Page 1: Table Of Contents
Duty cycle measurement (Duty Cycle/%) Resistance measurement Acoustic continuity test Diode test Capacity measurement OPERATING INSTRUCTIONS Measuring AC Measuring DC Measuring DC voltage Measuring AC voltage Measuring resistance / continuity / diode Auto Power OFF True RMS Technical data Testboy ® TV 216N... -
Page 2: Operation
Measuring instruments and their accessories are not toys, and must be kept out of the reach of children! In industrial facilities, the accident prevention regulations for electrical systems and equipment, established by the employer's liability insurance association, must be observed. Testboy ® TV 216N... - Page 3 Testboy or the use of replacement parts that have not been approved or manufactured by Testboy the use of alcohol, drugs or medication. Accuracy of the operating instructions These operating instructions have been compiled with due care and attention.
- Page 4 Certificate of quality All activities and processes carried out within Testboy GmbH relating to quality are monitored permanently within the framework of a Quality Management System. Furthermore, Testboy GmbH confirms that the testing equipment and instruments used during the calibration process are subject to a permanent inspection process.
-
Page 5: Operation
Thank you for purchasing the Testboy TV 216N ® The Testboy TV 216N is intended for measuring systems of Category CAT III and for voltages ® that do not exceed the reference to earth 600 V (AC or DC). Operation Before taking a measurement, allow the appliance to acclimatize. -
Page 6: Product-Specific Safety Instructions
When using this clamp meter, the user must observe all normal safety rules concerning: Protection against dangers of electric current. Protection of the clamp meter against misuse. For own safety, only use the test probes supplied with the instrument. Before use, check that they are in good conditions. Testboy ® TV 216N... -
Page 7: Maintenance And Cleaning
Use a screwdriver to release the safety screw at the rear. Remove the used batteries and replace with new batteries, type 1.5 V AAA. Replace the cover and secure with the screw. Batteries must not be disposed of with normal domestic waste. There will be a collection point near you! Testboy ® TV 216N... -
Page 8: Explanation Of Buttons
Press the B.L./HOLD button to freeze the value displayed at present. Press and hold the B.L./HOLD button to switch on the background lighting. Setting on the current range also switches on the lighting at the measurement point. Testboy ® TV 216N... -
Page 9: Measuring Transformer, Tong Jaws
The value is displayed and retained, this measurement is only carried out once. After the measurement, keep the "SEL" button pressed, to change to the normal measurement mode, by again pressing, returns to the inrush measurement. Testboy ® TV 216N... -
Page 10: Dc Measurement
± (1.2 % + 5 digits) 60 V 0.01 V 600 V 0.1 V ± (1.5 % + 10 digits) Input impedance: 10 M Frequency response: 40-400 Hz Maximum input voltage. 600 V DC or 600 V AC RMS. Testboy ® TV 216N... -
Page 11: Frequency Measurement (With The Clamp-On Ammeter)
600 0.1 6 k 0.001 k ± (1.2 % + 2 digits) 60 k 0.01 k 600 k 0.1 k 6 M 0.001 M ± (2.0 % + 5 digits) 60 M 0.1 M Testboy ® TV 216N... -
Page 12: Acoustic Continuity Test
< 2 µF ± (4.0 % + 5 digits) 60 µF 0.01 µF ± (4.0 % + 3 digits) 600 µF 0.1 µF 6 mF 1 µF 60 mF 10 µF Overload protection: 250 V DC or AC RMS Testboy ® TV 216N... -
Page 13: Operating Instructions
Set the function switch to range"V" To select the DC, press the button "SEL". Insert the black and red test leads into the inputs COM and INPUT. Apply the test leads to the circuit to be measured and read the value. Testboy ® TV 216N... -
Page 14: Measuring Ac Voltage
1 – 50 Digits can occur. However, the test result is not influenced. In order to maximize the precision of the appliance, the AC voltage should be > 13 mV and the AC > 1.3 A. Testboy ® TV 216N... -
Page 15: Technical Data
If the battery voltage is insufficient, the battery symbol appears on the display Tong opening Cable 20 - 23 mm Dimensions 155 x 50 x 25 mm (WxHxD) Weight approx. 340 g (with batteries) Accessories Operating instructions, bag Testboy ® TV 216N...
