Summary of Contents for Neve 1073SPX-D
- Page 1 1073SPX-D 1073 Channel Strip and USB/ADAT Audio Interface User Manual Issue 1...
-
Page 2: Health & Safety Notice (English)
Health & Safety Notice FOR YOUR OWN SAFETY AND FOR THE PROTECTION OF OTHERS PLEASE OBSERVE THE FOLLOWING HEALTH AND SAFETY INSTRUCTIONS READ THESE INSTRUCTIONS AND KEEP THEM HANDY • HEED ALL SAFETY WARNINGS • DO NOT USE NEAR WATER •... -
Page 3: Health & Safety Notice (French)
Avertissements de Santé & Sécurité POUR VOTRE SECURITE ET CELLE DES AUTRES MERCI DE RESPECTER LES INSTRUCTIONS DE SANTE ET SECURITE SUIVANTES LISEZ CES INSTRUCTIONS ET GARDEZ-LES À PORTÉE DE MAIN • TENEZ COMPTE DE TOUS LES AVERTISSEMENTS DE SÉCURITÉ •... -
Page 4: Important Safety Instructions (English)
© ® 2005 - 2024 AMS Neve Ltd own the copyright of all information and figures contained in this manual which are not to be copied or reproduced by any means or disclosed in part or whole to any third party without written permission. As part of our policy of continual product improvement, we reserve the right to alter specifications without notice but with due regard to all current legislation. -
Page 5: Important Safety Instructions (French)
Instructions Importantes sur la Sécurité: Pour votre sécurite et celle des autres merci de respecter les instructions de santé et sécurité suivantes : 1) Lisez ces instructions. 2) Gardez ces instructions. 3) Tenez compte de tous les avertissements. 4) Suivez toutes les instructions. 5) ATTENTION: afin de réduire les risques d'incendie ou de choc électrique, n'exposez pas cet appareil à... -
Page 6: Table Of Contents
Health & Safety notice (English) ............................2 Health & Safety notice (French) ............................3 Important Safety Instructions (English) ........................... 4 Important Safety Instructions (French) ..........................5 1073SPX-D Introduction ..............................7 Rack Mount Instructions (English) ............................ 8 Rack Mount Instructions (French)............................. 8 Quick Start Guide ................................9 Input Connections ................................ -
Page 7: 1073Spx-D Introduction
Digital Innovation The 1073SPX-D is the latest innovation in the Neve 1073 line, combining a complete 1073 channel strip with a powerful digital audio interface. Featuring USB and ADAT connectivity, the 1073SPX-D becomes a one-stop- shop for recording, mixing &... -
Page 8: Rack Mount Instructions (English)
Rack Mount Instructions Elevated Operating Ambient- If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient. Therefore, consideration should be given to installing the equipment in an environment compatible with the maximum ambient temperature (30°C) specified by the manufacturer. -
Page 9: Quick Start Guide
The 1073SPX-D is USB 2.0 compliant; USB 2 and USB 3 ports can be used for digital audio transfer. Once a Stable connection is made, (and the AMS Neve Audio Driver is installed for PC users) the USB LED will illuminate Blue. - Page 10 Windows To operate on a Windows 10 PC, download and install the 1073SPX-D Driver from - https://www.ams-neve.com/1073SPX-D/#MoreInfo > Downloads Follow the setup wizard instructions to install the driver. To select the 1073SPX-D as your PC Audio Interface, navigate to –...
-
Page 11: Input Connections
The DIGI switch activates the digital line input, fed from DAW output 3 named Neve Out 3 (Digi/Mon 3). This input is designed so that the 1073SPX-D can act as a USB or ADAT hardware insert by sending DAW signals directly into the SPX-D line preamp. -
Page 12: Preamp Controls
Gain Switch The 1073SPX-D gain switch is used to select the input type (Mic or Line) and set the preamp gain level for the selected input. Preamp gain is incremented in 5dB steps, ranging from -20 to +10 of line level, and -20 to -80dB of microphone level. - Page 13 The DI input has a high impedance of 2MΩ. DI signals pass through the microphone transformer and mic preamp stage of the 1073SPX-D. To apply gain to an instrument DI, set the 1073SPX-D gain switch to the microphone input side of the switch, and adjust gain accordingly.
-
Page 14: Eq Section
EQ Section The 1073SPX-D uses a three-band inductor-based EQ circuit, identical to the classic 1073 80-series modules. The EQ circuit also includes a choke-based high pass filter. EQ Switch The three-band EQ and HPF are activated via the EQ switch. Unless EQ is switched, the EQ and HPF are completely bypassed. -
Page 15: Output Connections & Controls
Output Connections & Controls Phase The Phase switch reverses the phase of the 1073SPX-D output signal. In the default position, absolute phase is preserved through the unit. When Phase is depressed, the output signal of the unit is inverted by 180 degrees. -
Page 16: Monitor Connections & Controls
Monitor Input The two monitor in L and monitor in R connections are used to input a stereo monitor source into the 1073SPX-D analogue monitor path. These connections are ideally used as monitor connections from an external audio interface, providing an additional monitor attenuator control via the HP/LS level pot. - Page 17 Blend The blend control is used to crossfade stereo DAW and mono SPX signals into the 1073SPX-D stereo monitor path. This pot is designed to allow for latency-free monitoring when tracking through the 1073SPX-D. • At the centre position, DAW and SPX signals are each attenuated by 6dB.
-
Page 18: Digital Connections & Controls
The USB 2.0 B-type port is used along with the cable(s) provided to connect the SPX-D to your computer as an audio interface. When connected, the 1073SPX-D can be used as both a playback and recording device for the connected computer and DAW software applications. -
Page 19: Usb/Adat Hub Mode
USB/ADAT Hub Mode The 1073SPX-D has two possible modes of digital operation. USB/ADAT Hub mode enables the 1073SPX-D to function as a 9x12 I/O USB audio interface for your Mac or PC, expandible via ADAT in and out connections. Connect the 1073SPX-D to your computer via USB. The USB LED will illuminate once the computer selects the SPX-D as its audio device. - Page 20 Internal/ADAT clock source selection In USB Hub mode, the 1073SPX-D can either clock to its internal clock source or can clock to an external source via the ADAT input. Note: sample rates must be matched on both devices when using ADAT clock mode.
- Page 21 Sample Rate/ ADAT Channel Count Configuration When using the 1073SPX-D in USB/ADAT Hub mode, adjustments must be made from within the audio driver in order to correctly map the unit’s digital ADAT I/O to the available channel count at the requested sample rate.
- Page 22 To configure for 88.2 or 96kHz sample rates, select – Input – 6 channel(s) Output – 8 channel(s) To configure for 176.4 or 192kHz sample rates, select – Input – 4 channel(s) Output – 6 channel(s)
- Page 23 To configure the ADAT channel count for your selected sample rate - Navigate to the Applications>Utilities>Audio MIDI Setup Select Neve SPX/DPX Mic Preamp from the Audio Devices Window Select Input & Output tabs to configure the ADAT I/O channel count To configure for 44.1 or 48 kHz sample rates, select –...
- Page 24 To configure for 176.4 or 192 kHz sample rate, select – Input – 4 ch 24-bit Integer 176.4 kHz/4 ch 24-bit Integer 192 kHz Output – 6 ch 24-bit Integer 176.4 kHz/6 ch 24-bit Integer 192 kHz...
-
Page 25: Adat Audio Expander Mode
96kHz. Sample Rate Selection To select the 1073SPX-D sample rate, press the SR button located to the left of the sample rate LEDs. The sample rate will toggle through 44, 48, 88, and The sample rate set on the 1073SPX-D must match the sample rate set on your audio interface. -
Page 26: Dimensions & Power Requirements
Dimensions & Power Requirements Height 44mm/1.75 inches Width 480mm/19 inches Depth 360mm/14.17 inches Weight 5.475Kg/12.07Lbs Voltage 100 – 240Vac Current 0.2A @ 240Vac Neve PS12221 T2A 230V 20mm +16V internal fuse -16V internal fuse T2A 230V 20mm 48V internal fuse T250mA 230V 20mm... -
Page 27: Audio Specification
Audio Specification Microphone Inputs Frequency Response +/- 0.25dB 20Hz to 20kHz Frequency Response +/-0.5dB 10Hz to 35kHz <0.2% 20-20kHz, <0.02% 1kHz Distortion (THD) <-124.5dBu 20-20kHz unweighted, gain @ 60dB Noise EIN Gain Range 20 to 80dB -56dBu Maximum Input Level (Max Gain @ 80dB) +6dBu Maximum Input Level... - Page 28 Headphone output (600Ω load) Maximum Output Level +20dBu Frequency Response 10 - 30kHz +/-0.1dB Distortion (THD) 0.005% Noise floor -90dBu Metering Signal ~-30dBu Clip +23dBu...
-
Page 29: Ad/Da Specification
Distortion, with a +26dBu input signal, minimum gain Round Trip Latency (RTL) Type Device S.R. Bits Buffer Measured RTL (ms) Noise Floor ASIO AMS Neve USB Audio Device 44100 8.707 -110.7 ASIO AMS Neve USB Audio Device 44100 10.454 -110.4... -
Page 30: Unit Connection Tables
Unit Connection Tables Power and Comms USB2 Type-B Preamplifier Microphone Inputs XLR 3-pin plug female Preamplifier Line Inputs XLR 3-pin plug female & ¼" TRS Jack socket Preamplifier DI inputs ¼" TRS Jack sockets Headphone Output ¼" TRS Jack socket Insert Sends ¼"... -
Page 31: Dimensions & Power Requirements (French)
Dimensions & Exigences Alimentation Hauteur 44mm/1.75” Largeur 480mm/19” Profondeur 360mm/14.17” Poids 5.475Kg/12.07Lbs Voltage 100 – 240Vac Courant 0.2A @ 240Vac Neve PS12221 T2A 230V 20mm +16V fusible interne -16V fusible interne T2A 230V 20mm 48V fusible interne T250mA 230V 20mm... -
Page 32: Audio Specification (French)
Spécifications Audio Entrées Microphone Réponse de fréquence +/- 0.25dB 20Hz à 20kHz Réponse de fréquence +/-0.5dB 10Hz à 35kHz <0.2% 20-20kHz, <0.02% 1kHz Distortion (THD+N) <-124.5dBu 20-20kHz unweighted, gain @ 60dB Bruit EIN Plage de Gain 20 – 80dB -56dBu Niveau Maximum Entrée (Gain Max @ 80dB) +6dBu... - Page 33 Sortie Casque (charge 600 Ohm) Niveau Maximum Sortie +20dBu Réponse de fréquence 10 - 30kHz +/-0.1dB Distortion (THD +N) 0.005% Bruit de fond -90dBu Mesure Signal -30dBu Clip +23dBu...
-
Page 34: Ad/Da Specification (French)
Distortion, avec un signal d’entrée de 26dBu, gain minimum Latence aller-retour Type Dispositif S.R. Bits Tampon RTL mesuré (ms) Bruit de Fond ASIO AMS Neve Dispositif USB Audio 44100 8.707 -110.7 ASIO AMS Neve Dispositif USB Audio 44100 10.454 -110.4... -
Page 35: Unit Connection Tables (French)
Table de connexion de l’unité Alimentation et Communications USB2 Type-B Préamplificateur (Sorties Microphone) XLR 3-broches F Préamplificateur (Entrées Ligne) XLR 3-broches F & ¼" (6.35mm) TRS Jack Préamplificateur (Entrées Directes DI) ¼" (6.35mm) TRS Jack Sortie Casque ¼" (6.35mm) TRS Jack Départs Insert ¼"...
