TOOLS REQUIRED
• Cordless Drill
COMPONENTS
Wafer-Head
Sheetmetal
Self-Drilling
Screw
Screw
x10
x2
INSTALLATION
Handi-Pod
Garden Shed Shelf Kits are available in two sizes.
®
1270mm Shelf Kits can be installed to the short walls of the
1270mm
Handi-Pod
Garden Shed HP1. 2140mm Shelf kits can be
®
installed to the long walls of the Handi-Pod
HP1 or HP2.
Shelves can be installed at any Panel Lap. Determine the wall
location and height to install the Shelf.
FIGURE 1.0
HANDI-POD
HANDI-POD
• 5/16 Hex-head Bit
• PH2 Phillips-head Bit
Hex-Head Self-
Drilling Screw
x2
Garden Shed
®
Note: shed is shown in partially
assembled state for illustrative
purposes only. Fully assemble
Shed before installing.
SHELF KIT
GARDEN SHED SHELF KIT INSTALLATION GUIDE
®
Shelf Bracket
Shelf
x2
x1
Remove existing Sheetmetal Screws from corners and along
the Panel lap.
OR
Sheetmetal Screw
2140mm
FIGURE 1.1
GARDEN SHED
®
OR
1270mm
2140mm
Do not remove
