- Page 1 ASSURANCE ™ Bidet Attachment Installation and User Manual...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Parts...................3 Pre-Installation..............4 Installation ................5 Wash Controls..............10 How to Use Your Bidet............12 Cleaning.................13 Warranty.................14... -
Page 3: Parts
PARTS Bidet Attachment 2 Adjustable Mounting Disks T-valve Connector with Rubber Washer (7/8" x 7/8" x 3/4") 27.5" Braided Metal Water Supply Line for T-valve Bidet Connection Plumbers Tape... -
Page 4: Pre-Installation
PRE-INSTALLATION Please review prior to starting the installation Water Supply Line • Confirm that your current water supply line to the toilet is a flexible water supply hose. • If it is a rigid pipe, you will need to replace this with a flexible water supply hose. -
Page 5: Installation
INSTALLATION Close the water supply valve 2. Disconnect the water hose from to the toilet. Flush the toilet to the fill valve connection under the minimize the water in the tank. tank of the toilet. Place a towel on the floor to absorb any water. - Page 6 INSTALLATION (cont.) supplied 6. Straighten the hinges on your seat 5. Connect the metal hose as shown in the diagram. with the bidet to the open side of the t-valve. 7. Place the bidet on the 8. Holding the attachment as far toilet.
- Page 7 9. While holding down the bidet attachment with one hand, pick up the seat, align the bolts to the mounting holes and push the seat downward through the slots in the circular mounting disks so the bolts enter the seat mounting holes on the toilet.
- Page 8 INSTALLATION (cont.) 10. Holding the bidet attachment in 11. Connect the hose from place, tighten the Stay•Tite nuts the t-valve to the bidet attachment until the installation head snaps and tighten. off. 12. Confirm that the handle 13. Slowly turn the water on the bidet is turned to the off supply valve open.
- Page 9 Notes...
-
Page 10: Wash Controls
ADJUSTABLE WASH FUNCTIONS Start with the t-valve knob in the off position… pointing straight down (see photo). 2. Turn the knob a small amount to open the valve (see photo). Turning the knob small amounts will help you find your preferred stream strength more quickly. - Page 11 Bidet Nozzle Self-Clean 3. Seated and prepared to be washed, slowly turn the bidet handle towards you (to the left), stopping on the first click. (Turning the bidet handle away from you, to the right, will self-clean the nozzle) Too Strong or Uncomfortable: Turn the t-valve knob closer to the “closed”...
-
Page 12: How To Use Your Bidet
HOW TO USE YOUR BIDET For personal wash, turn the handle to the left towards the " " position. To clean the nozzle, turn the handle to the right towards the " " position. The further the handle is turned, the stronger the water stream. -
Page 13: Cleaning
CLEANING Your Assurance Bidet Attachmentis made with a ™ high grade fire-retardant ABS resin. Using cleaning chemicals can damage the bidet material. 1. Clean the bidet attachment by wiping the surface area with a damp cloth regularly. 2. Do not use harsh detergents, cleaning chemicals or any cleaning tools with bristles on your bidet. -
Page 14: Warranty
Bemis may, at its option, require the return of the product for inspection and testing before honoring any warranty claim. This Limited Warranty... - Page 15 PARTICULAR PURPOSE. BEMIS EXPRESSLY DISCLAIMS LIABILITY FOR SPECIAL, PUNITIVE, EXEMPLARY, CONSEQUENTIAL OR INCIDENTAL DAMAGES ASSOCIATED WITH THE PRODUCT, INCLUDING LOST PROFITS OR BUSINESS INTERRUPTIONS. BEMIS’S LIABILTY UNDER THESE TERMS AND CONDITIONS SHALL NOT EXCEED THE PURCHASE PRICE OF THE PRODUCTS.
- Page 16 Thank You Customer Service: 888-722-6488 Bemis Manufacturing Co. 300 Mill Street Sheboygan Falls, WI 53085 ToiletSeats.com 0B7042003...
