up， the menu defaults to the first menu (fries), at this time the fries indicator flashes,
pot corresponding digital tube display flashes, and alternately display the default
temperature and time of the fries program. When the temperature is displayed, the
temperature indicator on the upper left of the display are always on. When the time is
displayed, the time indicator on the lower left of the display will be always on. If you press
key for 2 seconds, you can cancel the selection of ② pot and the product enters
the
standby mode.
Key 5 & Key6 –Temperature and Time Control Keys For The left pot Key
The Key 5 and Key 6 symbols enable you to add or decrease cooking temperature 5℃ at
a time for left pot. Keeping the Key held down will rapidly change the temperature.
Temperature Control range: 80℃—200℃.Also can to add or decrease cooking time for
left pot, one minute at a time. Keeping the key held down will rapidly change the time.
Time Control range:1min-60min.
Key 7 & Key 8
The Key 7 and Key 8 symbols enable you to add or decrease cooking temperature 5℃ at
a time for right pot. Keeping the Key held down will rapidly change the temperature.
Temperature Control range: 80℃—200℃.Also can to add or decrease cooking time for
right pot, one minute at a time. Keeping the key held down will rapidly change the time.
Time Control range:1min-60min.
Key 9 –Temp /Time Key Icon
Touch the " "key, pressing it and corresponding to the screen display the temp or time,
you can adjust the temperature and time you need.
Key 10 –Synchronization end key
Touch the " "key, two recipe with different time can be ended at the same time。
Indicator light "11 " Nixie tube for the left pot body
Indicator light "12 " Temperature light for the left pot body
Indicator light "13 " Time light for the left pot body
Indicator light "14 " Nixie tube for the right pot body
Indicator light "15 " Temperature light for the right pot body
Indicator light "16 " Time light for the right pot body
Indicator light " 17-24 " Recipe indicator
Detailed Operation Instructions
1. Boot mode
Firstly to confirm that the frying pan is correctly installed into the machine, insert the
plug into the socket, the machine will be powered on, the machine will beep once, all
the lights are lit for one second and then extinguished, the Power Icon will be
illuminated.
2. Standby Mode
Touch the Power Icon, and the Pot 1 Selection Icon and Pot 2 Select Icon indicator
lights up and stays on, the product enters standby mode. When the unit is in this
Standby mode and has not been operated within 3 mins, unit will be goes to Boot
mode.
3. Single pot working mode
3.1 The left pot(Pot
–Temperature and Time Control Keys For The right pot Key
)working mode
