REFRIGERATOR TABLE TOP
SERVICE MANUAL
Model
OCM 90 TS A+
Specifications are subject to possible modifications without prior notice.
Les présentes spécifications sont susceptibles d'être modifiées sans préavis.
Las especificaciones estàn sujetas a cambios sin previo aviso
Pictures are only sketches which may be different from your equipment.
Les images sont seulement de croquis qui peuvent être différentes du design de votre équipement.
Las imágenes son sólo los bosquejos que pueden ser diferentes de su equipo.

Advertisement

loading
Need help?

Need help?

Do you have a question about the SILENTRON SG 8640 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ocean SILENTRON SG 8640

Summary of Contents for Ocean SILENTRON SG 8640

  • Page 1 REFRIGERATOR TABLE TOP SERVICE MANUAL Model OCM 90 TS A+ Specifications are subject to possible modifications without prior notice. Les présentes spécifications sont susceptibles d'être modifiées sans préavis. Las especificaciones estàn sujetas a cambios sin previo aviso Pictures are only sketches which may be different from your equipment. Les images sont seulement de croquis qui peuvent être différentes du design de votre équipement.

  • Page 2: Customer Support

    REFRIG. TABLE TOP OCM 90 TS A+ CUSTOMER SUPPORT ASSEMBLE & DISASSEMBLE A- Changing The Door Swing Direction to Right Hand 1- Lie down the appliance to the left side. (FIG-1) Figure - 1 2- Dismantle both leveling foot. (FIG-2) Figure - 2 3- Unscrew the bottom hinge fixing screws and remove it.
  • Page 3 REFRIG. TABLE TOP OCM 90 TS A+ CUSTOMER SUPPORT ASSEMBLE & DISASSAMBLE 4- Remove the door. (FIG-4) Figure - 4 5 - Unscrew the right pin of the top hinge (FIG-5.1) Screw the pin on the left hole of the top hinge (FIG-5.2) Figure - 5.1 Figure - 5.2...
  • Page 4 REFRIG. TABLE TOP OCM 90 TS A+ CUSTOMER SUPPORT ASSEMBLE & DISASSAMBLE 6- Replace the top bushing and top bushing cap. (FIG-6) (You can use the bushing cap that is put in the user manuel bag) Remove the bottom bushing and assemble it to the left side. (FIG-6) Figure - 6 7- Assemble the door to the top hinge.
  • Page 5 REFRIG. TABLE TOP OCM 90 TS A+ CUSTOMER SUPPORT ASSEMBLE & DISASSAMBLE B- Changing The Freezer Door Swing Direction : 1. Remove the freezer door hinge cover. (FIG-1) Unscrew the two screws fixing the freezer door hinge and remove the freezer door (FIG-2) Figure - 1 Figure - 2 2.
  • Page 6 REFRIG. TABLE TOP OCM 90 TS A+ CUSTOMER SUPPORT ASSEMBLE & DISASSAMBLE C - Changing The Thermostat : 1) Remove the lamp cover and unscrew the fixing screw. 2) Remove the screw cap and unscrew the fixing screw. 3) Remove the thermostat box by pulling it and disconnecting the wire connector. 4) Remove the thermostat knob by pulling forward.

  • Page 7: Suction Tube

    REFRIG. TABLE TOP OCM 90 TS A+ REFRIG. TABLE TOP OCM 90 TS A+ CUSTOMER SUPPORT REFRIGERANT CYCLE DIAGRAM R.EVAPORATOR CONDENSER SUCTION TUBE COMPRESSOR...
  • Page 8 Sede Legale: via Leone XIII n°14 – 20145 Milano ITALY Cap. Soc. Euro 2.500.000,00 – Società con Socio Unico R.E.A. Milano 1544616 Cod. Fisc. – Part. IVA e n° Registro Imprese: 12287310150 www.ocean.it For product improvement, specifications and appearance in this manual are subject to change without prior notice.
