- Page 1 HAVEN 2000 HV2000E | HV2000R...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Important Safeguards . . . . . . . . . . . . . . . . 3 - 4 Product Diagram . -
Page 3: Important Safeguards
IMPORTANT SAFEGUARDS PLEASE OBSERVE THE FOLLOWING PRECAUTIONS AND INSTRUCTIONS BEFORE INSTALLATION AND USE. DANGER - To reduce the risk of electrocution: Do not place or store product where it can fall or be pulled into a tub or sink . Do not place in or drop into water or other liquid . - Page 4 IMPORTANT SAFEGUARDS (cont .) • Do not plug in the power cord before connecting the water supply hose . • Install in an area with adequate ventilation to avoid high levels of humidity which can damage the electronic components . •...
-
Page 5: Product Diagram
PRODUCT DIAGRAM Warm Air Dryer Dual Nozzles Heated Seat Control Knob Water Inlet 3 .5 Ft Power Cord Reset Button/ Quick Release Adjustable Temps Control Knob Dual Nozzles Rear Wash Stop Front Wash Front Wash Rear Wash... -
Page 6: Parts & Hardware
PARTS & HARDWARE 7/8" 1/2" 7/8" T-Valve Stay·Tite Bolts (2) Stay·Tite Nuts (2) ® ® *Cone washer inside Mounting Brackets Mounting Plate Bidet Hose RECOMMENDED INSTALLATION TOOL 5/8" Wrench... -
Page 7: Before Installation
BEFORE INSTALLATION Be sure that all parts are on hand before proceeding with the installation. Residual moisture in the bidet at purchase ensures that your product was tested at the factory with pure water to meet the highest quality standards and performance. Check the line that connects the toilet tank to the water shut off valve. -
Page 8: Installation
INSTALLATION INSTALLATION Insert bolts into metal mounting brackets, aligning the teeth on the bolt with the slots in the mounting bracket. Insert bolt with brackets into mounting plate. - Page 9 INSTALLATION (cont .) Slide mounting plate with bolts into seat until it clicks. Place bidet seat on bowl, adjusting seat front-to-back and side-to-side for proper fit.
- Page 10 Slide (AC) into hinges. Close hinge caps. Deslice (AC) en las bisagras. Cierre la tapa de las bisagras. INSTALLATION Glisser (AC) dan les charnières. Fermer les couvercles de charnières. (cont .) cludes n incluye el inclut Lightly finger tighten Stay·Tite ®...
-
Page 11: Water Connection
WATER CONNECTION Toilet Tank Cone Washer *Inside T-valve T-Valve Water Supply Line Bidet Hose Water Supply Shut-Off Valve... - Page 12 WATER CONNECTION (cont .) Close water supply valve. Flush toilet until toilet tank is empty. Place towel below tank to catch dripping water. Disconnect existing water supply line from toilet tank.
- Page 13 WATER CONNECTION (cont .) Ensuring rubber gasket is properly seated on top of T-valve. Attach T-valve to toilet TANK water supply fitting. Do not hold fill valve inside tank. IMPORTANT: T-VALVE INSTALLS AT THE BOTTOM OF TOILET TANK, NOT AT THE WALL.
- Page 14 WATER CONNECTION (cont .) Connect bidet hose directly to T-valve. Connect other end of bidet hose to seat's metal inlet, making sure it’s firmly connected. Do not sharply bend or twist hose. Slowly turn on water supply. Wipe hoses and connectors thoroughly with a towel and carefully observe for any leaks on all connections for at least 10 minutes.
-
Page 15: Operation
OPERATION This product includes a built-in seat sensor to avoid any accidental sprays while powered . Skin contact is required to activate any wash functions while powered . Adjust water pressure FRONT WASH by rotating the control knob forward Adjust water pressure REAR WASH by rotating the control knob backward... - Page 16 OPERATION (cont .) While not seated, long press control knob button NIGHT LIGHT to switch between night light settings . • Mode 1 - Knob light on, bowl light off • Mode 2 - Knob light off, bowl light on •...
-
Page 17: Cleaning & Maintenance
CLEANING & MAINTENANCE EASY·CLEAN REMOVAL & CLEANING ® Close cover . Push and hold seat release button, pulling seat forward to remove . Clean only with mild cleaners using a soft, damp cloth, & towel dry . NO HARSH CHEMICALS TOILET BLEACH CLEANER... - Page 18 CLEANING & MAINTENANCE (cont .) CLEAN SPRAY NOZZLES Pull out nozzle softly and use a smooth cloth, sponge or soft toothbrush to clean nozzle . USE DURING POWER FAILURE During a power outage, it is not possible to adjust the water and seat temperature .
- Page 19 CLEANING & MAINTENANCE (cont .) FILTER CLEANING Bidet Hose Filter Screen This product will not operate properly if the filter screen is clogged . Please clean the screen regularly . Unplug power cord . Close water shut-off valve . Unscrew bidet hose from bidet seat . Clean filter screen with a small brush .
- Page 20 CLEANING & MAINTENANCE (cont .) PERIODS OF NON-USE If you do not intend to use this product for an extended period of time, drain the water from the bidet seat Before draining, unplug the power cord and wait 30 minutes until the unit has cooled down .
-
Page 21: Troubleshooting
TROUBLESHOOTING Problem Cause Solution Inspect and Bidet hose has blockage reattach bidet hose Water does not spray Shut-off valve is closed Open the shut-off valve Water is leaking Knob is not completely Turn the control (while not occupied) turned to “Stop” knob to "stop"... -
Page 22: Specifications
SPECIFICATIONS Specifications HAVEN 2000 Power Rating 120Vac, 60Hz, 1050W Water Inlet Pressure 0 .1~ 0 .74MPa (0 .4 ~ 7 .5 kgf/cm) Power Cord 3 .5 feet Water Amount Regulation Stepless regulation Water Temperature Regulation ~95/100°F /OFF Wash Heating Method... -
Page 23: Warranty
Product’s purchase price (less shipping, if applicable), at Bemis’s option . Bemis may, at its option, require the return of any Product for inspection and testing before honoring any defect claim . This Limited Warranty excludes component parts... - Page 24 Thank you for your Bemis bidet ® seat purchase! Bemis Manufacturing Co . Sheboygan Falls, Wisconsin U .S .A . 888 .722 .6488 | Corp@BemisMfg .com ToiletSeats .com 012624...
