menu item, the features of the sensor such as approval, pro- cess fitting, seal, measuring range, electronics, housing and others are displayed. NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...

  • Page 59: Saving The Parameterisation Data

    If the instrument is equipped with a display and adjustment module, ment module the parameter adjustment data can be saved therein. The procedure is described in menu item "Copy device settings". NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...

  • Page 60: Setup With Pactware

    4 … 20 mA cable (dashed line in the previous illustration). Parameter adjustment Prerequisites For parameter adjustment of the instrument via a Windows PC, the configuration software PACTware and a suitable instrument driver NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 61 The standard version is available as a download under www.vega.com/downloads and "Software". The full version is avail- able on CD from the agency serving you. NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...

  • Page 62: Saving The Parameterisation Data

    7 Setup with PACTware Saving the parameterisation data We recommend documenting or saving the parameterisation data via PACTware. That way the data are available for multiple use or service purposes. NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...

  • Page 63: Set Up With Other Systems

    This software is updated via the Internet and new EDDs are automatically accepted into the device catalogue of this software after they are released by the manufacturer. They can then be transferred to a Field Communicator. NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...

  • Page 64: Diagnosis, Asset Management And Service

    The data are read out via a PC with PACTware/DTM or the control system with EDD. The echo curves are stored with date and time and the corresponding Echo curve memory echo data. The memory is divided into two sections: NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...

  • Page 65: Asset Management Function

    (for example during simulation). This status message is inactive by default. It can be activated by the user via PACTware/DTM or EDD. Out of specification: The measured value is unreliable because an instrument specification was exceeded (e.g. electronics temperature). NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 66 Error in the calibration carried Exchanging the electronics Bit 8 of Byte 0 … 5 • out in the factory Send instrument for repair Error in the cali- • Error in the EEPROM bration NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 67 "delivery status" • • M501 Hardware error EEPROM Exchanging the electronics Bit 1 of • Send instrument for repair Byte 14 … 24 Error in the non- active linearisation table NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...

  • Page 68: Rectify Faults

    Check, adapt if necessary ance too high • • Current signal greater than Sensor electronics defective Exchange the instrument or send it in 22 mA, less than 3.6 mA for repair NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 69 Amplitude or position of a false signal has Determine the reason for the changed changed (e.g. condensation, buildup); false signals, carry out false signal sup- false signal suppression no longer pression, e.g. with condensation time matches actual conditions NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 70 Varying condensation or contamination on Carry out a false signal suppression or jumps sporadically to the antenna increase false signal suppression with 100 % during filling condensation/contamination in the close range by editing time NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 71 "Setup" must be carried out again or must be checked for plausibility and completeness. Technical service Should these measures not be successful, please call BinMaster technical service at +1-402-434-9102. NCR-30 • 4 … 20 mA/HART - two-wire...

  • Page 72: Exchanging The Electronics Module

    Instruments with approvals can be bound to certain software versions. Therefore make sure that the approval is still effective after a software update is carried out. You can find detailed information in the download area at www.vega.com. How to proceed if a repair is necessary You can find an RMA return form as well as detailed information about the procedure in the support area of our website: NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 73 9 Diagnosis, asset management and service www.binmaster.com. By doing this you help us carry out the repair quickly and without having to call back for needed information. In case of repair, proceed as follows: • Print and fill out one form per instrument • Clean the instrument and pack it damage-proof •...

  • Page 74: Dismount

    Pass the instrument directly on to a spe- cialised recycling company and do not use the municipal collecting points. These may be used only for privately used products according to the WEEE directive. NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...

  • Page 75: Supplement

    Recommended torque for tightening the 60 … 100 Nm (44.25 … 73.76 lbf ft) flange screws Max. torque for NPT cable glands and Conduit tubes Ʋ Plastic housing 10 Nm (7.376 lbf ft) NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 76 1 mm (0.039 in) Fault signal, current output (adjustable) mA-value unchanged 20.5 mA, 22 mA, < 3.6 mA Max. output current 22 mA Load See load resistance under Power supply Starting current ≤ 3.6 mA; ≤ 10 mA for 5 ms after switching on NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 77 - 10 mm (- 0.394 in) Fig. 53: Deviation under reference conditions Reference plane Antenna edge Recommended measuring range Variables influencing measurement accuracy Specifications apply to the digital measured value Default values can be assigned individually. Already included in the meas. deviation NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 78 Ʋ Electronics with increased sensitivity 700 ms approx. Step response time ≤ 3 s Time span after a sudden measuring distance change by max. 0.5 m in liquid applications, max 2 m with bulk solids applications, until the output signal has taken for the first time 90 % of the final value (IEC 61298-2). NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 79 PFA and PFA 8 mm Standard -40 … +150 °C (14 … +302 °F) High temperature -40 … +200 °C (-40 … +392 °F) Process pressure Outside the specified beam angle, the energy level of the radar signal is 50% (-3 dB) less. EIRP: Equivalent Isotropic Radiated Power. NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 80 Options of the cable entry Ʋ Cable gland with integrated connec- M20 x 1.5 (cable: ø 5 … 9 mm) tion cable Ʋ Cable entry ½ NPT Ʋ Blind plug M20 x 1.5; ½ NPT NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 81 Standard cable Special cable Screened 4 … 20 mA/HART 50 m ● – – Profibus PA, Founda- 25 m – ● ● tion Fieldbus Integrated clock Date format Day.Month.Year Time format 12 h/24 h NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 82 Reference voltage 500 V AC Electrical protective measures Protection rating Ʋ according to IEC 60529 IP 66/IP 67 Ʋ Protection acc. to NEMA Type 4X Galvanic separation between electronics and metal housing parts NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...

  • Page 83: Dimensions

    ½ NPT Fig. 54: Housing versions with protection rating IP 66/IP 67 - with integrated display and adjustment module the housing is 9 mm/0.35 in higher Plastic single chamber Plastic double chamber NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 84 Fig. 56: Housing version with protection rating IP 66/IP 68 (1 bar) - with integrated display and adjustment module the housing is 9 mm/0.35 in higher Aluminium - single chamber Aluminium - double chamber NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 85 Fig. 58: Housing version with protection rating IP 66/IP 68 (1 bar) - with integrated display and adjustment module the housing is 9 mm/0.35 in higher Stainless steel single chamber (electropolished) Stainless steel single chamber (precision casting) Stainless steel double chamber housing (precision casting) NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 86 ø 75 mm (2.95") Fig. 59: NCR-30, flange version DN 50/DN 65 and 2"/2½" From DN 80 and from 3" With stainless steel housings and Aluminium double chamber housings, this dimension is 98 mm (3.86") NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 87 ø 75 mm (1.73") (2.95") Fig. 60: NCR-30, flange version, low temperature DN 50/DN 65 and 2"/2½" From DN 80 and from 3" With stainless steel housings and Aluminium double chamber housings, this dimension is 198 mm (7.80") NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 88 ø 90 mm ø 78 mm (3.07") (3.54") Fig. 61: NCR-30, hygienic fitting 1 NeumoBiocontrol Tuchenhagen Varivent DN 25 Hygienic fitting LA Hygienic fitting LB With stainless steel housings and Aluminium double chamber housings, this dimension is 4 mm (0.157") less NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 89 Clamp 3½" (ø 106 mm), 4" (ø 119 mm) according to DIN 32676, ISO 2852/316L With stainless steel housings and Aluminium double chamber housings, this dimension is 4 mm (0.157") less NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 90 Slotted nut DIN 11851, DN 80 and 3" Slotted nut DIN 11864-2, DN 50 Slotted nut DIN 11864-2, DN 80 With stainless steel housings and Aluminium double chamber housings, this dimension is 4 mm (0.157") less NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 91 ø 105 mm (4.13") ø 114 mm (4.49") Fig. 64: NCR-30, hygienic fitting 4 SMS DN 51 SMS DN 76 With stainless steel housings and Aluminium double chamber housings, this dimension is 4 mm (0.157") less NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...

  • Page 92: Industrial Property Rights

    VEGA product lines are global protected by industrial property rights. Further information see www.vega.com. 11.4 Trademark All the brands as well as trade and company names used are property of their lawful proprietor/originator. NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 93 Vessel installations 22 False signal suppression 53 Fault rectification 68 Foam generation 23 HART 60 HART mode 57 Instrument units 53 Instrument version 58 Language 50 Linearisation curve 54 Lock adjustment 50 Main menu 41 NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 94 Notes NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 95 Notes NCR-30 • 4 … 20 mA/HART - two-wire 925-0378...
  • Page 96 Subject to change without prior notice © VEGA Grieshaber KG, Schiltach/Germany 2018 BinMaster Phone: 402-434-9102 7201 N 98th St Fax: 402-434-9133 Lincoln, NE 68507 E-mail: info@binmaster.com www.binmaster.com 925-0378...
