- Page 1 SERVICE MANUAL E260CSR Crawler Excavator Part number 48090747 English February 2017...
- Page 2 GENERAL SAFETY INFORMATION INDEX NHK-EUR E260CSR(N)LC Book Code No. Index 25 1 Title Distribution Year-Month S5YN0129E01 OUTLINE 2012-02 S5YF0213E01 SPECIFICATIONS 2012-02 S5YF0313E01 ATTACHMENT DIMENSIONS 2012-02 S5YF1113E01 TOOLS 2012-02 STANDARD MAINTENANCE S5YF1213E01 TIME SCHEDULE 2012-02 MAINTENANCE STANDARD S5YF1313E01 AND TEST PROCEDURE...
- Page 3 GENERAL SAFETY INFORMATION NOTE: This Manual is prepared as a technical material in This Manual may be properly revised due to the im- which the information necessary for the maintenance provement of products, modification of specifications, and repairing services of our hydraulic excavators are etc.
-
Page 4: Table Of Contents
1. OUTLINE 1. OUTLINE TABLE OF CONTENTS GENERAL PRECAUTIONS FOR MAKING REPAIRS ........1-3 1.1.1 PREPARATION BEFORE DISASSEMBLING ..........1-3 1.1.2 SAFETY WHEN DISASSEMBLING AND ASSEMBLING ......1-3 1.1.3 DISASSEMBLING AND ASSEMBLING HYDRAULIC EQUIPMENT ..1-4 1.1.4 ELECTRICAL EQUIPMENT ................ 1-6 1.1.5 HYDRAULIC PARTS ................... - Page 5 ↑ ↑ December, 2011 E140CSR : YH07-09001~ (NHK-EUR) ↑ ↑ ↑ SK140SRLC-3 : YH07-09001~ (NA) ↑ ↑ February, 2012 E260CSR(N)LC : YU07-04001~ (NHK-EUR) ↑ ↑ ↑ 260SR : YU07-04001~ (NA) ↑ E230CSR : YB07- ↑ ↑ E230CSRLC : LA07-03001~ (NHK-EUR) ↑...
-
Page 6: General Precautions For Making Repairs
1. OUTLINE GENERAL PRECAUTIONS FOR MAKING REPAIRS 1.1.1 PREPARATION BEFORE DISASSEMBLING Read Operator's Manual before disassembling (1) Knowledge of operating procedure Read Operator's Manual carefully to understand the operating procedure. (2) Cleaning machines Clean machines of soil, mud, and dust before carrying into the service shop. Carrying a soiled machine into the service shop, causes making less efficient work and damage of parts. -
Page 7: Disassembling And Assembling Hydraulic Equipment
1. OUTLINE 1.1.3 DISASSEMBLING AND ASSEMBLING HYDRAULIC EQUIPMENT (1) Removing hydraulic equipment assy 1. Before removing pipes, release the pressure of hydraulic oil tank, or open the cover on the return side to tank, and take out the filter. 2. Drain the oil in the removed pipes into pan to prevent the oil from spilling on the ground. 3. - Page 8 1. OUTLINE (5) Installing hydraulic equipment 1. Confirm hydraulic oil and lubrication oil. 2. Air release is required in the following cases ; a. Change of hydraulic oil b. Replacement of parts on suction pipe side c. Removing and attaching hydraulic pump d.
-
Page 9: Electrical Equipment
1. OUTLINE 1.1.4 ELECTRICAL EQUIPMENT (1) The disassembly of electrical equipment is not allowed. (2) Handle equipment with care so as not to drop it or bump it. (3) Connector should be removed by unlocking while holding the connector. Never stress in tension to the caulked section by pulling wire. (4) Check that connector is connected and locked completely. - Page 10 Download the full PDF manual instantly. Our customer service e-mail: aservicemanualpdf@yahoo.com...
