3.1.1 Touching the
always on, as the defaults menu is fries, it's defaulted temperature and cooking
time for Fries recipe will be displayed alternately. If pressing and hold the Power
key icon for 2 sec, it can cancel the selection for the
Standby mode.
3.1.2 Touching the Menu Choice Key Icon, that is to select the menu you need to use,
press this key once to switch to the next menu, the selected menu icon will be
flashing with the defaulted temp and time will be displayed as well. The menu can
be cycled from the first to the eighth icon.
3.1.3 Touching the Temp Key Icon, the display will flash to show the temperature of the
current menu, pressing the "+" or "-" Key Icon to adjust the temp at 5℃ range. If
press and hold the "+" or "-" Key Icon, the temperature will be adjusted
continuously. The temperature range can be adjusted from 80℃- 200℃ for each
recipe.
3.1.4 Touching the Time Key Icon, the defaulted or set time will be flashed on the display
for the selected menu, Pressing the "+" or "-" Key Icon to adjust the time, the time
will change 1min per once pressing, if pressing and hold the "+" or "-" Key Icon, the
time will be continuously adjusted. The time can be adjusted from 1min to 60min for
each recipe.
3.1.5 After the debugging to recipe, temperature and time are all complete, touch the
Power Key Icon, the pan
cooking time in count down manner.
3.1.6 If need to adjust the temperature or time during the cooking process, pressing the
Temp/Time Key Icon once, then pressing "+" or "-" Key Icon to adjust the Temp or
Time. During the adjustment process, the unit keeps working.
3.1.7 If need to reset the recipe during cooking process, it is needed to lightly press the
Power Key Icon once to pause it, the heater and motor stop working, then follow
steps 3.1.2 - 3.1.5 to re-set the recipe, and resume it.
3.2 Pause or turn off the unit during cooking process
3.2.1 If need to pause the cooking during the cooking process, pressing the Power Key
Icon once to pause the heating and motor function during the cooking process. If
pause the unit and no following operation within 3 mins, the unit will go to the
machine will enter to standby mode.
3.2.2 If need to turn off the unit during cooking, press and hold the Power Key Icon for 2
seconds, the display will show the word "OFF", the buzzer will beep once, the
display will be extinguished and the product will enter to standby mode, then press
and hold the Power Key Icon for 2 sec, unit will enter to Boot mode.
3.3 Draw out of the basket
3.3.1 If the frying pan was drawn out, the display will show the "OPEN" at any time.
3.3.2 During cooking process, If the pan was drawn out, the unit will stops working (both
heating and motor will be stopped), when the basket is inserted back the unit will
resume working setting as per previous.
3.4 The right pot (Pot
3.4.1 Touch the Key Icon, then refer to item 3.1.2 - 3.1.17 for the subsequent steps.
3.5 Cooking Process is completed
3.5.1 When the cooking process is completed, the display shows "OFF" and will beep 5
sounds, the display will be extinguished, the unit enters standby mode.
4.Double pot working mode
4.1 Starting the 2 pots
4.1.1 Firstly, select one side and debug the menu, temperature and time according to
steps 3.1.2 - 3.1.7. Secondly, select another side and debug the wanted recipe,
temperature and time in the same way.
Key Icon once, then the icons in area 1 and area 2 are lit and
starts working, and the display shows the current
) working mode
pot, then the product enters
