User
Manual
CLUSTER S2
USER MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the CLUSTER S2 and is the answer not in the manual?

Questions and answers

Related Manuals for ROXX CLUSTER S2

Summary of Contents for ROXX CLUSTER S2

  • Page 1 User Manual CLUSTER S2 USER MANUAL...
  • Page 2 1.1. General Preventive Measures 1.2. Regulations for equipment that connects to power mains 1.3. Technical warnsigns and explanation 2. Introduction 2.1. About us 2.2. CLUSTER S2 3. General Product Information 3.1. Scope of delivery 3.2. Control Functions 3.3.Features 4. Installation & Setup 4.1 Physical Installation and Rigging...
  • Page 3 1.1.1. Please read, understand and follow the instructions. 1.1.2. Store the instructions and information in a safe place. Best solution is the ring binder provided by ROXX. 1.1.3. Follow all safety warnings. Under no circumstances remove safety warnings or other information from the equipment.
  • Page 4 User User Manual Manual 1.1.20. Observe all disposal laws applicable in your country. Especially for the packaging. 1.1.21. Plastic bags are not a toy! Keep away from children! 1.1.22. Please note that changes or modifications which are not approved by the party responsible for compliance will void the user’s authority to operate the device.
  • Page 5 User User Manual Manual 1.3. Technical warnsigns and explanation In order to prevent the risk of an electric shock, under no circumstances remove the cover/back or open the unit in any way! No user serviceable parts are inside. Service, maintenance and repairs should only be done by qualified service personnel or the manufacturer.
  • Page 6 CLUSTER S2 features a large number of build-in patterns and giving users a fast and simple way of creating stun- ning effects whenever a media server is not available, or the installation requires a speedy solution.
  • Page 7 Manual 3. GENERAL PRODUCT INFORMATION 3.1. Scope of delivery 1x CLUSTER S2 Power cord with plug (EU country specific, if not ordered differently) Pre-installed PUK We´re offering a wide range of professional accessories (optional). Please see under menu 6 or at our website www.roxxlight.com...
  • Page 8 4. INSTALLATION & SETUP 4.1 Physical Installation and Rigging ROXX CLUSTER S2 may be installed in any orientation. For this purpose the product provides several options: Standing: The fixtures Yoke includes two M8 inner threads to install the optional ROXX YOKE FLOOR EXTENSION.
  • Page 9 A: 3x Camlock with ¼ turn adapters B: 3x M12 / ½“ C: 1x TV Spigot 3. Using optional ROXX RIGGING BRACKET For seemless connection of multiple Blinders, to avoid gaps due to bracing of the truss structure by variable, sliding mounting positions.
  • Page 10 User User Manual Manual 2. Pre-Link Magnets on top and side help to allign the fix- tures due cluster process and giving support operation for convenient and save interlocking. Important Note: Even though the pre-link magnet system is strong enough to hold the devices to- gether, at least one hand must always remain on the device for support during the connection.
  • Page 11 User User Manual Manual The maximum loads listed here below take into account the 10-fold safety! 1. Rigging by integrated 1/4 turn Camlocks on top- or rear side Max. Tension Load: 90kg Max. Tension Load: 90kg Max. Torsion Load: 18.703 Nmm Max.
  • Page 12 Max. Tension Load: 88kg Max. Tension Load: 66kg Max. Torsion Load: 8.238Nmm Max. Torsion Load: 6.476Nmm 3. Using optional ROXX RIGGING BRACKET with 2x Mounting Clamps Max. Tension Load: 72kg Max. Torsion Load: 6.326 Nmm Important Note: Please be aware of using the centering PUK for safe RIGGING BRACKET installation to the...
  • Page 13 4.2.1. AC Power The CLUSTER S2 operates on any 100–260 V, 50/60 Hz AC mains power supply with a maximum power consump- tion of 1250W. Connect the fixture to AC power using the supplied cable or a similar one with Neutrik powerCON TRUE1 NAC3FX-W or a compatible type, to ensure the correct ingress protection (IP).
  • Page 14 User Manual 4.2.2. DMX Connection The CLUSTER S2 is fully controllable by DMX (USITT DMX512-A standard, based on RS-485) Art-Net, sACN and RDM. 4.2.2.1. Cable Connection If using a cabled DMX system, connect the DMX IN cable to the input connector (male 5-pin XLR connector) and DMX OUT cable to the output (female 5-pin XLR connectors).
  • Page 15 Once the fixture is connected to AC power, the boot process starts and the following information will appear on the display: “Ready to ROXX”, the product name and the current software version. After this process, the fixture is ready for operation, and starts in the previous- ly enabled mode.
  • Page 16 User User Manual Manual Display Off Pressing ESC + arrow down simultaneously the display backlight function will set to off and the display will turn off immediately. Once a control is pressed the display backlight will turn on. Manual display flip function* The fixture includes an auto display flip function by default.
  • Page 17 User User Manual Manual 5.4 Configuration Home Screen After boot process the fixture is ready for operation and starts in the previously enabled mode. At home screen the following information will appear, depending on the current operating mode: DMX Adress Operating Mode (DMX Mode, Quick Light or Standalone Mode) Next available DMX address depending on the fixtures DMX footprint External Data protocol (DMX / Art-Net / sACN).
  • Page 18 User User Manual Manual Level 1 Level 2 Menu DMX Mode DMX Mode 15CH Simple 31CH Easy Stand Alone 64CH Standard Settings 112CH Pure System Info 209CH Pure Mode 168 CH Full Access 265CH Full Access Extended 5.4.3 Stand Alone* Press ENTER to access to main menu (level 1).
  • Page 19 User User Manual Manual Level 1 Level 2 Level 3 Level 4 Menu Stand Alone Mode Auto Program DMX Mode Stop Stand Alone Stop Program Speed <0-100> Stand Alone Auto FX Effect 1 (Default 50) Settings Color Macro Effect 2 <0-100>...
  • Page 20 User User Manual Manual Level 4 Gels - Gels - Gels - Color Macros for Standalone Mode Color Macros for Standalone Mode Color Macros for Standalone Mode Pos. Gel Name Color Number Pos. Gel Name Color Number Pos. Gel Name Color Number 100% Red LED jade...
  • Page 21 User User Manual Manual Tunable White* The standalone mode “Tuneable White” allows the color temperature (CCT) to be adjusted from 2.000K – 10.000K in 100K steps and affects both RGB panels only. Besides brightness and shutter also a +/- green and magenta cor- rection is available.
  • Page 22 User User Manual Manual To define a User Color please press ENTER to access to main menu (level 1). While using the UP / DOWN arrows, please select the menu item “Stand Alone” and confirm by pressing ENTER. Select the item menu “User Color” by using the up/down controls and press ENTER. Using UP and DOWN select your desired preset number (Color 1 -5) and confirm with ENTER.
  • Page 23 User Manual Main Menu Menu Menu Menu Menu Remark Menu level 2 level 3 level 4 level 5 level 6 • 15CH Simple • 31CH Easy • 64CH Standard • 112CH Pure • 209CH Pure Mode Mode • 168 CH Full Access •...
  • Page 24 User Manual Main Menu Menu Menu Menu Menu Remark Menu level 2 level 3 level 4 level 5 level 6 Dimmer <0-100> Shutter <0-255> Tunable White CCT <2000K- (affetcs both RGB 10.000K> adjustable in 100K steps Panels) (default 5600K) 0= no function Tint 001--127 plus green <000>...
  • Page 25 User Manual Main Menu Menu Menu Menu Menu Remark Menu level 2 level 3 level 4 level 5 level 6 On= Flip control panel display by 180° (e.g. for Display Flip overhead installation) <on/off> Off= normal control panel dispaly On= controls permanent on , display itself will deactivate Backlight after 60 minues of incativity...
  • Page 26 User Manual Main Menu Menu Menu Menu Menu Remark Menu level 2 level 3 level 4 level 5 level 6 Calibration on RGB Panels Color Full Calibration for CCT & Colors Calibration (affetcs Calibrated DMX modes and Calibration on RGB Panels Stand Alone) CCT Calibration on CCT only, RAW Colors...
  • Page 27 User Manual Main Menu Menu Menu Menu Menu Remark Menu level 2 level 3 level 4 level 5 level 6 Normal output for constant Illumination illumination LED Mode Boost for temporarily hig- Boost hest output for blinder and strobe effects Run firmware update via USB port / keeps the current DMX Address...
  • Page 28 User Manual Main Menu Menu Menu Menu Menu Remark Menu level 2 level 3 level 4 level 5 level 6 RAW Balance <RAW/User Calibrated> LED Frequency <800Hz, 1200Hz, 2000Hz, 3600Hz, 12000Hz, 25000Hz> Fan <Auto, Silent, Fan Off, Max. Power> Factory / Select your User Settings User Reset List...
  • Page 29 User User Manual Manual Dimmer Curves LINEAR EXPONENTIAL LOGARITHMIC S-CURVE 5.4.6 System Info Level 1 Menu DMX Mode Stand Alone Slave Settings System Info Main Menu Menu level 2 Menu level 3 Menu level 4 Firmware Version vx.xx Display installed firmware version Serial Number 204xxxxxxxx RDM UID...
  • Page 30 User User Manual Manual 6. ACCESSORIES Yoke 2.2 Yoke 4.3 Floor Extension Rigging Bracket Art.: 13907001 Art.: 13907101 Art.: 13907411 Art.: 13907201 Omega Bracket ST Case 4 pcs. / 8 pcs. Art.: 13907411 Art.: 90900002 Case 2 pcs / 4 pcs Art.: 13907511 FX Filterframe SC FX Filterframe EH FX Distance Frame...
  • Page 31 User User Manual Manual 7. TECHNICAL DATA / DIAGRAMS 7.1 Technical drawings and measurements 452.00 400.00 500.00 210.00 56.00...
  • Page 32 Manual 7.2 IP Rating ROXX products conform to officially classified IP standard levels. CLUSTER S2 is rated to IP65 when using the covers for the housing parts. IP stands for Ingress Protection and IP65, according to classified standard, means shielded against dust and high-pressure jets of water from any side.
  • Page 33 User User Manual Manual 7.3 Technical Data Photometrics LED expected lifetime 50.000 hours Lightsource 612x CW LED´s (7000K), 680x RGB LED´s Type of optical system native, elliptical lens LED PWM Frequency selectable 800Hz, 1.200Hz, 2.000Hz, 3.600Hz, 12kHz, 25kHz Beam angles @ Full (50%) 66°...
  • Page 34 User User Manual Manual 7.3 Technical Data Operator & Controller Simple Mode 15CH, Easy Mode 39CH, Standard Mode 72CH (default mode), Pure Mode 112CH Single Pixel 8 Bit with Strobefunction, Pure Mode 209CH Single Pixel DMX channels 16 Bit with Strobefunction, Full Access Mode 177CH 8 Bit single Pixel with Pattern, Full Access Extended Mode 274CH 16 Bit with Pattern DMX modes USITT DMX512A...
  • Page 35 DMX CHART Manual Manual 7.4 DMX-Charts / Color Macro Charts / CCT Chart Here you can find the DMX charts and Pattern Charts for the Cluster S2 15CH Simple Mode for reading or 39CH Easy Mode downloading. Simply click on the icon or scan the QR code.
  • Page 36 User User Manual Manual Color Macro Chart for Stand Alone Gels - Color Macros for Standalone Mode Gels - Color Macros for Standalone Mode Position Gel Name Color Number Position Gel Name Color Number 100% Red LED Lavender LEE 058 Fire LEE 019 Magenta...
  • Page 37 User User Manual Manual CTC channel DMX / Color temperature 10.000 9.500 9.000 8.500 8.000 7.500 7.000 6.500 6.000 5.500 5.000 4.500 4.000 3.500 3.000 2.500 DMX (step) 2.000...
  • Page 38 User User Manual Manual CTC-Chart Color Color Color Color Color Color Temp Temp Temp Temp Temp Temp (Step) (Step) (Step) (Step) (Step) (Step) (°K) (°K) (°K) (°K) (°K) (°K) 7000 4525 2774 3649 5400 6276 7000 4545 2794 3670 5421 6296 7000 2814...
  • Page 39 204 xxxx * Note: During RDM identifying process CLUSTER S2 flashes white to blue color alternately. RDM functions For easy identifying ROXX CLUSTER S2 during RDM process the unit will jump from white color to blue color every second. Function...
  • Page 40 User User Manual Manual Function Action Values 0x8065 Invert Mapping Centric Tube 0= Off / 1= On 0x8066 Invert Mapping Single Tube 1 0= Off / 1= On 0x8067 Invert Mapping Single Tube 2 0= Off / 1= On 0x8068 Invert Mapping Single Tube 3 0= Off / 1= On 0x8069...
  • Page 41 Hansestr. 91 51149 Köln Email: info@roxxlight.com or the ROXX authorized reseller in your country, from where you purchased your product. Correct Disposal of this product This is for the European Union and European countries with electrical waste collection systems. When this label is shown on the product or brochure it means that the item cannot be disposed with household waste.
  • Page 42 • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. CE Compliance The equipment marketed by ROXX GmbH complies (where applicable) with the essential requirements and other specifi cations of the following Directives: • 2014/30/EU (EMC) •...
