PROGRAM SECTION
1/4" TS + XLR Combo Jack input with
preamplifier gain control, switchable
envelope trigger, and hold.

ABOUT SPECTRAVOX

Spectravox is a semi-modular analog spectral processor based around a 10-band resonant filter bank
that explores and expands the topology of the vocoder. Spectravox is both a standalone synthesizer
voice with a sculptable frequency spectrum and a 10-band vocoder with integrated modulation, able
to shift its filter bank across the audible spectrum. With a comprehensive patch bay and conforming
to the 60HP Eurorack standard, Spectravox can be combined with the other Moog semi-modular
instruments or inserted into any Eurorack setup.
CARRIER SECTION
PAGES 25 & 26
Selectable Sawtooth/Pulse wave
Voltage-Controlled Oscillator (VCO) with Pulse
Width Modulation (PWM) and a VCO/Carrier
and noise crossfader.
8
PAGE 24
