ROXX E.SHOW TW+ User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

User
Manual
E.SHOW TW+
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E.SHOW TW+ and is the answer not in the manual?

Questions and answers

Related Manuals for ROXX E.SHOW TW+

Summary of Contents for ROXX E.SHOW TW+

  • Page 1 User Manual E.SHOW TW+ USER MANUAL...

  • Page 2: Table Of Contents

    User Manual CONTENT 1. Safety Informations 1.1. General Preventive Measures 1.2. Regulations for equipment that connects to power mains 1.3. Technical warnsigns and explanation 2. Introduction 2.1. About us 2.2. E.SHOW TW+ 3. General Product Information 3.1. Scope of delivery 3.2.
  • Page 3 User Manual 7. Technical Data / Diagrams 7.1 Technical drawings and measurements 7.2 IP Rating 7.3 Technical Data 7.4 DMX-Charts / Color Macro Charts / CCT Chart 7.5 RDM Templates 8. Troubleshooting 9. Manufacturer´s Declaration...

  • Page 4: Safety Informations

    1.1.1. Please read, understand and follow the instructions. 1.1.2. Store the instructions and information in a safe place. Best solution is the ring binder provided by ROXX. 1.1.3. Follow all safety warnings. Under no circumstances remove safety warnings or other information from the equipment.

  • Page 5: Regulations For Equipment That Connects To Power Mains

    User Manual 1.1.20. Observe all disposal laws applicable in your country. Especially for the packaging. 1.1.21. Plastic bags are not a toy! Keep away from children! 1.1.22. Please note that changes or modifications which are not approved by the party responsible for compliance will void the user’s authority to operate the device.

  • Page 6: Technical Warnsigns And Explanation

    User Manual 1.3. Technical warnsigns and explanation In order to prevent the risk of an electric shock, under no circumstances remove the cover/back or open the unit in any way! No user serviceable parts are inside. Service, maintenance and repairs should only be done by qualified service personnel or the manufacturer.

  • Page 7: Introduction

    In addition to DMX and RDM control, Lumenradio‘s latest Wireless DMX technology (CRMX) enables wireless as well as fl exible control plus integrating a Bluetooth interface allows direct controlling via unique ROXX.APP without additional hardware. Covering all possible requirements, the fi xture includes an extensive range of accessories...

  • Page 8: General Product Information

    • Stand Alone Functions including cinema effects, various auto programs, customisable scenes, CCT, LEE adjusted color macros and custom color templates (RGBALC) • Master & Slave (by DMX and Wireless DMX) • Wireless DMX (Lumenradio CRMX ® • ROXX App - Bluetooth 5.0 3.3. Features...

  • Page 9: Installation & Setup

    Please take care that supporting surfaces are loadable and stable. Hanging: On the bottom the yoke provides 2 Camlock QuickRelease connectors. Here it´s possible to click in the ROXX Omega Bracket ST (optional accessory) equiped with any suitable clamp. Open...

  • Page 10: Connections

    Manual Pendant Light*: The sophisticated and attractive design of the ROXX E.SHOW TW+ makes the luminaire predestinated for the use as a pendant light, e.g. for exhibition booths, galas,… The position of the safety eyelet and the lamp body balancing makes that possible in a perfect way.

  • Page 11: Ac Power

    User Manual 4.2.1. AC Power The E.SHOW TW+ operates on any 100–260 V, 50/60 Hz AC mains power supply with a maximum power con- sumption of 220W. Connect the fixture to AC power using the supplied cable or a similar one with Neutrik powerCON TRUE1 NAC3FX-W or a compatible type, to ensure the correct ingress protection (IP).

  • Page 12: Wireless Connection

    Working in Receiver Mode: receive wireless DMX- and RDM Signals via CRMX Working in Transmitter Mode: transmit DMX (1 universe) to other units via CRMX Full Control via Bluetooth 5.0 and ROXX App The Fixture is able to send DMX-data received by CRMX or Bluetooth to its physical DMX-Output XLR Connector and hereafter, plugged in by cable, to any DMX-capable unit.
  • Page 13 User Manual 4.2.2.2. Wireless Connection CRMX Enabled • CRMX(TX) The indicator infront of "CRMX Operation Mode (TX)" shows that the fixture is now working in wireless DMX 9 CH Linked transmit mode. Receive Reset Next "(TX)"= CRMX operating mode Disconnect ( 10 ) is set to transmit BLE (Bluetooth)
  • Page 14 BLE (Bluetooth) Enabled + Paired DMX). CRMX Enabled CRMX(TX) Operation Mode No indicator infront of "BLE", 9 CH Linked fixture is not paired to ROXX Receive Reset App. Next Disconnect ( 10 ) BLE (Bluetooth) Enabled, not paired Enabled CRMX...

  • Page 15: Operation

    Once the fixture is connected to AC power, the boot process starts and the following information will appear on the display: “Ready to ROXX”, the product name and the current software version. After this process, the fixture is ready for operation, and starts in the previous- ly enabled mode.
  • Page 16 User Manual Display Off Pressing ESC + arrow down simultaneously the display backlight function will set to off and the display will turn off immediately. Once a control is pressed the display backlight will turn on. BLE enabled / disabled Pressing ESC + Arrow Up simultaneously the Bluetooth will enabled or disabled.

  • Page 17: Configuration

    User Manual 5.4 Configuration Home Screen After boot process the fixture is ready for operation and starts in the previously enabled mode. At home screen the following information will appear, depending on the current operating mode: DMX Adress Operating Mode (DMX Mode, Quick Light or Standalone Mode) Next available DMX address depending on the fixtures DMX footprint External Data protocol (CRMX, DMX, BLE).

  • Page 18: Stand Alone

    User Manual Level 1 Level 2 Menu DMX Mode DMX Mode 3CH CCT – Factory Calibrated Stand Alone 3CH RGB – Factory Calibrated Slave 6CH RGB – Factory Calibrated Settings 9CH RGB (Default) – Factory Calibrated 11CH RGB – Factory Calibrated System Info 14CH RGB –...
  • Page 19 User Manual After confirming your preferred Auto Program, you can now adjust speed and brightness at level 4. To adjust speed, please use the UP / DOWN arrows to select the menu item “Speed”, and confirm with ENTER. After use UP / DOWN arrows to adjust the speed value between 000-100 and confirm by ENTER or jump back by ESC. To adjust brightness please select “Dim”...
  • Page 20 User Manual Level 1 Level 2 Menu Stand Alone Mode DMX Mode Stop Stand Alone Stand Alone Auto Slave Editor Settings Color Macro Quick Color System Info Tunable White User Color Timer Color Settings Select “Editor” by using the up/down arrows and press ENTER. Here at sub-menu (level 3) you can choose between Program 1-3, Dimmer and Stop Program.
  • Page 21 User Manual Color Macro* 46 different color macros (34x matched LEE color filters, 6 LED colors and 6 different Whites) are available as presets. For each the brightness can be adjusted separately. Level 1 Level 2 Level 3 Menu Stand Alone Mode Color Macro DMX Mode Stop Stand Alone...
  • Page 22 User Manual Quick Color* The standalone mode “Quick Color” allows a direct adjustment of the single LED colors R, G, B, A, L, C, Dimmer and Shutter. Level 1 Level 2 Level 3 Menu Stand Alone Mode Quick Color DMX Mode Stop Stand Alone Dimmer <0-100>...
  • Page 23 User Manual After please select the item “Tunable White” by using the up/down arrows and press ENTER again. Using UP and DOWN controls to select your desired menu item, confirm by ENTER and adjust the desired value by up and down controls and confirm all entries with ENTER. * Note: Tint values = no function/neutral...
  • Page 24 User Manual Timer* Via the internal timer function, all Stand Alone modes except "Auto" and "Editor" can be conveniently faded in and out after the function is enabled in the previously activated standalone mode, without the need for an external controller. Also it remains active even the fixture is switched off and restarted.

  • Page 25: Slave Mode

    User Manual Level 1 Level 2 Level 3 Menu Stand Alone Mode Color Settings DMX Mode Stop Stand Alone Factory Calibrated Stand Alone Auto Slave Editor Settings Color Macro Quick Color System Info Tunable White User Color Timer Color Settings 5.4.4 Slave Mode* Slave Mode allows same model fixtures to be controlled by the “Master”...
  • Page 26 User Manual Main Menu Menu level 2 Menu level 3 Menu level 4 Description CRMX <on/off> On=CRMX enabled / Off= CRMX disabled Receive= CRMX module as Receiver Operating Mode <receive/transmit> Transmit= CRMX module as Transmitter Yes= pair with CRMX devices. CRMX must be activated on all devices and the pairing must be Transmit Link <no/yes>...
  • Page 27 User Manual Main Menu Menu level 2 Menu level 3 Menu level 4 Description The LED responds abruptly to it´s DMX values Dimmer Response The LED responds similar to a halogen fixture Halogen with soft changes at brightness. <0-255> RAW Balance Green <0-255>...
  • Page 28 User Manual Main Menu Menu level 2 Menu level 3 Menu level 4 Menu Level 5 Description DMX Mode. 3CH CCT, 3CH RGB, 6CH RGB, 9CH RGB, 11CH RGB, 14CH RGB, 6CH DIRECT, 12CH DIRECT, 13CH DIRECT, 20CH DIRECT, <3CH HSI, 10CH HSI CRMX <on/off>...

  • Page 29: System Info

    User Manual 5.4.6 System Info Level 1 Menu DMX Mode Stand Alone Slave Settings System Info Main Menu Menu level 2 Menu level 3 Menu level 4 Display installed firmware version Firmware Version vx.xx Serial Number 102xxxxxxxx Display unique RDM ID for identification RDM UID 0X6a6axxxxxxxx Celsius...

  • Page 30: Accessories

    User Manual 6. ACCESSORIES 6.1 Lenses Available lenses for ROXX E.SHOW black with order numbers: Narrow Medium Wide Elliptical Narrow Elliptical Wide Art.: 11207001 Art.: 11207101 Art.: 11207201 Art.: 11207301 Art.: 11208201 Lens matrix: SHOW TW+ SHOW FC SHOW T...

  • Page 31: More Accessories

    User Manual 6.2 More accessories Accessory Holder 8-way barndoor Gel-frame Honey comb Art.: 11907401 Art.: 11907501 Art.: 11907701 Art.: 11907601 Omega Bracket ST Softbox by DoPchoice Snapgrid by DoPchoice Full anti-glare shield Art.: 90900002 Art.: 11908301 Art.: 11908301 Art.: 11208401 Touring case 8 Art.: 11908001...
  • Page 32 User Manual 7. TECHNICAL DATA / DIAGRAMS 7.1 Technical drawings and measurements...
  • Page 33 7.2 IP Rating ROXX products conform to officially classified IP standard levels. E.SHOW TW+ is rated to IP65 when using the co- vers for the housing parts. IP stands for Ingress Protection and IP65, according to classified standard, means shielded against dust and high-pressure jets of water from any side.
  • Page 34 User Manual 7.3 Technical Data Photometrics LED expected lifetime 50.000 hours Lightsource 1x230W RGBALC reflector + interchangable lens plates Type of optical system LED PWM Frequency selectable 800Hz, 1200Hz, 2000Hz, 3600Hz, 12kHz, 25kHz 19° (with narrow lens) 36° (with medium lens) Beam angles (50%) 59°...
  • Page 35 User Manual 7.3 Technical Data Operator & Controller DMX channels 3CH CCT, 3/6/9/11/14CH RGB, 6/12/13/20CH DIRECT, 3/10CH HSI DMX modes CRMX, W-DMX™ G2, W-DMX™ G3, W-DMX™ G4, W-DMX™ G4S USITT DMX512A Protocol RDM ANSI E1.20 Bluetooth (Low Energy) OLED graphical display / 4 controls Setting and addressing RDM ANSI E1.20 Standalone mode...
  • Page 36 User DMX CHART Manual 7.4 DMX-Charts / Color Macro Charts / CCT Chart 3CH CCT 6CH DIRECT 3CH RGB 12CH DIRECT 6CH RGB 13CH DIRECT 9CH RGB / Default Mode 20CH DIRECT 11CH RGB 3CH HSI 14CH RGB 10CH HSI 3 CH CCT MODE (Factory Calibrated) - 8bit Function Value...
  • Page 37 DMX CHART 9 CH - RGB (Factory Calibrated Mode) - 8bit / Default Mode Function Value Setting Dimmer 000-255 0 - 100% 000 - 019 Shutter close 020 - 024 Shutter open 025 - 064 Strobe 1 (fast slow) 065 - 069 Shutter open 070 - 084 Strobe 2: opening pulse (fast...
  • Page 38 DMX CHART 11 CH RGB Mode (Factory Calibrated) - 8bit Function Value Setting Dimmer 000-255 0 - 100% 000 - 019 Shutter close 020 - 024 Shutter open 025 - 064 Strobe 1 (fast slow) 065 - 069 Shutter open 070 - 084 Strobe 2: opening pulse (fast slow)
  • Page 39 DMX CHART 000 - 005 no function Color Macro 006-105 0,1s - 10s (0,1s steps) Crossfade (Transition Time 106-214 11s - 119s (1s steps) between Color 215-244 2m - 4m50s (10s steps) Macros) 245-255 5m - 15m (1m steps) 000-029 No function 030-034 Linear Dimmer Curve (hold 3s)
  • Page 40 DMX CHART 000 - 019 Shutter close 020 - 024 Shutter open 025 - 064 Strobe 1 (fast slow) 065 - 069 Shutter open 070 - 084 Strobe 2: opening pulse (fast slow) 085 - 089 Shutter open 090 - 104 Strobe 3: closing pulse (fast slow) 105 - 109...
  • Page 41 DMX CHART 000 - 005 no function Color Macro 006-105 0,1s - 10s (0,1s steps) Crossfade (Transition Time 106-214 11s - 119s (1s steps) between Color 215-244 2m - 4m50s (10s steps) Macros) 245-255 5m - 15m (1m steps) 000-029 No function 030-034 Linear Dimmer Curve (hold 3s)
  • Page 42 DMX CHART 12 CH - DIRECT MODE (RAW) - 16bit Function Value Setting 000-255 0 - 100% Red Fine 000-255 0 - 100% Green 000-255 0 - 100% Green Fine 000-255 0 - 100% Blue 000-255 0 - 100% Blue Fine 000-255 0 - 100% Amber...
  • Page 43 DMX CHART Amber 000-255 0 - 100% Lime 000-255 0 - 100% RGBALC Fade to 100% = CTC Cyan 000-255 0 - 100% 000 - 004 005-226 2000K-6500K (please see detailed CTC chart) 182-182 5600K (affects RGBALC) 226-226 6500K 227-255 6621K-10.000K (please see detailed CTC chart) no function Tint...
  • Page 44 DMX CHART 150-154 Fan High Power (hold 3s) 155-159 No function 160-164 Redshift On (hold 1,5s / affects only between 2700-3500K) Device Settings 165-169 Redshift Off (hold 1,5s) (please see remark 170-179 No function 180-184 Factory Reset (hold 3s / except User Reset defaults) 185-189 User Reset (hold 3s) 190-255...
  • Page 45 DMX CHART Lime 000-255 0 - 100% Lime Fine 000-255 0 - 100% RGBALC Fade to 100% = CTC Cyan 000-255 0 - 100% Cyan Fine 000-255 0 - 100% 000 - 004 005-226 2000K-6500K (please see detailed CTC chart) 182-182 5600K (affects RGBALC)
  • Page 46 DMX CHART 140-144 Fan Studio (hold 3s) 145-149 Fan Off (hold 3s) 150-154 Fan High Power (hold 3s) 155-159 No function Device Settings 160-164 Redshift On (hold 1,5s / affects only between 2700-3500K) (please see 165-169 Redshift Off (hold 1,5s) remark *1) 170-179 No function...
  • Page 47 DMX CHART 000-255 0° (RED) Thru 360° Satuation 000-255 0 - 100% (CTC HUE) 000 - 004 5600K 005-226 2000K-6500K (please see detailed CTC chart) (affects HUE, 182-182 5600K Saturation) 226-226 6500K 227-255 6621K-10.000K (please see detailed CTC chart) no function Tint 001-127 Magenta...
  • Page 48 DMX CHART 165-169 Redshift Off (hold 1,5s) 170-179 No function Device Settings (please see 180-184 Factory Reset (hold 3s / except User Reset defaults) remark *1) 185-189 User Reset (hold 3s) 190-255 No function Remark *1 - After adjustments please set the value back to 000 to avoid any disturbance by endless function call. Color Macro Chart for DMX Gels - Color Macros for DMX Gels - Color Macros for DMX...
  • Page 49 User Manual Color Macro Chart for Stand Alone Gels - Color Macros for Standalone Mode Gels - Color Macros for Standalone Mode Position Gel Name Color Number Position Gel Name Color Number 100% Red LED Lavender LEE 058 Fire LEE 019 Magenta LEE 113 Medium Red...
  • Page 50 User Manual CTC channel DMX / Color temperature 10.000 9.500 9.000 8.500 8.000 7.500 7.000 6.500 6.000 5.500 5.000 4.500 4.000 3.500 3.000 2.500 DMX (step) 2.000...
  • Page 51 User Manual CTC-Chart Color Color Color Color Color Color Temp Temp Temp Temp Temp Temp (Step) (Step) (Step) (Step) (Step) (Step) (°K) (°K) (°K) (°K) (°K) (°K) 5600 4525 2774 3649 5400 6276 5600 4545 2794 3670 5421 6296 5600 4566 2814 3690...
  • Page 52 0102 xxxx * Note: During RDM identifying process E.SHOW TW+ flashes white to blue color alternately. RDM functions For easy identifying ROXX E.SHOW TW+ during RDM process the unit will jump from white color to blue color every second. Function...
  • Page 53 Bluetooth is disabled at your mobile Please eanble Bluetooth at your mobile device device settings. Please use same Bluetooth Pin to connect ROXX. APP with the fixture. Current BLE Pin can be read Mobile device has wrong Bluetooth Pin out inside fixture´s wireless DMX settings.
  • Page 54 ROXX GmbH, Hansestr. 91, 51149 Köln Email: info@roxxlight.com or the ROXX authorized reseller in your country, from where you purchased your product. Correct Disposal of this product This is for the European Union and European countries with electrical waste collection systems. When this label is shown on the product or brochure it means that the item cannot be disposed with household waste.
  • Page 55 User Manual CE Compliance The equipment marketed by ROXX GmbH complies (where applicable) with the essential requirements and other specifications of the following Directives: • 2014/53/EU (RED) • 2014/30/EU (EMC) • 2014/35/EU (LVD) • 2011/65/EU (RoHS) The complete EU- and UK-Declaration of Conformity can be found at www.roxxlight.com/support, or you can also request it at info@roxxlight.com...
