  • Page 1 TAU 115÷600 N OIL EN INSTALLATION, TECHNICAL ASSISTANCE SERVICE AND SYSTEM MANAGEMENT MANUAL...
  • Page 2 MODEL CODE give dependable and safe service and to provide comfort in TAU 115 N OIL 20124406 the home for many years to come. Arrange for your boiler to be TAU 150 N OIL 20124407 serviced regularly by an authorised Technical Assistance Service .
  • Page 3: Table Of Contents

    Contents CONTENTS 1 GENERAL INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 General Safety Information .
  • Page 4: General Information

    GENERAL INFORMATION GENERAL INFORMATION GENERAL INFORMATION Precautions The operation of any appliance that uses fuel, electrical power General Safety Information and water demands that a number of fundamental safety pre- cautions be respected: The boiler is delivered in separate crates. Check that it is complete, undamaged and as ordered as soon as you re- It is forbidden to use electrical devices or equipment, such ceive it.
  • Page 5: Description Of The Appliance

    GENERAL INFORMATION GENERAL INFORMATION Description of the appliance TAU N OIL boilers feature lightly pressurised combustion cham- bers for a smoother burner action, and high temperature resist- TAU N OIL steel boilers are triple flue pass, condensing boil- ant, stainless steel turbulators inside the tube bundle for maxi- ers for installation in a boiler room.
  • Page 6: Control Panels

    GENERAL INFORMATION GENERAL INFORMATION Control panels control panels that can be used with TAU N OIL steel boilers are listed below. These control panels cater for all the needs of the heating system and of all the devices installed in it. TECH CLIMA TOP for central heating (1 direct zone and 2 mixed zones) and domestic hot water production with a single stage, two stage, or modulating burner.
  • Page 7: Recommended Burners And Technical Specifications

    GENERAL INFORMATION GENERAL INFORMATION Recommended burners and technical specifications 1.5.1 TAU N OIL with power < 400 kW The burners suggested to obtain the best performance of TAU N OIL <400 kW boilers are: BURNERS TAU N OIL MODEL CODE BG7.1D 20015696 RL 25 BLU...
  • Page 8 GENERAL INFORMATION GENERAL INFORMATION Technical specifications TAU N OIL DESCRIPTION Condensing boiler for central heating Device type Fuel Low-sulphur fuel oil (< 50ppm) Device category See Burner Rated heat input (Qmax) HCV (LCV) (115) (150) (210) (270) (350) Rated heat input (Qmin) HCV (LCV) (80) (111) (151)
  • Page 9: Tau N Oil With Power > 400 Kw

    GENERAL INFORMATION GENERAL INFORMATION 1.5.2 TAU N OIL with power > 400 kW The burners suggested to obtain the best performance of TAU N OIL >400 kW boilers are: BURNERS TAU N OIL MODEL CODE RL 42 BLU 20027567 RL 55/M BLU 3899210 RL 85/M BLU 3896011...
  • Page 10 GENERAL INFORMATION GENERAL INFORMATION Technical specifications TAU N OIL DESCRIPTION Condensing boiler for central heating Device type Fuel Low-sulphur fuel oil (< 50ppm) Device category See Burner Rated heat input (Qmax) HCV (LCV) (450) (600) Rated heat input (Qmin) HCV (LCV) (351) (451) Useful (rated) heat output...
  • Page 11: Identification

    The products are identified by: Serial number plate This is located on the boiler body and specifies the serial num- ber, model, and furnace power. RIELLO S.p.A. Via Ing.Pilade Riello 7 37045 Legnago (VR) - ITALY Data plate Pres. Max esercizio Matricola Max.operating press.
  • Page 12: System Manager

    SYSTEM MANAGER SYSTEM MANAGER 2 SYSTEM MANAGER − Adjust the timer thermostat (if installed) or the tempera- ture control to the desired temperature (~20° C) Putting into service Have ’s Technical Assistance Service start up your TAU N OIL boiler for the first time. Once this has been done, the boiler can be left to function automatically.
  • Page 13: Preparing For Extended Periods Of Disuse

    SYSTEM MANAGER SYSTEM MANAGER Preparing for extended periods of disuse Cleaning If the boiler is not going to be used for an extended period of Use a cloth damped in soapy water to clean the boiler’s external time, perform the following operations: casing.
  • Page 14: Useful Information

    SYSTEM MANAGER SYSTEM MANAGER Useful information Seller: ................Installer: ................Mr.: .................. Mr.: .................. Address: ................Address: ................Tel.: .................. Tel.: .................. Technical Assistance Service: ..........Mr.: .................. Address: ................Tel.: .................. Date Work done Fuel oil supplier: ............... Mr.: .................. Address: ................
  • Page 15: Installer

    INSTALLER INSTALLER 3 INSTALLER The second package contains the panelling, complete with the assembly accessories, inside a protective cardboard box and a wooden crate. Unpacking the product For the boiler to function correctly, it must be connected to a The TAU N OIL boiler is supplied in two separate packages. control panel and dedicated control accessories.
  • Page 16: Overall Dimensions And Weights

    INSTALLER INSTALLER Overall dimensions and weights TAU N OIL DESCRIPTION A - Base width B - Width L - Length 1455 1455 1455 1630 1830 2035 2235 L1 - Base depth 1295 1295 1295 1470 1670 1875 2075 H - Height of water fittings 1315 1315 1315...
  • Page 17: Installation Premises

    INSTALLER INSTALLER Installation premises TAU N OIL steel boilers must be installed in a dedicated In Belgium, boilers must be installed according to standards boiler room, with adequately sized vents, in compliance with NBN D51.003, NBN D30.003, NBN B61.002 (heat output < 70 applicable laws and standards.
  • Page 18: Water In Central Heating Systems

    INSTALLER INSTALLER Water in central heating systems 2. Central heating systems INTRODUCTION Do not use automatic filling devices to add water to central heating systems. Use a manual device instead and record Water used in central heating systems MUST be suitably treated top-ups in the system service book.
  • Page 19 INSTALLER INSTALLER 4. Eliminating air and gas from central heating systems If oxygen enters a circuit continuously or even intermittently (e.g. in under-floor heating systems whose pipes are not pro- tected by impermeable synthetic sheaths, in circuits with open expansion vessels, or in circuits that require frequent top-ups) always separate the boiler’s water circuit from the central heat- ing circuit.
  • Page 20: Water Connections

    INSTALLER INSTALLER Water connections TAU N OIL boilers are designed and made for use in central heating installations, but can also be used for domestic hot water production if connected to a suitable storage cylinder. Water fittings are as specified in the following table. TAU N OIL DESCRIPTION 1 - Heating flow (*)
  • Page 21 INSTALLER INSTALLER TYPICAL INSTALLATION SCHEMATIC Direct systems DHW USER HEATING HEATING FLOW POINTS RETURN 16 3 INLET 15 3 Direct and mixed systems HEATING FLOW DHW USER POINTS HEATING HEATING RETURN RETURN BT (*) AT (*) 15 16 INLET 15 3 Boiler TAU N OIL 15 Water softener filter...
  • Page 22: Condensate Evacuation

    INSTALLER INSTALLER Condensate evacuation 3.8 Neutralising the condensate TAU N OIL condensing boilers produce a flow of condensate that NEUTRALISATION KIT N2-N3 varies according to operating conditions. The maximum hourly N2-N3 neutralisation units are designed for systems with boiler production of condensate is shown in the technical specifica- condensate drain pits located at a lower level than the boiler tions table for each individual model.
  • Page 23 INSTALLER INSTALLER NEUTRALISATION UNIT TYPES HN2-NH3 (with pump) The connection pipes used must be as short and straight as HN2 and NH3 neutralisation units are designed for systems with possible and corrosion-resistant. Any curves or sharp bends boiler condensate drain pits at a higher level than the boiler can lead to the hoses becoming clogged and can therefore condensate drain fitting.
  • Page 24: Discharge Of Combustion Products

    INSTALLER INSTALLER Discharge of combustion products The flue gas exhaust and stack connection must be made in compliance with applicable laws and standards, using heat resistant, condensate resistant and stress resistant rigid pipe and sealed joints. The stack must be fitted with a condensate trap and drain and the flue gas exhaust pipe must be installed at a slope of at least 3° towards the boiler.
  • Page 25: Door Hinges

    INSTALLER INSTALLER 3.10 Door hinges Smaller sizes The boilers are pre-fitted with three hinges so that the direction (system A) of opening of the door can be rapidly reversed. Once you have checked that the default direction of opening is as required, or have reversed the direction of opening as in- structed in the ‘Changing the direction of door opening’...
  • Page 26 INSTALLER INSTALLER System B - Larger sizes Open the door and with the aid of Then seal the door by tightening the bolts (2) so that the door is self-supported by a small hacksaw or a file remove the compression against the packing. knockout on the side opposite the Remove the plug (1) taking care not to lose the compressed spring inserted in the leading edge of the door (both top and...
  • Page 27: Removing The Hinge Assembly "B

    INSTALLER INSTALLER 3.12 Removing the hinge assembly "B" System A − First ensure that the side safety bolt (2) is tight and then (**) remove the main fixing bolt (1) − With the door open, remove the hinge assembly ‘B’ (bushing, bolt, and washer) opposite the pivot side of the door.
  • Page 28: Fitting The Casing Panels

    INSTALLER INSTALLER 3.14 Fitting the casing panels To mount the panelling, proceed as follows: On models 450, 600, also fit side panels (6) and (7). − Push out the pre-formed slots in the boiler’s side panel − Secure the side panels in place using the top cross beams (2) or (3) depending on what side you want to install the (8) and the screws provided control panel) corresponding to the oval cable grommets...
  • Page 29 The labels can be found in the document pouch. The appliance installer MUST apply these labels, as shown in the figure below, once installation is complete. They must be visible. If the labels are lost, please request new ones from the Technical Assistance Service. RIELLO S.p.A. Via Ing.Pilade Riello 7 37045 Legnago (VR) - ITALY 066940IE CALDAIA IN ACCIAIO STEEL BOILER...
  • Page 30: Technical Assistance Service

    TECHNICAL ASSISTANCE SERVICE TECHNICAL ASSISTANCE SERVICE 4 TECHNICAL ASSISTANCE SERVICE − The mains power connections to the boiler and its ac- cessories (burner, pump, control panel, thermostats, etc.) have been properly made. Preparing for initial startup It is essential to perform the following checks before starting up or testing the functioning of your TAU N OIL boiler.
  • Page 31: Checks During And After Initial Start-Up

    TECHNICAL ASSISTANCE SERVICE TECHNICAL ASSISTANCE SERVICE The burner should now ignite and remain in operation until the Turn off the main power switch to the boiler and make sure that set temperature is reached. the boiler shuts down properly. If any ignition faults or malfunctions occur, the burner performs a “LOCKOUT SHUTDOWN”.
  • Page 32: Cleaning The Boiler

    TECHNICAL ASSISTANCE SERVICE TECHNICAL ASSISTANCE SERVICE OPENING THE DOOR System A − Make sure that the safety bolts (1) on the side of the boiler are tight. System A - B − To open the door, simply remove the main fixing bolts 2 System B holding the door in place.
  • Page 33 TECHNICAL ASSISTANCE SERVICE TECHNICAL ASSISTANCE SERVICE − Use a flue brush (3) or other suitable tool to clean inside Clean condensation trap the combustion chamber and the flue gas pipes − Disconnect the corrugated condensate outlet pipes (1) − Remove the deposits accumulated in the flue box and the tapping point pipe (2), and remove the inspec- through the opening of the inspection door (4).
  • Page 34: Troubleshooting

    TECHNICAL ASSISTANCE SERVICE TECHNICAL ASSISTANCE SERVICE 4.6 Troubleshooting FAULT CAUSE SOLUTION Boiler dirty − Clean the flue gas pipes Heat exchanger and burner mismatched − Check specifications and settings The boiler does not reach its temperature setpoint Burner capacity insufficient −...
  • Page 35 TECHNICAL ASSISTANCE SERVICE TECHNICAL ASSISTANCE SERVICE...
  • Page 36 TECHNICAL ASSISTANCE SERVICE TECHNICAL ASSISTANCE SERVICE...
  • Page 37 TECHNICAL ASSISTANCE SERVICE TECHNICAL ASSISTANCE SERVICE...
  • Page 38 RIELLO S.p.A. Via Ing. Pilade Riello, 7 37045 - Legnago (VR) www.riello.com The manufacturer strives to continuously improve all products. Appearance, dimensions, technical specifications, standard equipment and accessories are therefore liable to modification without notice.
