ROXX UpdateBOX Instructions

UpdateBOX
Instructions
Installation & Update Instructions
Check your Box version!
Before using the ROX UpdateBOX for the fi rst time
please check your current Box version. Turn on the
Update Box and during boot up read out the soft-
ware version it is working on.
- If your software version is lower than "0.86"
please continue with the steps described under
"ROXX UpdateBox Version A"
- If your software version is "0.86" or higher,
please continue with the steps described under
"ROXX UpdateBox Version B"
Note: it is possible to upgrade the UpdateBox hard-
and software from "VersionA" to "VersionB". Please
contact your local dealer!
ROXX UpdateBox Version A
Connect the ROXX UpdateBOX to a windows com-
puter.
1.
Download the software "ArtNetConfi ger" from
the ROXX homepage to the computer under the fol-
lowing webaddress:
https://roxxlight.com/de/support/
2.
Deactivate computers WLAN.
3.
Connect the UpdateBOX to the computer. Please
use the USB cable as well as a Network cable pa-
rallel. Be sure, that the computers network card is
set to "IP automatically".
4.
Turn the UpdateBOX on by pressing "Power".
5.
Open the just downloaded software "ArtNet-
C onfi ger".
6.
Allow network access if windows is asking.
7.
Press "Search" in the upper left corner of the soft-
ware window.
8.
The UpdateBOX will appear as one item in the
software window. Select the item by clicking on it.
Please compare if IP addresses displayed in the
software and on the UpdateBOX are matching.
Update the BOX
The ROXX UpdateBOX itself must work on soft-
ware version "0.44" or higher. You can check when
booting up the UpdateBOX. If your UpdateBOX is
already UpToDate you can go on directly with step
17. If not, please follow the next steps:
9.
Download the latest UpdateBOX Firmware from
the ROXX homepage under
https://roxxlight.com/de/support/
10.
Switch the UpdateBOX off by pressing "Power".
11.
Press and hold the "Up"- and the "Down"-But
tons of the BOX and switch it on by pressing "pow-
er" simultaneously. The UpdateBOX will now start
in "Programe manager" mode. Release all buttons.
12.
In the ArtNetConfi ger software open via the
menu: "Tools" -> "Customer Firmware Upgrade".
13.
In the now opening window browse to the just
downloaded UpdateBOX Firmware and open the
.bin-fi le (for example "Programe_manager V0.54.
bin").
14.
Press "Upgrade". The Update process on the
Box is starting. After completed Update process
press "Stop" on the computer. Don´t close the "Cus-
tomer fi rmware upgrade"-window.
15.
The UpdateBOX reboots in the new software
version.
16.
Turn the UpdateBOX off and on again using
"Power".
REV: 01
