AIRFORCE Aspira ob 60 Instruction On Mounting And Use Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
D
GB
F
PRESCRIPTIONS DE MONTAGE ET MODE D'EMPLOI
NL
MONTAGEVOORSCHRIFTEN EN GEBRUIKSAANWIIZING
ES
S
I
aspira induction
Model : Aspira ob 60
MONTAGE- UND GEBRAUCHSANWEISUNG
INSTRUCTIONS ON MOUNTING AND USE
MONTAJE Y MODO DE EMPLEO
MONTERINGS- OCH BRUKSANVISNINGAR
ISTRUZIONI DI MONTAGGIO E D'USO

Advertisement

loading
Need help?

Need help?

Do you have a question about the Aspira ob 60 and is the answer not in the manual?

Questions and answers

Related Manuals for AIRFORCE Aspira ob 60

Summary of Contents for AIRFORCE Aspira ob 60

  • Page 1 Model : Aspira ob 60 MONTAGE- UND GEBRAUCHSANWEISUNG INSTRUCTIONS ON MOUNTING AND USE PRESCRIPTIONS DE MONTAGE ET MODE D’EMPLOI MONTAGEVOORSCHRIFTEN EN GEBRUIKSAANWIIZING MONTAJE Y MODO DE EMPLEO MONTERINGS- OCH BRUKSANVISNINGAR ISTRUZIONI DI MONTAGGIO E D’USO...
  • Page 3 Per tutte le operazioni di installazione e manutenzione utilizzare guanti da lavoro Always wear work gloves for all installation and maintenance operations Bei allen Installations- und Instandhaltungsarbeiten immer Schutzhandschuhe tragen. Draag bij alle installatie- en onderhoudswerkzaamheden werkhandschoenen. Todas las operaciones de instalación y mantenimiento se deben realizar utilizando guantes de trabajo. Para todas as operações de instalação e manutenção, utilize luvas adequadas para este tipo de atividade Πάντοτε...
  • Page 4 Min. 0 110mm Min. 0 120mm Min. 0 110mm Min. 0 120mm...
  • Page 5 Zone 3 Zone 1 2,1 kW 1,4 kW 3 kw Booster 2 kw Booster Zone 2 Zone 4 1,4 kW 1,85 kW...
  • Page 8 Flächenbündige Kochfelder Hinweise zum Einbau Ein flächenbündiges Kochfeld ist nur für den Einbau in Naturstein (Granit, Marmor), Massivholz und geflieste Arbeitsplatten geeignet. Bei Arbeitsplatten aus anderen Materialien erfragen Sie bit- te beim jeweiligen Hersteller, ob sie für den Einbau eines flächenbündigen Kochfeldes geeignet ist. Flush Cooktop Notes about Installation A flush cooktop is only appropriate for installation in counters made of natural stone (granite or...
  • Page 11 Torx t10...
  • Page 12 > Torx t10 KTFOBH10...
  • Page 13 > KTFOBH10 Installation A Installation B > > >...
  • Page 14 Installation B Installation A Min.130 Max.140 Max.140...
  • Page 15 Installation B Installation A silicone X (Min.130) X-55 Torx t10 X-55...
  • Page 16 Installation A Installation B silicone...
  • Page 17 Installation A Installation B Torx t10...
  • Page 18 Installation A Installation B Y= H-415 > H-415...
  • Page 20 Plus...
  • Page 21 accessories at page 37 > accessories at page 37...
  • Page 22 Option 1...
  • Page 23 AFFCARFPH6 KTFOBH6...
  • Page 24 Installation C Installation D >...
  • Page 25 Installation C Installation D Min.130 Max.140 Max.140...
  • Page 26 Installation C Installation D silicone X (Min.130) X-55 Torx t10 X-55...
  • Page 27 Installation C Installation D silicone...
  • Page 28 Installation C Installation D Torx t10...
  • Page 29 Installation C Installation D > H-395...

  • Page 34: Electrical Connection Diagram

    Electrical connection diagram 220-240V 220-240V 220-240V The induction hob is composed of 2 modules, each one can absorb 3.7kW max. Scheme 1: for 1 phase (220-240V~ 1N), total power absorbed 7,4kW (7,4kW for phase) Scheme 2: for 2 phase (380-415V~ 2N), total power absorbed 7,4kW (3,7kW for phase) The total rated power of the product is 8,8kW (1,4kW+3kW+3kW+1,4kW)
  • Page 35 ANWEISUNGEN WARNINGS Caution ASPIRA his instruction handbook is conserved together with the for future consultation. If the equipment is sold or transferred to another person, make certain the instruction handbook is supplied together with it, so that the new user can become aware of the operation of the cooker hood and related warnings.
  • Page 36 ANWEISUNGEN WARNINGS leaning and maintenance must not be carried out by children without proper supervision. f the power cord is damaged, it must be replaced by a qualified service centre or technician only. he electrical installation must have a breaker upstream from the appliance which ensures that all poles are disconnected with a contact gap of at least 3mm.

  • Page 37: Fire Hazard

    ANWEISUNGEN WARNINGS he induction hob should not be used as a work surface. The rough underside of food containers can scratch the surface of the cooktop. lways keep the cooking areas and underside of food containers perfectly dry. Fire hazard il and grease that are too hot will catch fire quickly.

  • Page 38: Burn Hazard

    ANWEISUNGEN WARNINGS Burn hazard AUTION: This appliance and its accessible parts become very hot during use. ay attention to avoid touching the heating elements. eep children under 8 years of age away from the appliance, unless they are continually monitored. o not place objects such as knives, forks, spoons or lids on the induction top, as they may overheat.
  • Page 39 ANWEISUNGEN WARNINGS Non-suitable food containers ever use recipients made of: normal finegrained steel, glass, pottery, copper and aluminium. Do not place empty containers on the cooking zone, as they may cause damage. o not place hot recipients on the control panel, in the area of the pilot lights or on the edge of the cooking top, as they may cause damage.
  • Page 40 ANWEISUNGEN WARNINGS ny interventions or repairs on the unit during the warranty period must be carried out solely by the manufacturer’s authorised service centre; conversely, the warranty will be is invalidated and terminated immediately. The manufacturer will not recognise any warranties under any circumstances for any problems subsequently encountered.

  • Page 41: Noise Emissions

    ANWEISUNGEN WARNINGS Noise emissions nduction can generate slight noise emissions, which can vary depending on the material, type of pot and power setting selected. When the cooktop is used frequently, the cooling fan turns itself on to protect the electronics, generating a buzzing sound: this is perfectly normal.
  • Page 42 FUNZIONAMENTO OPERATION Display This device allows you to choose the operating mode (suction or filtration), depending on the installation. Upon first start-up, the display shows which operating mode is enabled. Filtration: the display shows the letters C and the filter reset button flashes quickly. Suction: the display indicates the letter C and the filter reset button is off.
  • Page 43 FUNZIONAMENTO OPERATION A:Timer key: when touching the key, the timer will be enabled, regardless of the selected suction speed. Upon first touch, the time will be 5 minutes (shown by a flashing button on the key), the second touch corresponds to 10 minutes (double flashing time) and the third touch to 20 minutes (triple flashing time) The timer key will flash throughout the entire operation.

  • Page 44: Switching On The Cooktop

    FUNZIONAMENTO OPERATION Switching on the cooktop ASPIRA is equipped with touch sensitive electronic sensor keys. Switch on the cooktop firstly, and then the desired cooking zone. Activating the desired cooking zones Press the power button for at least 2 seconds. All of the displays will light up.
  • Page 45 FUNZIONAMENTO OPERATION If a cooking zone remains lit for too long at the same power level, the appliance will automatically switch it off, and the residual heat indicator H will appear. Switch it back on to reset the cooking zone’s operation. The table below lists the maximum uninterrupted operating time for each power level: Powen Operating limit in minutes...
  • Page 46 FUNZIONAMENTO OPERATION Lock function: touch the power button, then simultaneously press the button that indicates the cooking zone at the lower right, followed by the – key; press the button that indicates the cooking zone at the lower right once again.Once the Child Lock function has been enabled, the symbol L will appear on the display.To disable the Child Lock function: touch the power button, then simultaneously press the button that indicates the cooking zone at the lower right, followed by the –...
  • Page 47 CLEANING AND MAINTENANCE FUNZIONAMENTO Cooking top The cooking top must be cleaned after each use. Allow the appliance to cool before cleaning it. Prior to cleaning the ceramic glass cooking hob, it is advisable to activate the Child Lock function, so that the cooking top is not switched on accidentally (see Child Lock function).
  • Page 48 CLEANING AND MAINTENANCE FUNZIONAMENTO OPERATION TABLE OF COOKING TOP ERRORS These errors appear on the cooking top display. Error code Description Possible causes Solution If the display in one of the cooking zones shows C, E, C flashing, E flashing one of these symbols, an Problems or changes Contact the authorised...
  • Page 49 CLEANING AND MAINTENANCE FUNZIONAMENTO Continuous activation of Dry and clean the glass or one of the control keys; Liquid or pot on the remove the pot from the Er 03 or the control switches off control zone control zone. after 10 seconds. Contact the authorised The power returns to Fault detected on a...
  • Page 52 AFLIASP60OBN Ed.04-08-21...
