HOMCOM AF-D5509AS Manual page 10

4.1.2 Pressing the Power Key Icon, 2 pots start working at the same time, the display
shows both sides working time in count down manner.
4.1.3 It also can be started one side firstly as per 3.1.1 to 3.1.7 After one side is started, to
start another side as per 3.4.1.
4.2 Debug during the double pots working process
4.2.1 During the cooking process of 2 pots are working at the same time, if you need to
debug the temp or time for Pot
① or ②， then follow step 3.1.6 and 3.1.7 to complete it.
4.3 Pause or turn off the unit during the cooking process
4.3.1 In the double pots working process, if need to pause one out of 2 sides pot, need to
pressing the Pot Key Icon
Icon within 10 seconds, Pot
operation within 3 mins, the paused side will goes to standby mode. If need to
pause both sides, just pressing the Power Key Icon and 2 sides will be paused. If
no following operation within 3 mins, both sides will enter to standby mode. If need
to resume it, pressing the Power Key Icon once.
4.3.2 In the cooking process, if need to turn off one side, need to press the Pot Key Icon
or firstly, and then pressing and hold the Power Key Icon for 2 sec. Then the
selected pot will be side will goes to Standby mode. If need to turn off both side, just
need to press and hold the Power Key Icon for 2 sec.
4.4 Draw out of the basket
4.4.1 If the frying pan was drawn out, the display will show the "OPEN" at any time.
4.4.2 During cooking process, If one pan was drawn out, the corresponding side will
stops working (Pulling out one pot will not affect the work of the other pot), and it
will resume working as per previous setting when the basket is inserted back.
4.5 Cooking Process is completed
4.5.1 When the cooking process is completed, the display shows "OFF" and will beep 5
sounds, then the display will be extinguished, the unit enters standby mode.
4.6 Smart Finish Function
4.6.1 The Smart Finish function can only be activated while in double pot working mode
with the Smart Finish Key icon will be illuminated to flashing.
4.6.2 When each side are all selected, pressing the Smart Finish Key Icon, its key icon
will be stop flashing but always illuminated, then press the Power Key Icon, the
longer cooking time side starts cooking, the shorter cooking time side will be HOLD
until each side time are same, then the hold side will starts working and finish the
cooking with another side at the same time. In this process, the Smart Finish Key
Icon is always illuminated.
4.6.3 When one side is on cooking, and another is HOLD:
4.6.3.1 If adjust the Hold side pre-set time to over the current cooking time for the cooking
side, or to adjust the cooking time of the cooking side to let it smaller than the pre-
set time of the HOLD side, the Smart Finish mode will be quitted, and the Smart
Finish icon will be extinguished. Each side keeps working as per its own preset
cooking time.
4.6.3.2 If withdraw the working side, its display shows "OPEN", this side will stops
working, but the HOLD side still shows "HOLD", Insert back the basket, this side
resume working and unit still in the smart finish mode.
4.6.3.3 If withdraw the HOLD side basket, its display will show "Open", but the working
side is still on working without influence.
4.6.3.4 When withdraw the HOLD side basket, if the cooking time at another side is
decreased less than the pre-set cooking time for the HOLD side, but the withdraw
basket doesn't inserted back, the Smart Finish mode will be quitted, and the
Smart Finish icon will be extinguished. Each side keeps working as per its own
or Pot temperature or time, Need to choose
or key icon firstly, and then pressing the Power Key
or Pot will be paused working. If no following
10
