Russell Hobbs 22000-56 - Coffee Maker Manual

BEFORE USING FOR THE FIRST TIME

• Fill the reservoir to the max mark, and run the appliance without coffee.


GROUND COFFEE

• If you buy ground coffee, medium filter-ground coffee will give you the best results.


FILLING

1. Unplug the appliance.
2. Remove the carafe from the hotplate.
3. Open the reservoir lid.
4. Fill the reservoir with the exact amount of water required.
   1. Use at least 2 cups of water if you're using ground coffee.
   2. Use at least 4 cups of water if you're using coffee beans.
   3. Don't fill above the max mark.
5. Close the reservoir lid
6. Squeeze the catch into the end of the filter lid, and open it fully.
7. Put the exact amount of coffee into the filter.
   1. Use 1 level tablespoonful of ground coffee for each cup.
   2. Use 1 heaped tablespoonful of whole beans for each cup.
   3. The number of tablespoons of coffee must match the number of cups of water.
8. Close the filter lid, and press down to engage the catch.

DIAGRAMS

1. filter

1. grinder
2. filter holder
3. catch
4. filter lid
5. reservoir lid
6. hotplate
7. carafe

press

SWITCH ON

9. Replace the carafe on the hotplate.
10. Put the plug into the power socket.

• The display will glow, showing 12:00 blinking and + 12 (12 cups).

COFFEE NOW

11. Ignore the display.
12. Use the button to cycle the bottom of the display to the grind setting you need:
    = you're using ground coffee
    + 4, 6, 8, 10, or 12 = you're using coffee beans + the number of cups/tablespoon
13. Press the button – If you're using coffee beans, the grinder will operate.
14. Shortly afterwards, coffee will start to drip into the carafe.
    • If you want to stop the coffee maker while it's brewing, press the button. The light will go off.
15. When it's done, the hotplate will keep the carafe warm.
16. The display will count up, to show how long the keep warm function has been operating.
17. After a set time, the heater will switch off, the display will stop glowing, and the appliance will go into standby mode.
18. To wake the appliance, press the button.

• The default keep warm time is 40 minutes.
• You may change this – see below.
• After about 40 minutes, chemical changes will affect the taste of the coffee.

COFFEE LATER

19. Set the clock to the correct time.
    1. Use the h and min buttons to set the correct hour and minute.
    2. It's a 12 hour clock – the display shows PM for afternoon.
    3. If you overshoot, you can't step back.
    4. The clock will retain its settings until the coffee maker is unplugged.
20. Set the timer to the time you want to start brewing.
    1. Press and release the button.
    2. " " will blink on the display.
    3. If you don't press anything for 5 seconds, the display will revert to normal.
    4. You'll have to press the button, and start again.
    5. Use the h and min buttons to set the correct hour and minute.
    6. When you've set the time, wait 5 seconds, and the display will revert to normal.

ACTIVATION

21. Press the button to activate the timer.
    • will show on the display.
22. To cancel the timer before brewing has started, press the button again.

KEEP WARM TIME

23. The default keep warm time is 40 minutes.
24. To change this, press the button, and hold it in for 3 seconds.
    • The display will show the current keep warm time.
25. Use the min button to choose the keep warm time you want – the options are 00, 20, 30, and 40 minutes after brewing has finished.
26. Press the button again, to activate your choice.

BREW STRENGTH

27. Use this feature if you prefer your coffee a bit stronger. It slows the brewing process, lengthening the time the water is in contact with the coffee.
28. Use the button to choose the setting you want – the setting shows in the bottom right corner of the display:
    blank = normal strength (the default setting)
    = stronger
    = even stronger

*If you want to change these settings, you should do so before making coffee.

A QUICK CUP

29. You can remove the carafe at any time. To prevent the filter holder overflowing, replace the carafe on the hotplate within about 20 seconds.

CARE AND MAINTENANCE

30. Unplug, and let the appliance and carafe cool down fully before cleaning, or for about 10 minutes before refilling.
31. Tip the contents of the filter into the bin.
32. Hand wash the carafe, filter, and filter holder.
33. Press the lever at the rear of the carafe lid, above the handle, to open the carafe lid.
34. Clean the outside surfaces of the appliance with a damp cloth.
35. Don't put any part of the appliance in a dishwasher.

Descale regularly, (at least monthly).

30. Descale the appliance at least monthly with a proprietary descaler. Follow the instructions on the package of descaler.

*Products returned under guarantee with faults due to scale will be subject to a repair charge.

IMPORTANT SAFEGUARDS

Read the instructions, keep them safe, pass them on if you pass the appliance on. Remove all packaging before use.

Follow basic safety precautions, including:

1. This appliance can be used by persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been supervised/instructed and understand the hazards involved.
   • Children must not use or play with the appliance.
   • Keep the appliance and cable out of reach of children.

Don't immerse the appliance in liquid.
The surfaces of the appliance will get hot. Residual heat will keep the surfaces hot after use.
Misuse of the appliance may cause injury.

2. Unplug the appliance before assembly, disassembly, or cleaning.
3. Don't leave the appliance unattended while plugged in.
4. If the cable is damaged, it must be replaced by the manufacturer, its service agent, or someone similarly qualified, to avoid hazard.
5. Sit the appliance on a stable, level, heat-resistant surface.
6. Don't use accessories or attachments other than those we supply.
7. Don't use the appliance for any purpose other than those described in these instructions.
8. Don't use the appliance if it's damaged or malfunctions.

household use only
