HANDI-MATE
S L I D I N G D O O R H A N D I - M AT E ™ I N S TA L L AT I O N G U I D E
BEFORE YOU START
PRIOR TO INSTALLATION
It is important that you contact your local government authority to determine if building approval is required.
To ensure that the installation and erection of your Stratco Handi-Mate™ Shed proceeds smoothly you should confirm that all the components and
materials listed on the delivery documentation and in this installation guide have been supplied. Details for ordering individual components can be found in
the "Component Index" section at the end of this document.
Carefully read this installation guide to familiarise yourself with all the steps involved and ensure that you have the correct tools and equipment for the job.
All Stratco Handi-Mate™ Sheds must be securely bolted to a permanent concrete base with sufficient masonry anchors securing all four corners of the
Handi-Mate™ shed to prevent wind uplift.
SHED WINDOWS (OPTIONAL)
Stratco Shed Windows are avaliable as an optional add-on, avaliable in both Louvre and Sliding variations. Refer to the "Window Installation" section if
installing a Stratco Window, or visit your local Stratco store for more information.
FLOORING PREPARATION
The installer is responsible for ensuring the slab or concrete pads are sufficient to support the shed and sustain wind loading.
Do not directly anchor your shed to pavers.
Option 1 - Before building the shed, pour a base that is larger than the area by at least 200mm in each direction. The base should be poured so the concrete
outside the shed floor area slopes away from the shed to help prevent water from entering the shed.
Option 2 - Substantial concrete pads may be used at each anchor location as an alternative to a complete concrete floor. It is recommended pads are
minimum Ø250mm x 400mm deep, embedded into a firm natural soil base.
IMPORTANT NOTES:
It is essential to clear and level the site prior to assembling your Stratco Handi-Mate™ Shed.
1.
Note there are different types and colours of screws. Ensure that the right type and colour screw is being used at each location.
2.
Stability and performance of the shed relies on the door being closed during high wind events.
3.
Do not traverse the roof of the Handi-Mate™.
4.
Use heavy gloves when handling steel sheeting and flashings and never attempt to install a shed in windy conditions.
5.
SHED
™
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Stratco Handi-Mate 1
Summary of Contents for Stratco Handi-Mate 1
- Page 1 Carefully read this installation guide to familiarise yourself with all the steps involved and ensure that you have the correct tools and equipment for the job. All Stratco Handi-Mate™ Sheds must be securely bolted to a permanent concrete base with sufficient masonry anchors securing all four corners of the Handi-Mate™...
-
Page 2: Tools Required
TOOLS REQUIRED Rivet Gun Power Drill Phillips Head Driver Hex Head Driver Adjustable Spanner 3.5mm & 12mm Drill Bit 10mm Masonry Bit Gloves Safety Glasses Step Ladder 2 x Trestle / Saw-horse Permanent Marker Tape Measure HANDI-MATE™ MODEL SIZES 1860 mm sws cws 2210 mm Handi-Mate™... - Page 3 COMPONENTS Ridge Cap Ridge Beam Barge Support Sliding Rail Bottom Channel Runner Rail Wall Channel L/H Barge Cap R/H Barge Cap Top Door Bottom Door Door Shroud Vertical Door Jamb Channel Channel Door Channel Figure 1.1...
- Page 4 COMPONENTS Split Wall Sheet Split Door Sheet Corner Wall Sheet Wall Sheet Door Wheel Door Nut Door Stop Corner Bracket Handle Mount Door Handle Door Tongue Door Latch Hold Down Lug M8x47 Masonry Anchor 10x16 Wafer-Head 10x22 Wafer-Head 10x25 Self-Drilling 10x16 Self-Drilling 10x16 Self-Drilling Screw...
-
Page 5: Wall Assembly
Handi-Mate Window Assembly Stratco Shed Windows are avaliable as an optional add- on. Refer to the “Window Installation” section at the end of this document if installing a Stratco Window, or visit a Stratco store for more information. Corner Wall Sheet... - Page 6 Fasten the top and bottom Wall Channels to the Wall Sheets using 10x16 self-drilling screws through each pilot hole, ignoring the two holes at each Coloured Rivet end (Figure 1.8). 10x16 self-drilling screw Wall Channel Figure 1.8 Join any overlapping sheets to one another using coloured rivets through Figure 1.9 the mid-span of lapping crests (Figure 1.9).
-
Page 7: Door Assembly
Fit the Door Jamb over the Wall Sheet, ensuring it is inside the Bottom Fasten one 10x16 self-drilling screw through the underside of the Bottom Channel & Sliding Rail and into the Door Jamb (Figure 2.5). Channel and Sliding Rail (Figure 2.3). Sliding Rail Sliding Rail 10x16 self-drilling screw... - Page 8 Fix the Door Wheels to the Top Door Channel using Door Nuts (Figure 3.1). Ensure the lip of the Top and Bottom Door Channels fit over the Vertical Door Channels (Figure 3.5). Door Nut Vertical Door Channel Top Door Channel Top / Bottom Door Channel Door Wheel...
- Page 9 Crest-fix 10x16 wafer screws through the Top Door Channel and into the ø Using the pilot holes in the Handle Mounts as a guide, drill a 3.5mm pilot ø ridges either side of the Door Roller (Figure 3.9). hole, then 12mm hole through the wall sheet (Figure 3.11).
- Page 10 Fit the Corner Bracket over the Top Wall Channels. Ensure the pilot holes Use the Door Shroud as a guide to set the correct spacing between the of the Corner Bracket and Wall Channels line up (Figure 4.2). Door Jambs. Fit the Corner Bracket as per Figure 4.2 - 4.3. Top Channel Door Shroud Corner Bracket...
- Page 11 Fit the Barge Support over the Sliding Rail. Fasten 10x16 self-drilling Check the walls are square. Check the diagonal measurements from screws through each pilot hole in the Barge Support and into the Sliding corner to corner (dashed lines, Figure 4.11). The diagonal measurements Rail (Figure 4.8).
-
Page 12: Roof Assembly
The maximum spacing allowed between anchor points is determined by the wind classification assigned to the location of your Handi-Mate. If required, refer to your local council for advice on the wind classification Anchor Spacing of your location. N1 / N2 wind classifications = 1400mm maximum distance between anchor points. - Page 13 Use an adjustable spanner to turn up the pans at the ridge end of the roof Lay the roof sheeting hard against the step of the Ridge Beam. Fasten three sheets. This will prevent water flowing back under the sheet (Figure 5.3). 10x16 self-drilling screws with neo washers through the pans of the Roof Sheet and into the Ridge Beam (Figure 5.7).
- Page 14 Install the opposing side Roof Sheets as per previous steps. Use a single 10x16 self-drilling screw with neo washer to secure the overlap of the ridge caps to the Ridge Beam. Fasten the Ridge Cap to the Ridge Beam using 10x16 self-drilling screws with neo washers at 300mm spacings along the entire length of the Ridge Cap (Figure 5.13).
- Page 15 Fasten the Door Stop to the Sliding Rail with a 10x22 wafer-head screw Close the Door and rotate the handle so that the Door Tongue is spaced 630mm away from the Door Jamb (Figure 5.16). horizontal. Using the Door Tongue as a guide, fasten the Door Latch to the Door Jamb with two 10x16 self-drilling screws (Figure 5.19).
-
Page 16: Window Installation
Fasten two coloured 10x25 self-drilling screws with neo washers through the front face of each Barge Cap into the Barge Support. Stratco Shed Windows are an optional add-on, avaliable in both Louvre and Sliding variations. Installation methods are identical for each window type. -
Page 17: Component Index
Figure 5.4 SHED MAINTENANCE Wall Channel Your Stratco Handi-Mate Shed will maintain its good looks for even longer with a simple wash and wipe down. Cleaning should be performed as often as is required to remove any dirt, salt and pollutants. - Page 18 Ph: 1300 155 155 QUEENSLAND • NEW SOUTH WALES • VICTORIA AUSTRALIAN CAPITAL TERRITORY • SOUTH AUSTRALIA stratco.com.au WESTERN AUSTRALIA • NORTHERN TERRITORY All brands and logos/images accompanied by ® or ™ are trade marks of Stratco (Australia) Pty Limited.
