- Page 1 Sentinel Kinetic MVHR Range Quick installation guide...
-
Page 2: Product Description
Product Description Product Description Sentinel Kinetic, Sentinel Kinetic F, Sentinel Kinetic Plus & Sentinel Kinetic High Flow Units are available with the condensate drain on the right or left hand side. Fig 1: Sentinel Kinetic Right handed Fig 2: Sentinel Kinetic F, Sentinel Kinetic Plus and High Flow Right handed Fig 3: Sentinel Kinetic Left handed Fig 4: Sentinel Kinetic F, Sentinel Kinetic Plus and High Flow Left... -
Page 3: Installation
Installation Figure 5: Sentinel Kinetic Dimensions Figure 6: Sentinel Kinetic Plus and Sentinel Kinetic High Flow Dimensions Sentinel Kinetic MVHR Installation & Commissioning... - Page 4 Vent Axia Sentinel Kinetic MVHR Wiring Option 1 - Mains Voltage Boost Switch Diagram Black wire from unit Connection Block inside protected box Factory Fitted Cable Supply Spur Min 1.0mm2 cable Live/Neutral/Earth Fit to front 'BMS' port only Boost Switch Alternative Wiring without 3 pole isolator 3 pole isolator Supply Spur...
