- Page 1 Personal Wash Bidet Installation and User’s Manual...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Parts...................3 Pre-Installation..............4 Installation ................5 Adjusting the Comfort Stream ........10 ™ How to Use Your Bidet............12 Cleaning.................13 Warranty.................14... -
Page 3: Parts
PARTS Bidet attachment 2 Adjustable mounting disks T-Valve connector with rubber washer (7/8” x 7/8” x 3/4”) 27.5” Braided Metal Hose for T-Valve / Bidet connection Teflon tape... -
Page 4: Pre-Installation
PRE-INSTALLATION Please review prior to starting the installation Water Supply Line • Confirm that your current water supply line to the toilet is a flexible water supply hose • If it is a rigid pipe, you will need to replace this with a flexible water supply hose •... -
Page 5: Installation
INSTALLATION Close the water supply valve 2. Disconnect the water hose from to the toilet. Flush the toilet to the fill valve connection under the minimize the water in the tank. tank of the toilet Place a towel on the floor to absorb any water. - Page 6 INSTALLATION (cont.) supplied 6. Straighten the hinges on your 5. Connect the metal hose Clean Shield seat as shown in the with the Bidet to the open side of diagram. the T-Valve. 7. Place the bidet on the 8. Holding the attachment as far toilet.
- Page 7 9. While holding down the bidet attachment with one hand, pick up the Clean Shield seat, align the bolts to the mounting holes and push the seat downward through the slots in the circular mounting disks so the bolts enter the seat mounting holes on the toilet.
- Page 8 INSTALLATION (cont.) 11. Holding the bidet attachment in 12. Connect the hose from place, tighten the Snap 2 Secure the T-Valve to the Bidet nuts until the installation head Attachment and tighten. snaps off. 13. Confirm that the handle 14. Slowly turn the water on the bidet is turned to the off supply valve open.
- Page 9 Notes...
-
Page 10: Adjusting The Comfort Stream
ADJUSTING the COMFORT STREAM ™ Start with the T-Valve knob in the off position… pointing straight down (see photo) 2. Turn the knob a small amount to open the valve (see photo) Turning the knob small amounts will help you find your preferred stream strength more quickly... - Page 11 Bidet Nozzle Self Clean 3. Seated and prepared to be washed, slowly turn the bidet handle towards you (to the left), stopping on the first click. (Turning the Bidet Handle away from you, to the right, will self-clean the Nozzle) Too Strong or Uncomfortable: Turn the T-Valve Knob closer to the “Closed”...
-
Page 12: How To Use Your Bidet
HOW TO USE YOUR BIDET For personal wash, turn the Handle to the left towards the “ ” position. To Clean the Nozzle, turn the Handle to the right towards the “ ” position. The further the Handle is turned, the stronger the water stream. -
Page 13: Cleaning
CLEANING Your Personal Wash Bidet is made with a high grade fire-retardant ABS resin. Using cleaning chemicals can damage the bidet material. 1. Clean the Personal Wash Bidet by wiping the surface area with a damp cloth regularly. 2. Do not use harsh detergents, cleaning chemicals or any cleaning tools with bristles on your bidet. -
Page 14: Warranty
Bemis may, at its option, require the return of the Product for inspection and testing before honoring any warranty claim. This Limited Warranty... - Page 15 PARTICULAR PURPOSE. BEMIS EXPRESSLY DISCLAIMS LIABILITY FOR SPECIAL, PUNITIVE, EXEMPLARY, CONSEQUENTIAL OR INCIDENTAL DAMAGES ASSOCIATED WITH THE PRODUCT, INCLUDING LOST PROFITS OR BUSINESS INTERRUPTIONS. BEMIS’S LIABILTY UNDER THESE TERMS AND CONDITIONS SHALL NOT EXCEED THE PURCHASE PRICE OF THE PRODUCTS.
- Page 16 Thank You Customer Service: 833-431-1703 Bemis Independence 300 Mill Street Sheboygan Falls, WI 53085 BemisIndependence.com...
