AIRFORCE centrale b2 Instruction On Mounting And Use Manual

Hide thumbs

Advertisement

Table of Contents

aspira induction
Model:
centrale b2
MONTAGE- UND GEBRAUCHSANWEISUNG
D
GB
INSTRUCTIONS ON MOUNTING AND USE
F
PRESCRIPTIONS DE MONTAGE ET MODE D'EMPLOI
NL
MONTAGEVOORSCHRIFTEN EN GEBRUIKSAANWIIZING
ES
MONTAJE Y MODO DE EMPLEO
ISTRUZIONI DI MONTAGGIO E D'USO
I

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the centrale b2 and is the answer not in the manual?

Questions and answers

Related Manuals for AIRFORCE centrale b2

Summary of Contents for AIRFORCE centrale b2

  • Page 1 Model: centrale b2 MONTAGE- UND GEBRAUCHSANWEISUNG INSTRUCTIONS ON MOUNTING AND USE PRESCRIPTIONS DE MONTAGE ET MODE D’EMPLOI MONTAGEVOORSCHRIFTEN EN GEBRUIKSAANWIIZING MONTAJE Y MODO DE EMPLEO ISTRUZIONI DI MONTAGGIO E D’USO...
  • Page 3 WARNINGS Caution his instruction handbook is conserved together with the centrale b2 for future consultation. If the equipment is sold or transferred to another person, make certain the instruction handbook is supplied together with it, so that the new user can become aware of the operation of the cooker hood and related warnings.
  • Page 4 ANWEISUNGEN WARNINGS leaning and maintenance must not be carried out by children without proper supervision. f the power cord is damaged, it must be replaced by a qualified service centre or technician only. he electrical installation must have a breaker upstream from the appliance which ensures that all poles are disconnected with a contact gap of at least 3mm.

  • Page 5: Fire Hazard

    ANWEISUNGEN WARNINGS he induction hob should not be used as a work surface. The rough underside of food containers can scratch the surface of the cooktop. lways keep the cooking areas and underside of food containers perfectly dry. Fire hazard il and grease that are too hot will catch fire quickly.

  • Page 6: Burn Hazard

    ANWEISUNGEN WARNINGS Burn hazard AUTION: This appliance and its accessible parts become very hot during use. ay attention to avoid touching the heating elements. eep children under 8 years of age away from the appliance, unless they are continually monitored. o not place objects such as knives, forks, spoons or lids on the induction top, as they may overheat.
  • Page 7 ANWEISUNGEN WARNINGS Non-suitable food containers ever use recipients made of: normal finegrained steel, glass, pottery, copper and aluminium. Do not place empty containers on the cooking zone, as they may cause damage. o not place hot recipients on the control panel, in the area of the pilot lights or on the edge of the cooking top, as they may cause damage.
  • Page 8 ANWEISUNGEN WARNINGS ny interventions or repairs on the unit during the warranty period must be carried out solely by the manufacturer’s authorised service centre; conversely, the warranty will be is invalidated and terminated immediately. The manufacturer will not recognise any warranties under any circumstances for any problems subsequently encountered.

  • Page 9: Noise Emissions

    ANWEISUNGEN WARNINGS Noise emissions nduction can generate slight noise emissions, which can vary depending on the material, type of pot and power setting selected. When the cooktop is used frequently, the cooling fan turns itself on to protect the electronics, generating a buzzing sound: this is perfectly normal.
  • Page 10 Fig.1 Min.160 mm Schublade Drawer Tiroir Schuif Cajón Cassetto...

  • Page 11: Technical Drawing

    Technical drawing...
  • Page 12 X + 515 X + 495 ) X ( X + 406 X - 6 MIN 820/MAX 975 X + 88 X + 216 X + 212...
  • Page 13 4 verschiedene Weisen installiert werden; wählen sie den Montagetyp, der am besten zu ihrem Küchenmöbel passt. centrale b2 can be installed in 4 different modes to better suit the layout of every kitchen; choose the mounting type that is more suitable for your furniture.
  • Page 14 Installation Version 1 Installatie versie 1 Installation version 1 Versión de instalación 1 Installation version 1 Installazione versione 1...
  • Page 15 Installation Version 1 Installatie versie 1 Installation version 1 Versión de instalación 1 Installation version 1 Installazione versione 1 MIN 820 / MAX 975 O 70 X-10 R 10...
  • Page 16 Installation Version 2 Installatie versie 2 Installation version 2 Versión de instalación 2 Installation version 2 Installazione versione 2...
  • Page 17 Installation Version 2 Installatie versie 2 Installation version 2 Versión de instalación 2 Installation version 2 Installazione versione 2 MIN 820 / MAX 975 X-10 R 10...
  • Page 18 Installation Version 3 Installatie versie 3 Installation version 3 Versión de instalación 3 Installation version 3 Installazione versione 3...
  • Page 19 Installation Version 3 Installatie versie 3 Installation version 3 Versión de instalación 3 Installation version 3 Installazione versione 3 MIN 820 / MAX 975 X-190 O 70 R 10...
  • Page 20 Installation Version 4 Installatie versie 4 Installation version 4 Versión de instalación 4 Installation version 4 Installazione versione 4...
  • Page 21 Installation Version 4 Installatie versie 4 Installation version 4 Versión de instalación 4 Installation version 4 Installazione versione 4 MIN 820 / MAX 975 X-190 R 10...
  • Page 22 Von hier ab gelten die Montageanleitungen für alle 4 Installationswei- sen; achten Sie auf die Ausrichtung des Motors und des Anschlusses beim ausgewählten Installationstyp. From this point on, the assembly instructions apply to each of the four setup modes; be careful to the position of the motor and the fitting, specific to the type of installation chosen.
  • Page 23 AFV0010...
  • Page 24 X>140mm...
  • Page 25 X<140mm...
  • Page 27 pay attention! place exactly at 255mm...
  • Page 29 AFV0002 AFV0002...
  • Page 30 AFV0002...
  • Page 31 AFV0005...
  • Page 34 pay attention! place exactly at 258mm...
  • Page 37 exhaustion mode...
  • Page 38 exhaustion mode...
  • Page 39 recirculation mode A k t i v k o h l e f i l t e r Charcoal Filter Filtre à charbon Koolstoffilter Filtro al carbòn Filtro al carbone...
  • Page 40 recirculation mode...

  • Page 42: Electrical Connection Diagram

    Electrical connection diagram 220-240V 220-240V 220-240V The induction hob is composed of 2 modules, each one can absorb 3.7kW max. The total rated power of the product is 8,8kW (1,4kW+3kW+3kW+1,4kW)

  • Page 43: Pot Detection

    FUNZIONAMENTO OPERATION Switching on the cooktop Aspira is equipped with touch sensitive electronic sensor keys. Switch on the cooktop firstly, and then the desired cooking zone. Activating the desired cooking zones Press the power button for at least 2 seconds. All of the displays will light up.
  • Page 44 FUNZIONAMENTO OPERATION If a cooking zone remains lit for too long at the same power level, the appliance will automatically switch it off, and the residual heat indicator H will appear. Switch it back on to reset the cooking zone’s operation. The table below lists the maximum uninterrupted operating time for each power level: Powen Operating limit in minutes...
  • Page 45 FUNZIONAMENTO OPERATION Lock function: touch the power button, then simultaneously press the button that indicates the cooking zone at the lower right, followed by the – key; press the button that indicates the cooking zone at the lower right once again.Once the Child Lock function has been enabled, the symbol L will appear on the display.To disable the Child Lock function: touch the power button, then simultaneously press the button that indicates the cooking zone at the lower right, followed by the –...
  • Page 46 FUNZIONAMENTO OPERATION centrale b2 Display This device allows you to choose the operating mode (suction or filtration), depending on the installation. Upon first start-up, the display shows which operating mode is enabled. Filtration: the display shows the letters C and the filter reset button flashes quickly.
  • Page 47 FUNZIONAMENTO OPERATION F:Filter reset key: Active only in filtration mode: After 120 hours of operation of the hood, the symbol F, alternating with the symbol C, will flash indicating the need to clean/replace the activated carbon filters; the carbon filters can be washed in the dishwasher once, and then they must be replaced.
  • Page 48 CLEANING AND MAINTENANCE FUNZIONAMENTO Cooking top The cooking top must be cleaned after each use. Allow the appliance to cool before cleaning it. Prior to cleaning the ceramic glass cooking hob, it is advisable to activate the Child Lock function, so that the cooking top is not switched on accidentally (see Child Lock function).
  • Page 49 CLEANING AND MAINTENANCE FUNZIONAMENTO OPERATION TABLE OF COOKING TOP ERRORS These errors appear on the cooking top display. Error code Description Possible causes Solution If the display in one of the cooking zones shows C, E, C flashing, E flashing one of these symbols, an Problems or changes Contact the authorised...
  • Page 50 CLEANING AND MAINTENANCE FUNZIONAMENTO Continuous activation of Dry and clean the glass or one of the control keys; Liquid or pot on the remove the pot from the Er 03 or the control switches off control zone control zone. after 10 seconds. Contact the authorised The power returns to Fault detected on a...
  • Page 51 NOTES ....................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
