CARRIER
(Continued)
PULSE WIDTH
PULSE WIDTH
This sets the pulse width of the VCO when PULSE is selected via the VCO
WAVE switch. Turning PULSE WIDTH results in a pulse width of about 1% duty
cycle at a minimum to about 50% at maximum.
CARRIER MIX
CARRIER MIX
With crossfader blending between the VCO signal and the NOISE signal, the
resulting mix is sent into the synthesis filter bank. Patching a signal to the
CARRIER input on the patch bay will replace the VCO signal with whatever
signal is present at the CARRIER input.

PROGRAM

The PROGRAM section of Spectravox sends the signal
connected to the PROGRAM INPUT into the analysis filter
bank—whose outputs are the 10 envelope followers (1
ENV F, 2 ENV F ... 10 ENV F). The PROGRAM signal thus
animates the synthesis filter bank when Spectravox is in
VOCODER mode.
25
