- Page 1 Silent Fan Installation and Wiring Instructions Stock Ref. N° 44 66 58A - VASF100B 44 66 59A - VASF100T 220-240V~50Hz IP44 PLEASE READ INSTRUCTIONS IN CONJUNCTION WITH ILLUSTRATIONS. PLEASE SAVE THESE INSTRUCTIONS.
-
Page 2: Safety And Guidance Notes
Installation and Wiring Instructions for the Silent Range of Extractor Fans. IMPORTANT: READ THESE INSTRUCTIONS BEFORE COMMENCING THE INSTALLATION DO NOT install this product in areas where the following may be present or occur: • Excessive oil or a grease laden atmosphere. •... -
Page 3: Installation
Stock Reference WINDOW FITTING KIT White Brown For use in single or sealed double Wall Fitting Kit 100mm 254102 254100 glazing and most materials up to 40mm thick. Window Fitting Kit 100mm 442947 - A. INSTALLATION IMPORTANT: The fan should only be used in conjunction with fixed wiring. For positioning of fan refer to Fig.1. - Page 4 1. Select and follow the appropriate wiring diagram. (Fig. 2 or 3) 2. Check all connections have been made correctly and ensure all terminal connections are securely fastened. 3. Ensure the impeller rotates and is free from obstructions. Fig.2 – Basic VASF100B 3A (Max) Note: LS is not used on the basic model Fig.3 –...
-
Page 5: Speed Setting
C. SETUP WARNING: THE FAN AND ANCILLARY CONTROL EQUIPMENT MUST BE ISOLATED FROM THE POWER SUPPLY DURING THE INSTALLATION / OR MAINTENANCE. SPEED SETTING: The fans are factory set to low-speed, but have two speed settings for different installation requirements; you can select either high or low speed as follows: SILENT FAN –... -
Page 6: Servicing And Maintenance
D. SERVICING AND MAINTENANCE. WARNING: THE FAN AND ANCILLARY CONTROL EQUIPMENT MUST BE ISOLATED FROM THE POWER SUPPLY DURING MAINTENANCE. 1. At intervals appropriate to the installation, the fan should be inspected and cleaned to ensure there is no build up of dirt or other deposits. 2.
